Telco Systems EdgeGate483S Manual de usuario
EdgeGate483S
(GW-483S)
Installation Guide
MN100167 Rev. B
GW-483S Installation Guide Rev. B
The information in this document is subject to change without notice and describes only the
product defined in the introduction of this documentation. This document is intended for the use of
Telco Systems' customers only for the purposes of the agreement under which the document is
submitted, and no part of it may be reproduced or transmitted in any form or means without the
prior written permission of Telco Systems. The document has been prepared to be used by
professional and properly trained personnel, and the customer assumes full responsibility when
using it. Telco Systems welcomes customer comments as part of the process of continuous
development and improvement of the documentation.
If the Release Notes that are shipped with your device contain information that conflicts with the
information in the user guide or supplements it, follow the Release Notes.
The information or statements given in this document concerning the suitability, capacity, or
performance of the mentioned hardware or software products cannot be considered binding but
shall be defined in the agreement made between Telco Systems and the customer. However, Telco
Systems has made all reasonable efforts to ensure that the instructions contained in the document
are adequate and free of material errors and omissions. Telco Systems will, if necessary, explain
issues which may not be covered by the document.
Telco Systems' liability for any errors in the document is limited to the documentary correction of
errors. TELCO SYSTEMS WILL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS IN
THIS DOCUMENT OR FOR ANY DAMAGES, INCIDENTAL OR CONSEQUENTIAL
(INCLUDING MONETARY LOSSES), that might arise from the use of this document or the
information in it.
This document and the product it describes are considered protected by copyright according to the
applicable laws.
Telco Systems logo is a registered trademark of Telco Systems, a BATM Company.
Other product names mentioned in this document may be trademarks of their respective
companies, and they are mentioned for identification purposes only.
Copyright © Telco Systems 2007. All rights reserved.
Safety Considerations 2
GW-483S Installation Guide Rev. B
Safety Considerations
Please read these safety considerations before you begin installation. The instructions in this guide
are for use by qualified personnel only. To avoid shock, do not perform any procedures other than
those contained in the instructions.
CAUTION
Changes or modifications made to this device that are not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
Safety Considerations 3
GW-483S Installation Guide Rev. B
Table of Contents
SAFETY CONSIDERATIONS...................................................................................................................... 3
TABLE OF FIGURES.................................................................................................................................... 5
ABOUT THIS DOCUMENT ......................................................................................................................... 6
WHO SHOULD USE THIS GUIDE.....................................................................................................................6
OBTAINING TECHNICAL ASSISTANCE............................................................................................................6
INTRODUCTION........................................................................................................................................... 7
PRODUCT HIGHLIGHTS ..................................................................................................................................7
PORTS............................................................................................................................................................7
POWERING OPTIONS......................................................................................................................................7
AVAILABLE GW-483S OPTIONS....................................................................................................................8
BEFORE YOU INSTALL...................................................................................................................................9
INSTALLING THE GW-483S..................................................................................................................... 12
INSTALLING THE CABINET...........................................................................................................................12
INSTALLING THE VOIP GATEWAY BOARD ENCLOSURE...............................................................................14
INSTALLING THE RF VIDEO BOARD (OPTIONAL).........................................................................................19
DIAGNOSTICS............................................................................................................................................. 23
LED FUNCTIONS .........................................................................................................................................23
POST INSTALLATION STATUS ......................................................................................................................23
DEBUG ........................................................................................................................................................23
APPENDIX A: CABLE PINOUTS .............................................................................................................25
SPECIFICATIONS....................................................................................................................................... 27
PHYSICAL SPECIFICATIONS .........................................................................................................................27
OPERATING CONDITIONS.............................................................................................................................27
SAFETY AND ELECTROMAGNETIC COMPATIBILITY .....................................................................................27
ACRONYMS................................................................................................................................................. 29
REVISION HISTORY.................................................................................................................................. 30
Safety Considerations 4
GW-483S Installation Guide Rev. B
Table of Figures
Figure 1: The VoIP Gateway Board....................................................................................10
Figure 2: A GW-483S System Cabinet – The Technician Access Area.............................11
Figure 3: A GW-483S System – Cable Management Area.................................................13
Figure 4: A GW-483S System – Telco Cable Management ...............................................14
Figure 5: The VoIP Gateway Board Enclosure – Top View...............................................15
Figure 6: Gateway Board Connectors .................................................................................16
Figure 7: A GW-483S System – Customer Cable Management.........................................17
Figure 8: A Terminal Bridge Assembly..............................................................................18
Figure 9: Special Hex Pin Tools..........................................................................................19
Figure 10: RF Video Board – Top View.............................................................................20
Figure 11: RF Video Board – Front View...........................................................................20
Figure 12: RF Board Cable Management............................................................................21
Figure 13: Console Cable....................................................................................................24
Table of Figures 5
GW-483S Installation Guide Rev. B
About This Document
Who Should Use This Guide
This guide is intended for network administrators who are proficient with network switching and
routing concepts. Installation, replacement and maintenance of the equipment described in this
guide may only be done by trained and qualified service personnel.
Obtaining Technical Assistance
Telco Systems provides technical assistance for customers and partners. Users can obtain technical
assistance by any of the following phone, fax and e-mail options:
Web Access: http://www.telco.com
BATM Advanced Communications – Main Support Center in Israel
Tel: +972-4-993-5630
Fax: +972-4-993-7926
Email: [email protected]
Telco Systems a BATM Company – for Americas
Tel: 1-800-227-0937 (U.S.), 1-781-255-2120 (Outside U.S.)
Fax: 781-255-2122
Email: [email protected]
BATM Germany - for Northern Europe
Tel: +49-241-463-4652
Fax: +49-241-463-5492
Email: [email protected]
BATM France – for Southern Europe
Tel: +33-15-671-2720
Fax: +33-14-377-1780
Telco Systems, a BATM Company Asia Pacific in Singapore
Tel: +65-6-725-9901
Fax: +65-6-725-9889
Email: [email protected]
Telco Systems, a BATM Company Asia Pacific in Japan
Tel: +81-3-5521-1705
Fax: +81-3-5510-9131
Email: [email protected]
About This Document 6
GW-483S Installation Guide Rev. B
Introduction
The EdgeGate483S is a multi-service customer premises equipment (CPE) device designed to
reduce the cost of delivering voice, video, and data services to homes, small office/home office
(SOHO), and small enterprise.
This guide provides installation instructions for the GW-483S family of EdgeGate483S systems.
The GW-483S is comprised of an indoors/outdoors cabinet whose main components are a VoIP
gateway board and an optional RF analog converter board.
Product Highlights
•FTTH/B active Ethernet CPE
•Voice (VoIP), video, data and home networking - all-in-one box
•Superior voice quality using various QoS mechanisms
•Supports both 100M and 1G networks in one product
•Wire speed performance
•Part of a complete end-to-end solution
•Enhanced mechanics and cable management
Ports
The GW-483S system provides the following ports:
•100BaseFx and 1GBaseX combo uplink ports (SFP)
•8x10/100BaseTX ports (RJ45 connectors)
•2xFXS Telephony Interfaces (RJ11 connectors)
Powering Options
The GW-483S system supports the following indoor/outdoor powering options:
•Indoor integrated UPS+PSU
•Indoor 110/220 power supply unit with no power backup.
•Outdoor integrated UPS+PSU
•Outdoor powering system including meter collar
Introduction 7
GW-483S Installation Guide Rev. B
Available GW-483S Options
The tables below describe the various system, board and power supply options:
System Models
Model Name Power Option Options
GW-483S-z
(z = software
option to be loaded
on the gateway:
S => SIP
M => MGCP)
Not included •100BaseFx and 1GBaseX uplink
•8 10/100BaseTX ports
•2 local phone lines
•Unpopulated SFP for 100M/1G
GW-483S-RF-z Not included •100BaseFx and 1GBaseX uplink
•8 10/100BaseTX ports
•2 local phone lines
•Unpopulated SFP for 100M/1G
•RF Analog Converter
Note: A variety of SM, MM and bi-directional LX, SX, ZX SFPs is available.
Accessories (need to be ordered separately)
Model Name Power Option Description
GW-power-15m Power cable to connect PSU+UPS to
EdgeGate. Length 15m (~50ft)
Outdoor power supply options
Model Name Power Option Options
GW-483S-O-M Outdoor powering system
including meter collar N/A
GW-483S-O-P Outdoor integrated UPS+PSU N/A
Indoor power supply Options
Model Name Power Option Options
GW-483S-I-P Indoor integrated UPS+PSU N/A
GW-483S-I-P-y Indoor 110/220 power supply
unit, no power backup.
Introduction 8
GW-483S Installation Guide Rev. B
Before You Install
Before you begin the installation:
1. Please review the packing list.
2. Familiarize yourself with the equipment and unit (see pictures below).
Packing List
The packing list depends on the ordered GW-483S model, but can include some or all of the
following items:
•GW-483S Cabinet
•A VoIP Gateway Board assembly with 2 position Terminal Bridge.
•Two 2-Screw Terminal Bridge assemblies.
•RF Video Converter unit (optional, as ordered)
•Power Supply kit. (optional, as ordered)
•Console cable.
Pictures and Drawings
The following figures depict different views of the GW-483S system.
Introduction 9
GW-483S Installation Guide Rev. B
8 LAN
Ports
2 Phone
Lines
Power,
Ready, and
Voice LED
Labels
F.O.
LNK/ACT
LED Label
Phone Line
Adapters
Telco Area
Lock Screw
Cable
Conduit
Cable
Conduit
Customer
Access
Screw
Bottom
Hinge
Top
Hinge
Actual
location of
LEDs
Reset
Button
Label
Actual
location of
Reset Button
Figure 1: The VoIP Gateway Board
NOTE
The Power, Ready, Voice and FO LNK/ACT LEDs and the Reset Button are
physically located to the left of the Phone 1/Phone 2 connectors, but their
callout labels have been moved to the right side of the module in order to
provide the user with better readability.
The top-to-bottom order of the LEDs & Reset Button corresponds to the
top-to-bottom order of their labels.
Introduction 10
