Tektronix MDO32 Instrucciones de instalación y mantenimiento
3 Series MDO
Mixed Domain Oscilloscope
Declassification and Security Instructions
*P077150100*
077-1501-00
3 Series MDO
Mixed Domain Oscilloscope
Declassification and Security Instructions
www.tek.com
077-1501-00
Warning
The servicing instructions are for use by qualified personnel only. To avoid
personal injury, do not perform any servicing unless you are qualified to do
so. Refer to all safety summaries prior to performing service.
Supports 3 Series MDO Firmware V1.0 and above
Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products
are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all
previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
■In North America, call 1-800-833-9200.
■Worldwide, visit www.tek.com to find contacts in your area.
Table of Contents
Preface ................................................................................................................................................. 3
Memory devices
Volatile memory devices ................................................................................................................ 1
Nonvolatile memory devices .......................................................................................................... 3
Media and data export devices ....................................................................................................... 4
Clear and sanitize procedures
Disable the USB device port .......................................................................................................... 7
Use the 3-SEC option to disable all I/O ports ................................................................................ 7
Disable the LAN port and clear the LAN Ethernet settings ........................................................... 8
Enable the USB device port ............................................................................................................ 8
Use the 3-SEC option to enable the I/O ports ................................................................................ 9
Enable the LAN port and set the LAN Ethernet settings ............................................................... 9
Built-in security features
When to use TekSecure ................................................................................................................ 11
Use TekSecure to erase memory contents .................................................................................... 12
Clear or sanitize a non-functional instrument
Acquisition board ......................................................................................................................... 13
USB flash drive ............................................................................................................................ 13
Charges ......................................................................................................................................... 13
3 Series MDO Declassification and Security Instructions i
Table of Contents
ii 3 Series MDO Declassification and Security Instructions
Preface
This document helps customers with data security concerns to sanitize or remove
memory devices from the Tektronix 3 Series MDO Mixed Domain
Oscilloscopes.
These products have data storage (memory) devices and data output devices.
These instructions tell how to clear or sanitize the memory devices and disable
the data output devices. The instructions also tell how to declassify an instrument
that is not functioning.
Instrument code and calibration settings reside in nonvolatile flash memory.
Instrument setups and reference waveforms may also be stored in flash memory
or on USB drives connected to the instrument.
If you have any questions, contact the Tektronix Technical Support Center at
www.tektronix.com/support.
Reference
The procedures in this document are written to meet the requirements specified
in:
■NISPOM, DoD 5220.22–M, Chapter 8
■SFO Process Manual for Certification & Accreditation of Classified Systems
under NISPOM
Products
The following Tektronix products are covered by this document:
■MDO32
■MDO34
Required documents
To perform the procedures in this document, you might need access to the
3 Series MDO manuals listed below. These manuals are available on the
Tektronix Web site at www.tektronix.com/downloads.
■3 Series MDO Service Manual (Tektronix part number, 077-1500-xx)
■3 Series MDO Technical Reference Manual (Tektronix part number,
077-1499-xx)
Terms used in this document
The following terms may be used in this document:
■Clear. This removes data on media/memory before reusing it in a secured
area. All reusable memory is cleared to deny access to previously stored
information by standard means of access.
■Erase. This is equivalent to clear.
■Instrument Declassification. A term that refers to procedures that must be
undertaken before an instrument can be removed from a secure environment.
Declassification procedures include memory sanitization and memory
removal, and sometimes both.
■Media storage/data export device. Any of several devices that can be used
to store or export data from the instrument, such as a USB port.
■Nonvolatile memory. Data is retained when the instrument is powered off.
■Power off. Some instruments have a “Standby” mode, in which power is still
supplied to the instrument. For the purpose of clearing data, putting the
instrument in Standby mode does not qualify as powering off. For these
products, you will need to either press a rear-panel OFF switch or remove the
power source from the instrument.
■Remove. This is a physical means to clear the data by removing the memory
device from the instrument. Instructions are available in the product Service
Manual.
■Sanitize. This eradicates the data from media/memory so that the data cannot
be recovered by other means or technology. This is typically used when the
device will be moved (temporarily or permanently) from a secured area to a
non-secured area.
■Scrub. This is equivalent to sanitize.
■User Accessible. User is able to directly retrieve the memory device
contents.
■User-modifiable. User can write to the memory device during normal
instrument operation, using the instrument interface or remote control.
■Volatile memory. Data is lost when the instrument is powered off.
Device terms
The following terms are used with the memory devices in this document:
■User data. Describes the type of information stored in the device. Refers to
waveforms or other measurement data representing signals connected to the
instrument by users.
■User settings. Describes the type of information stored in the device. Refers
to instrument settings that can be changed by the user.
■Both. Describes the type of information stored in the device. It means that
both user data and user settings are stored in the device
■None. Describes the type of information stored in the device. It means that
neither user data nor user settings are stored in the device
■Directly. Describes how data is modified. It means that the user can modify
the data.
■Indirectly. Describes how data is modified. It means that the instrument
system resources modify the data and that the user cannot modify the data.
