Teledyne Forge 5GigE Manual de usuario

INSTALLATIONGUIDE

FORGE®

Version 1.0

Revised 1/18/2023

1/18/2023

FCC Compliance

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device must accept any interference received, including interference

that may cause undesirable operation.

Korean EMCCertification

The KCC symbol indicates that this product complies with Korea’s Electrical Communication Basic Law regarding EMC

testing for electromagnetic interference (EMI) and susceptibility (EMS). This equipment has received a conformity

assessment for use in a business environment, and it may cause radio frequency interference if it is used in a home

environment.

Hardware Warranty

The warranty for the Forge 5GigE camera is 3 years. For detailed information on how to repair or replace your camera,

please see the terms and conditions on our website.

Export Control

The ECCN for this product is EAR099.

WEEE

The symbol indicates that this product may not be treated as household waste. Please ensure this product

is properly disposed as inappropriate waste handling of this product may cause potential hazards to the

environment and human health. For more detailed information about recycling of this product, please

Trademarks

Names and marks appearing on the products herein are either registered trademarks or trademarks of Teledyne FLIR,

LLC and/or its subsidiaries.

Licensing

To view the licenses of open source packages used in this product please see What open source packages does

firmware use?

1/18/2023

Table of Contents

1 Forge 5GigE Installation Guide 1

2 Handling Precautions and Camera Care 2

3 Forge 5GigE Installation 3

3.1 Preparing for Installation 3

3.2 Installing your Interface Card and Software 4

3.3 Installing your Forge 5GigE 5

3.4 Powering your Forge 5GigE 5

4 Tools to Control your Forge 5GigE 7

4.1 Using the Spinnaker® SDK 7

4.1.1 SpinView Camera Evaluation Application 7

4.1.2 Custom Applications Built with the Spinnaker API 7

4.2 Using GenICam Applications 8

5 Configuring Forge 5GigE Setup 9

5.1 Configuring Camera Drivers 9

5.2 Configuring the IP Address 9

5.3 Allocating Bandwidth 10

5.3.1 Determining Bandwidth Requirements 10

5.4 Configuring Other Ethernet Settings 11

5.4.1 Stream Channel Destination Address 11

5.4.2 Heartbeat 11

5.5 Forge 5GigE Firmware 12

5.5.1 Determining Firmware Version 12

5.5.2 Upgrading Firmware 12

6 Forge 5GigE Physical Interface 14

6.1 Forge 5GigE Physical Description 14

6.2 Forge 5GigE Dimensions 15

6.3 Interface Connector 16

6.4 Interface Cables 16

6.5 Interface Card 16

6.6 General Purpose Input/Output (GPIO) 17

1/18/2023

Teledyne FLIR Forge®Installation Guide i

6.7 Mounting your Forge 5GigE 18

6.8 Camera Temperature and Heat Dissipation 19

6.9 Lens Mounting 19

6.9.1 Back Flange Distance 19

6.10 Non-Volatile Flash Memory 19

6.11 Dust Protection 20

6.12 Infrared Cut-Off Filters 20

6.13 Readout Method 22

6.13.1 Global Shutter 22

7 Input/Output Control 23

7.1 General Purpose Input/Output (GPIO) 23

7.2 GPIO Electrical Characteristics 25

7.3 Input Timing Characteristics 27

7.4 Output Timing Characteristics 29

8 Troubleshooting 31

8.1 Support 31

8.2 Status Indicator LED 32

Contacting Us 33

Revision History 33

1/18/2023

Teledyne FLIR Forge®Installation Guide ii

1 Forge 5GigE Installation Guide

Welcome to the Forge 5GigE camera. We offer a number of resources to assist you with the Forge 5GigE.

nSpinnaker SDK—software development kit that provides GenICam-compliant controls to create applications for

the camera. Spinnaker is available for download. Each installation includes API documentation for C, C++, and

C#.

nRelease Notes—information about the current firmware release including feature additions or changes, bug

fixes, and known issues.

nSpecifications—information about the camera model as it performs with the current firmware.

nGetting Started—quick start guide for installing the camera and software.

nInstallation Guide—information about installing the camera and SDK, the physical interface and mechanical

properties, troubleshooting and how to get help. This document is available as a PDF for download or as a

webpage included in the firmware release package.

nTechnical Reference—information about the features supported by the camera model with the current

firmware, including: image format control, acquisition control, sequencing, binning/decimation, and others. This

document is available as a PDF for download or as a webpage included in the firmware release package.

nFirmware—programming inserted into the programmable ROM of the camera that can be updated in-field. New

firmware packages are available for download and include both the firmware file and documentation.

These resources as well as knowledge base articles and application notes can be found on the Support page for the

product.

Forge Support Articles Forge Resources

1/18/2023

Teledyne FLIR Forge®Installation Guide 1

2 Handling Precautions and Camera Care

Warning! Do not open the camera housing. Doing so voids the

Hardware Warranty described in the Terms and Conditions on our

website.

Your Teledyne FLIR machine vision camera is a precisely manufactured device and should be handled with care. Here

are some tips on how to care for the device.

nAvoid electrostatic charging.

nWhen handling the camera unit, avoid touching the lenses. Fingerprints will affect the quality of the image

produced by the device.

nTo clean the lenses, use a standard camera lens cleaning kit or a clean dry cotton cloth. Do not apply excessive

force.

nExtended exposure to bright sunlight, rain, dusty environments, etc. may cause problems with the electronics

and the optics of the system.

nAvoid excessive shaking, dropping or any kind of mishandling of the device.

Cleaning the imaging surface of your camera

Related Knowledge Base Articles

1/18/2023

Teledyne FLIR Forge®Installation Guide 2

3 Forge 5GigE Installation

3.1 Preparing for Installation

What system configuration is recommended?

Recommended System Configuration:

nOS—Windowsor Linux (32- or 64-bit)

nCPU— Intel i7 or greater

nRAM—8 GB dual channel

nPorts—GigE network adapter with 5G Full Duplex support

nSoftware—Microsoft Visual Studio 2015 (to run and compile example code)

Do you have all the parts you need?

To install your camera you need the following components:

nEthernet cable (see Interface Cables)

nPowered Ethernet switch or Ethernet power injector (if using PoE)

nGPIOcable (see General Purpose Input/Output (GPIO))

nLens (see Lens Mounting )

nTripod adapter (optional) (see Mounting your Forge 5GigE)

nInterface card (see Interface Card)

Teledyne FLIR sells a number of the additional parts required for installation. To purchase, visit the Accessories page.

Have you visited the Teledyne FLIR website?

A downloads account is required to download software and firmware.

1. Go to www.flir.com/account.

2. Enter your email address and click Continue.

3. Complete the Create an account form and click Continue.

4. You will receive an email with a link to activate your account.

5. Once activated, you can login using the credentials you've created.

The Forge resources page has many links to help you operate your camera effectively, including:

nSpinnaker®SDKsoftware, including drivers (login required)

nFirmware updates and release notes (login required)

nDimensional drawings and CADmodels

nDocumentation

1/18/2023

Teledyne FLIR Forge®Installation Guide 3

3 Forge 5GigE Installation

3.2 Installing your Interface Card and Software

1. Install your Interface Card

Ensure the card is installed per the manufacturer's instructions.

Connect the internal IDE or SATApower connector on the card to the computer power supply.

Alternatively, use your PC's built-in host controller, if equipped.

Open the Windows Device Manager. Ensure the card is properly installed. Ethernet cards appear under Network

Adapters. An exclamation point (!) next to the card indicates the driver has not yet been installed.

Configure the network adapter to use 5G Full Duplex.

a. Update the driver to the latest to access the 5GFull Duplex option.

b. In Windows go to Control Panel\Network and Internet\Network Connections, right-click on your network

adapter and select Properties.

c. Click Configure.

d. On the Advanced tab, from the Property box select Speed &Duplex and from the Value drop-down select

5Gbps Full Duplex.

e. Click OK.

On the Advanced tab, if not already enabled, set the Jumbo Packet to 9014 Bytes.

2. Install the Spinnaker® Software

Note: For existing users who already have Spinnaker installed, we

recommend ensuring you have the latest version for optimal

performance of your camera. If you do not need to install

Spinnaker, use SpinView to install and enable drivers for your card.

Forge requires Spinnaker version 3.0 or later.

a. Go to the Spinnaker SDK page.

b. Click the Download button. You are prompted to login, if not already.

c. Select your operating system. Depending on your selection there may be other versions to select.

d. After download is complete, open the file to start the Spinnaker setup wizard.

e. Follow the steps in each setup dialog.

1/18/2023

Teledyne FLIR Forge®Installation Guide 4

3 Forge 5GigE Installation

3. Optimize the settings of your Ethernet card

a. In Start->All Programs-> Spinnaker SDK->SpinView, right click on the Network Adapter and select Adapter

Configuration. The Adapter Config Utility lists your network adapters and allows you to access the following:

nAdapter IP address

nSubnet mask

nDefault gateway

nReceive buffers

nTransmit buffers

nJumbo packets

Note: See How to Optimize GigENetwork Adapter Settings for more

information on configuring for best performance.

3.3 Installing your Forge 5GigE

1. Attach a Lens

Unscrew the dust cap from the lens holder to install a lens.

2. Connect the interface Card and Cable to the Camera

Plug the interface cable into the host controller card and the camera. The cable jack screws can be used for a secure

connection. If using PoE, connect a powered Ethernet switch or Ethernet power injector in between the card and the

camera.

When the camera is first connected, the operating system automatically installs the camera driver. Camera drivers are

available with the Spinnaker SDK installation.

3. Plug in the GPIO connector

GPIOis used for power, trigger, serial input output, and strobe.

4. Confirm Successful Installation

Run the SpinView application: Start->All Programs-> Spinnaker->SpinView

The SpinView application can be used to test the camera's image acquisition capabilities and make changes to the

camera's installation configuration.

5. Configure IPSettings if necessary

By default, a dynamic IPaddress is assigned to the camera according to the DHCP protocol. If DHCP addressing fails, a

link-local address is assigned. If necessary, in SpinView change the IPaddress of the camera to be on the same subnet

as the NIC.

3.4 Powering your Forge 5GigE

Power can be provided over the Ethernet interface (PoE). To use PoE, you must also have a powered Ethernet card, a

powered Ethernet switch, or an Ethernet power injector.

Power can also be provided externally through the GPIO interface: 12 V nominal (8 - 24 V). Power consumption is 7 W

maximum.

1/18/2023

Teledyne FLIR Forge®Installation Guide 5

3 Forge 5GigE Installation

If both power sources are connected the camera always uses external power over the GPIO connector.

The camera does not transmit images for the first 100 ms after power-up. The auto-exposure and auto-white balance

algorithms do not run while the camera is powered down. It may therefore take several images to get a satisfactory

image.

When the camera is power cycled (power disengaged then re- engaged), the camera reverts to its default factory

settings, or if applicable, a saved user set.

1/18/2023

Teledyne FLIR Forge®Installation Guide 6

Tabla de contenidos

Otros manuales de Cámara digital de Teledyne

Teledyne

Teledyne USB VISION BLACKFLY S Manual de usuario

Teledyne

Teledyne Princeton Instruments Nano-XF Guía del usuario

Teledyne

Teledyne DALSA Piranha 2 P2-2x-40 Series Manual de usuario

Teledyne

Teledyne Piranha4 Manual de usuario

Teledyne

Teledyne Piranha4 Manual de usuario

Teledyne

Teledyne Princeton Instruments Sophia-XO Guía del usuario

Teledyne

Teledyne DALSA Piranha PC-30-02K80-00-R Manual de usuario

Teledyne

Teledyne Genie Nano-10G Series Manual de usuario

Teledyne

Teledyne Piranha4 Manual de usuario

Teledyne

Teledyne QuantaPro CP-10-04M02-50-L Manual de usuario

Teledyne

Teledyne FLIR ONE Series Manual de usuario

Teledyne

Teledyne Princeton Instruments PICam 5.x Manual de operación y mantenimiento

Teledyne

Teledyne G3-GM10-M0641 Manual de usuario

Teledyne

Teledyne EV71YC4MNT4005-BA0 Manual de usuario

Teledyne

Teledyne Princeton Instruments Quad-RO Guía del usuario

Teledyne

Teledyne Lt Series Manual de usuario

Teledyne

Teledyne Linea CL LA-CM-08K08A Manual de usuario

Teledyne

Teledyne Piranha4 Manual de usuario

Teledyne

Teledyne Linea Color GigE LA-GC-02k05B Manual de usuario

Teledyne

Teledyne Princeton Instruments NIRvana Guía del usuario

Teledyne

Teledyne PIXIS-XF Guía del usuario

Teledyne

Teledyne Falcon4 57M Manual de usuario

Teledyne

Teledyne ProEM Series Guía del usuario

Teledyne

Teledyne FLIR A50 Series Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
