1
User Manual
NF620
Before using the product, please read this manual carefully
2
Notice:
Signal Communications Limited reserves the right to make improvements to the product
described in this manual at any time and without prior notice.
This manual is copyrighted. All rights are reserved. This manual may not be copied, reproduced
or translated in whole or part without prior consent rom Signal Communications Limited.
Tele Eye is a trademark o Signal Communications Limited and is registered in China, Hong
Kong, US and other countries.
TeleEye's products are sold under the brand name o CAMERIO in Australia, Japan, Korea, New
Zealand, Taiwan and Argentina.
CAMERIO is a trademark o Signal Communications Limited and is registered in Australia,
Japan, Korea, New Zealand, Taiwan and Argentina.
All other trademarks are the property o their respective owners
Copyright (c) 2007 Signal Communications Limited (A Member o TeleEye Group). All rights
reserved.
Version 1.5
Limits o Liability and Disclaimer o Warranty
Signal Communications Limited has taken care in preparation o this manual, but makes no
expressed or implied warranty o any kind and assume no responsibility or errors or omissions.
No liability is assumed or incidental or consequential damages in connection with or arising out
o the use o the in ormation or accessories contained herein.
Features and speci ications are subject to change without prior notice.
3
Table Of Contents
SAFETY PRECAUTIONS........................................................ 5
. PRODUCT FEATURES....................................................... 6
1.1 PRODUCT INSTRUCTIONS ................................................. 6
1.2 PRODUCT FEATURES ....................................................... 7
1.3 TECHNICAL SPECIFICATIONS............................................. 8
2. DESCRIPTION OF THE FRONT/REAR VIEW.................. 0
2.1 FRONT PANEL AND REAR PANEL ..................................... 10
2.2 RS-232 PORT & ALARM I/O ........................................ 11
2.3 FLANK PANEL................................................................ 12
2.4 THE USB FUNCTION...................................................... 13
3. INSTALLATION................................................................. 4
3.1 CONNECTING WITH A MULTIPLEXER..................... 14
3.2 UPDATING SYSTEM SOFTWARE ............................ 15
3.3 NF620 SD CARD TROUBLESHOOTING ............................ 17
4. Network Configuration .................................................... 8
4.1 CABLE CONNECTIONS ................................................... 18
4.1.1 Connect to a computer ................................. 18
4.1.2 Connect to a LAN Hub (INTRANET) ............ 19
4.2 CONFIGURE YOUR NF620 NETWORK SETTINGS.............. 20
4.2.1 Enable DHCP Function ................................ 20
4.2.2 Set IP Address.............................................. 20
4.3 TCP/IP COMMUNICATION SOFTWARE ............................. 22
4.4 TCP/IP INSTALLATION ................................................... 24
4.5 TCP/IP CONFIGURATION SETTING................................... 25
4.6 CONNECTION TESTING .................................................. 26
4
5. Operating Instructions for Image Software and
Network................................................................................. 28
5.1 MICROSOFT INTERNET EXPLORER .................................. 29
5.1.1 Connecting the NF620................................. 29
5.1.2 Change Image Setting................................. 31
5.1.3 Change the Network Setting........................ 33
5.1.4 Change the System Setting......................... 41
5.1.5 Change the Application Setting ................... 47
5.1.6 Change the SD card Setting........................ 55
5.1.7 Change the Pan/Tilt setting ......................... 56
5.1.8 PPPoE & DDNS .......................................... 59
5.2 THE NF62S.................................................................. 61
5.2.1 Introduction to NF62S.................................. 61
5.2.2 Install the NF62S in your PC ....................... 61
5.2.3 NF62S ......................................................... 65
5.2.4 The Image Viewer ....................................... 81
6. ADVANCED OPERATION ................................................ 82
7. SPECIFICATIONS............................................................. 86
APPENDIX . –NF620 UPnP How To .................................. 87
APPENDIX 2. –The ARP function........................................ 98
APPENDIX 3. –Register as a DDNS member ................... 00
APPENDIX 4. –FAQ ............................................................ 04
5
SAFETY PRECAUTIONS
All the ollowing sa ety and operational instructions to prevent harm or injury to the operator(s) or
other persons should be read care ully be ore the unit is activated.
WARNING
To prevent ire or shock hazard, avoid exposing this unit to rain or moisture.
Do not block ventilation openings.
Do not place anything on top o the unit that might spill or all into it.
Do not attempt to service this unit yoursel , as opening or removing covers may
expose you to dangerous voltage or other hazards. Please re er all servicing to
your distributor / retailer.
Do not use liquid cleaners or aerosols or cleaning.
To prevent ire or electric shock, do not overload wall outlets or extension cord.
This unit must be grounded to reduce the risk o electric shocks.
6
. PRODUCT FEATURES
1.1 Product Instructions
This user- riendly device combines cutting-edge sophistication with practical reliability and
convenience, high per ormance with smooth remote communication. Just plug in the network
cable!! You’ll get live streaming Video & Audio anytime any place! You’ll have security you can rely
on! The especially high resolution has 480 TV lines, a built-in web server and a Network inter ace to
connect you with the Internet securely and ast.
Other special eatures include the masking o personal private images with lexible mask-area
positioning and size, the sel -downloading automatic video codec and other components, and the
whole unit is very easy to set up. You can access the network to get smooth images through the
real-time and synchronized audio / visual stream provided by the device, because it supports two
compression modes, the MJPEG and the MPEG4 -- you can change rom one to the other as you
wish. The MPEG4 ile ormat is a very small size ile, so it can save more images over a longer time
and can be set extremely ast. The device also has a built-in website server providing many Internet
unctions and protocols, including the MDIX protocol which recognizes both the normal and the
crossover cables, either o which can connect up with a NF620.
We hope this device makes it easier or you to get your IP address in ormation. This unit supports
the USB inter ace which helps you to very easily get an IP address to open the IE browser: just type
in your IP address to the browser and you can access your NF620.
The device can hope ully provide the advanced motion detection unction to improve your network
surveillance with both the power ul and enhanced multi-zone and multi-sensitivity modes o
detection. We believe this unit is the right answer to all your network surveillance problems. Try it
and you'll see.
7
1.2 Product Features
◆ 1/3” Sony Super HAD CCD sensor.
◆ 480 TV lines.
◆ Built-in web server.
◆ Our comprehensive Plug & Play eatures-
* PnP video codec–installation o automatic video codec or any component.
* PnP IP address–supports UPnP protocol.
* PnP con iguration–USB inter ace or setup.
* PnP recording–built-in SD card or recording.
◆ Auto white balance (AWB) & auto tracing white balance or color temperatures rom
2500°k to 9500°k.
◆ Advanced motion detection–multi-zone & multi-sensitivity.
◆ Privacy image masking with ree position and size.
◆ CIF up to Full D1 resolution.
◆ Low Lux: By employing high sensitivity image sensor and low noise circuit design
produces 0.5 lux.
◆ Auto Iris Control (AIC), Auto Gain Control (AGC), Auto Back Light Compensation
(ABLC), and Flicker less (FL)
◆ Fixed shutter speed: 1/1000 sec.
◆ Supports the SD card as a local storage.
◆ Dual codec---MPEG4/MJPEG or various applications.
◆ Real-time and synchronized A/V stream.
◆ No latency. Synchronized Analogy / Digital signal.
◆ Position a camera any place you want–No PC required or operation.
◆ Supports pre-alarm & post-alarm unctions.
◆ Supports the MDIX protocol. Recognizes both the normal and the crossover cables,
either o which can connect up with a NF620.
8
1.3 Technical Speci ications
General:
Built‧-in Web Server and network inter ace. You don’t need a PC to operate.
Installation:
Fast and simple installation ‧– connect to your network and assign an IP address within a
minute. The null modem cable enclosed helps you to set up without a network.
Camera:
Digital, 24‧-bit color.
Image sensor:
‧1/3 inch Sony Super HAD CCD sensor.
MPEG4 resolution (pixels): 640×480, 320x240‧
Exposure:
Automatic AGC.‧
White Balance: Indoor installation.‧
Exposure times: 1/30‧-1/27,000s.
Sensitivity:
Minimum Illumination: 0.5 Lux. F1.2‧
Image:
Image rame rate: up to 25 rames/second.‧
‧Supports two compression modes, the Motion-JPEG and the MPEG4.
5 levels o compression provided. The ile size o an M‧-JPEG compressed image
depends on the image’s actual content. Images with a lot o detail will generate bigger
iles. The level o compression determines the image quality. High compression requires
smaller iles while low compression gives you iner image quality along with bigger iles.
The table below contains the average ile size in Kbytes, derived rom real li e tests.
General I/O:
Input/Output connector to trigger the camera vis‧-a-vis external events, or instance a
door sensor with a solenoid.
Event triggered remote image storage through e‧-mail and FTP.
System Requirements:
‧Compatible with operating systems such as Windows 2000 and Windows XP.
‧Internet Explorer 6.x.
Non‧-network modem installation needs Windows PC.
9
Supported Protocols:
‧TCP/IP, DHCP, HTTP, SMTP, SNTP, DDNS, DNS
Security:
Password protection available, unless exposure is pre erred.‧
Connections:
RJ 45 twisted pa‧ir cable, 10/100 Mbit Ethernet network connection.
Modem connection: RS‧-232 modem connector or dial-up use. Supports most V90
modems.
Input/Output connector to trigger the camera vis‧-a-vis external events.
Operating Environment:
Operation temperature: ‧41-122° F (5-50° C).
Humidity: 20‧-80% RHG, non-condensing.
WARNING: Avoid aiming the camera at the sun or other extremely bright lights.
Irrespective o whether the camera is used or unused, the CCD image sensor may be
damaged i exposed to very bright objects. Dimensions and weight are as ollows.
Dimensions / Weight:
Height:‧ 55 (mm)
Width:‧ 95 (mm)
Length:‧ 62 (mm)
Weight:‧ 306 g
(Not including power supply and mini-tripod.)
Accessories Included:
‧CD-R x 1
Power supply: 5V DC/2A.‧
‧Instruction manual.
10
2. DESCRIPTION OF THE
FRONT/REAR VIEW
2.1 Front Panel and Rear Panel
-- Front Panel -- -- Rear Panel --
1
I/O
DC5V
ETHERNET
VIDEO
4
2 3
5
.
MICROPHONE:
The NF620
has an additional audio unction. The device has a microphone built into its ront
panel which records sound.
2.
ALARM I/O & RS-232 Port:
The RS-
232 communication port unctions as a connector to an external control device. This
port includes ALARM OUT, GROUND, ALARM IN, and ALARM RECOVER or connecting with
external devices.
WARNING: You can't use general RS-232
cables to link up with the I/O connectors in the rear
panel o the device (please see the next page or urther details).
3.
VIDEO OUT Connector:
The connector provides the unit’s composite video signals to a monitor.
4.
Plug Inlet:
A DC 5V inlet that connects to an external power supply.
5.
ETHERNET 0/ 00 Connector:
This is a standard RJ-45 connector or 10/100 Mbps Ethernet networks.
