Operator’s

Manual

PP0

08 Passive Probe

Unauthorized duplication of Teledyne LeCroy documentation materials is

strictly prohibited. Customers are permitted to duplicate and distribute

Teledyne LeCroy documentation for internal educational purposes.

Teledyne LeCroy is a registered trademark of Teledyne LeCroy, Inc. Windows

is a registered trademark of Microsoft Corporation. Other product or brand

names are trademarks or requested trademarks of their respective holders.

Information in this publication supersedes all earlier versions. Specifications

are subject to change without notice.

Warranty

Teledyne LeCroy warrants this oscilloscope accessory for normal use and

operation within specification for a period of one year from the date of shipment.

Spare parts, replacement parts and repairs are warranted for 90 days.

In exercising its warranty, Teledyne LeCroy, at its option, will either repair or

replace any assembly returned within its warranty period to the Customer

Service Department or an authorized service center. However, this will be done

only if the product is determined by Teledyne LeCroy’s examination to be

defective due to workmanship or materials, and the defect is not caused by

misuse, neglect, accident, abnormal conditions of operation, or damage resulting

from attempted repair or modifications by a non-authorized service facility.

The customer will be responsible for the transportation and insurance charges

for the return of products to the service facility. Teledyne LeCroy will return all

products under warranty with transportation charges prepaid.

This warranty replaces all other warranties, expressed or implied, including but

not limited to any implied warranty of merchantability, fitness or adequacy for

any particular purposes or use. Teledyne LeCroy shall not be liable for any

special, incidental, or consequential damages, whether in contract or otherwise.

928596-00 Rev A

July, 2017

Operator’s Manual

Safety Instructions

Follow generally accepted safety procedures in addition to the precautions

specified in this section. The overall safety of any system incorporating this

accessory is the responsibility of the assembler of the system.

Symbols

These terms and symbols may appear on the probe body or in this manual to

alert you to important safety considerations.

High Voltage WARNING, risk of electric shock or burn.

CAUTION of potential damage to equipment, or WARNING of

potential injury. Attend to the accompanying information to protect

against personal injury or damage. Do not proceed until conditions

are fully understood and met.

DOUBLE INSULATION

PROTECTIVE (EARTH) TERMINAL

Precautions

To avoid personal injury or damage to property, review and comply with the

following safety precautions. Use product only as specified.

Connect only to grounded instruments. Use only with compatible Teledyne

LeCroy oscilloscopes that have their BNC input connected to an earth

ground. Do not connect the probe reference lead to any point which is at a

potential other than earth ground.

Connect and disconnect properly. Connect probe to the oscilloscope before

connecting the probe to the test circuit. Disconnect the probe input and

reference lead from the test circuit before disconnecting the probe from the

oscilloscope. To avoid injury or death due to electric shock, do not connect or

disconnect probes or probe accessories while they are connected to a

voltage source.

PP008 Passive Probe

Do not overload. To avoid electric shock or fire, do not apply any potential to

the probe leads that exceeds the maximum rating of the probe.

Comply with voltage derating curve. When measuring higher frequency

signals, comply with the Voltage vs. Frequency Derating Curve.

Observe all terminal ratings. To avoid electric shock or fire, observe all

markings on the oscilloscope before connecting. Consult the respective

oscilloscope product manual for further ratings information.

Do not remove probe casing. Removing the probe’s case or touching exposed

connections may result in electric shock.

Use only within operational environment listed. Use indoors only. Do not use

in wet or explosive atmospheres. Keep product surfaces clean and dry.

Use only accessories compatible with the probe.

Handle with care. The probe tip is extremely sharp and may puncture skin or

cause other bodily injury if not handled properly.

Keep fingers behind the finger guard of probe body and accessories.

Do not operate with suspected failures. Before each use, inspect the probe

and accessories for any potential damage such as tears or other defects in

the probe body, cable jacket, accessories, etc. If any part is damaged, cease

operation immediately and sequester the probe from inadvertent use.

Operator’s Manual

Introduction

The PP008 is a miniature high impedance passive probe designed for use

with ≤ 600 MHz Teledyne LeCroy oscilloscopes. Its high input resistance and

low capacitance make it ideal for general purpose probing of signals with

frequency content from DC through several hundred MHz.

Keep fingers behind the probe’s finger guard during use.

Rated for indoor use only. Do not operate where conductive pollutants

may be present.

Maximum input voltage derates when frequency response is

approximately 30 kHz or higher. See voltage derating curve on p.4.

Specifications

Electrical Characteristics

Attenuation ÷10 ±1%

Input Resistance 10 MΩ±1%

Input Capacitance 9.5 pF

Input Impedance (see plot on p.5)

Compensation Range 10 – 20 pF

Bandwidth 500 MHz (-3 dB)

Electrical Ratings*

Max. Input Voltage Circuits not directly connected to Mains, 400 Vrms,

1250 V transient overvoltage

CAT II, 300 Vrms

Pollution Degree 2

* See Certifications for an explanation of rating categories.

PP008 Passive Probe

Operating Environment

Temperature, Operating 0oto 50oC

Temperature, Storage -40oto 71oC

Altitude, Operating Up to 2000 m (6560 ft)

Humidity, Operating 5% to 85% RH to 30° C

5% to 65% RH 30° C to 40° C

5% to 45% RH above 40° C

General Characteristics

Cable Length 1.3 m (4.3 ft)

Weight (probe only) 46 g

Max. VIN vs. Frequency

Frequency (Hz)

100 K 1 M 100 M10 M

VIN (Vrms)

150

250

350

400

300

200

100

Operator’s Manual

Typical Input Impedance

Connectivity Accessories

Teledyne LeCroy provides over 30 individual accessories for the PP008

probe, which enable reliable connections to any physical configuration. In

addition to those provided with the standard probe, several optional varieties

are available either individually, or grouped in sets related to specific

application needs.

The PK007 series of connectivity accessories is compatible with any

Teledyne LeCroy 2.5 mm PP008 series probe. Accessories are shown with

the Teledyne LeCroy part number followed by the description.

PK701 Basic Adapter Kit replaces the common standard accessories with Qty. 2

each of 1, 2, 4, 5 and 14, plus Qty. 1 adjustment tool (3).

PK702 Advanced Adapter Kit contains a large assortment of accessories: Qty. 1

each of 1, 2, 3, 5, 7, 8, 9, 10, 11, 13, 14, 15, 18, 21, 25, 29, 32; Qty. 2 each of 4,12, 22,

23, 24; and Qty. 5 of PCB adapter 16.

PK703 SMD Adapter Kit contains an assortment useful for attaching to surface

mounted ICs and components: Qty. 1each of 14, 17, 18, 22, 23, 25, 28, 29 and 32,

and Qty. 2 each of 5, 6, 7, 8, 9, 10, 11, 13 and 15.

PK704 Micro Clip Kit adapts the probe for use with 0.5 mm IC lead clips. It

contains Qty. 1 each of 16,17, and 18, and Qty. 2 each of micro-clips 22 and 23.

ZIN (Ω)

100 k

10 M

1 M

10 k

1 k

100

Frequency (Hz)

1 k 1 M 100 M

PP008 Passive Probe

Standard Accessories

(1)

(2)

(3)

PK007-001

Sprung Hook

PK007-002

Standard Ground Lead

PK007-003

Adjustment Tool

(4, 5)

(6)

(7, 8, 9, 10, 11)

PK007-004

Rigid Tip, 0.5mm

PK007-005

Spring Tip, 0.5 mm

PK007-007

Insulating Cap

PK007-008 IC Cap 0.5 mm pitch (green)

PK007

-009 IC Cap 0.65 mm pitch (blue)

PK007

-010 IC Cap 0.8 mm pitch (gray)

PK007

-011 IC Cap 1.0 mm pitch (brown)

PK007

-012 IC Cap 1.27 mm pitch (black)

(12)

(13)

(14)

PK007-006

Color Coding Rings (set)

PK007-013

Ground Blade

PK007-016

Ground Spring

(15)

(16)

PK007-014

Copper Pad

PK007-015

PCB Adapter

Operator’s Manual

Optional Accessories

INPUT ADAPTERS AND CLIPS

(17)

(18)

(19)

(20)

PK007-017

Single Lead Adapter

PK007-018

Dual Lead Adapter

PK007-022

Adapter, 2 mm plug

PK007-023

Adapter, 4 mm plug

(21)

(22)

(23)

PK007-019

Pico Hook™

PK007-020

Micro Clip, Long

PK007-021

Micro Clip, Short

(24)

PK007-031

BNC Adapter

(For low voltage use only

≤42 V pk AC + DC)

PP008 Passive Probe

GROUND LEADS

(25)

(26)

PK007-024

Probe Tip Ground Lead w 0.8 mm Socket

PK007-025

Probe Tip Ground Lead with Alligator

Clip

(28)

(29)

(30)

PK007-026

Ground Lead with mini clip

PK007-027

Ground Lead, 8 mm socket

PK007-028

Ground Lead, 2 mm plug

(31)

(32)

PK007-029

Ground Lead, 4 mm plug

PK007-030

High Frequency Compensated

Ground Lead

*The PK007-030 High Frequency compenated ground lead allows operation with long

ground lead wiith minimum signal distortion.
