Release notes
This document describes the key features and known limitations of software
version 1.5 of the Tektronix WFM2200 SD/HD/3G SDI Waveform Monitor and
Generator.
Some of these notes apply only to instruments with specific options installed. A
list of available instrument options is available at www.tektronix.com.
Software version 1.5
New features The following new features were introduced with software version 1.5:
Genlock. The test signals that are generated from the SDI output now have the
ability to Genlock to the External Reference Input. The status of the Genlock
function is shown in the Status Bar and in the Generator Status display.
Moving circle. You can add a moving circle to the output signal, which allows
you to easily identify whether the test signal is active “live” or still, and helps
determine problems within the signal path that has been caused by equipment
freezing on the last frame. This can be useful for troubleshooting a signal path or
piece of equipment without the need to carry an additional generator.
WFM2200 Release Notes 1
Release notes
Power button. The operation of the Power button for powering off the instrument
has changed. The button functions as follows:
There are two methods for powering off the instrument:
Press the Power button on the front panel. This opens the Power off or
Standby dialog box where you can use the arrows buttons to select from the
following actions:
NOTE. When you press the Power button, you must make a selection in the Power
off or Standby dialog box within 5 seconds or the instrument will automatically
power off.
Power off. This is the default selection. You can press the SEL button to
immediately power off the instrument or you can wait 5 seconds for the
instrument to automatically power off.
Standby. Use the arrow buttons to select Standby to put the instrument in
Standby mode. In Standby mode, the instrument consumes less power
than when it is turned on and also takes less time to turn back on than
when the instrument is turned completely off.
Cancel. Use the arrow buttons to select Cancel if you want to cancel the
power-off operation.
Press and hold the Power button for 5 seconds and then release the button to
immediately power off the instrument.
NOTE. To remove power completely from the instrument, disconnect the AC
adapter from the power connector and remove any installed battery pack.
Known problem fixed The following known problem was fixed with this release.
Audio outputs. When the instrument was powered on or came out of Standby
mode with the audio input configured for embedded audio, the channel 1
audio signal was assigned to both the left and right outputs on the speaker and
headphone.
2WFM2200 Release Notes
Release notes
Key features and benefits
The WFM2200 waveform monitor has the following features:
Battery-operated
portability
Portable, handheld form factor is ideal for field production setup and
troubleshooting
Operates using the supplied AC adapter or the supplied Lithium-Ion, internal
and replaceable battery pack
Optional accessories include the WFM220BC External Battery Charger,
the WFM200BA Rechargeable Battery Pack, and the WFM200FSC Soft
Carrying Case
Two SDI inputs with
multiformat and
multistandard support
Comes standard with auto-detection of HD/SD-SDI and multiple Dual Link
video formats (including RGB and XYZ color space support)
Can be upgraded to include 3G-SDI (Level A and Level B) format support
with the purchase of an option key (Option 3G required)
Video and audio signal
generation
Generates SD/HD/3G SDI color bar and pathological signals for
troubleshooting signal paths and equipment (Option 3G is required for
3G-SDI test signal generation)
Generates AES audio test tones for embedded and AES output
Audio monitoring Monitors up to 16 channels of embedded AES/EBU audio
Comes standard with an independent AES input and output for audio facility
testing
Comes standard with simultaneous monitoring support including a
Multichannel Surround Sound 1display and flexible Lissajous display
1Audio Surround Sound Display licensed from Radio Technische Werksütten GmbH and Co. KG (RTW).
Color gamut compliance
monitoring
Comes standard with the Tektronix-patented Diamond and Arrowhead
displays for color gamut compliance monitoring
WFM2200 Release Notes 3
Release notes
Comprehensive data
monitoring helps to quickly
resolve difficult content
quality and reliability
issues (Option DATA)
Provides simultaneous CEA708/608 Closed Caption monitoring; Teletext
and OP47 subtitle monitoring
Detects and decodes ANC data including AFD, WSS, Video Index, TSID,
V-Chip, Broadcast Flag/CGMS-A, VITC, LTC, and ANC TC
Includes ARIB STD-B35/B37/B39, TR-B22, and TR-B23 support
Includes the ANC Data Inspector and SDI Data Analysis display to help
troubleshoot ANC data and SDI data problems
Variety of monitoring
displays
Includes the Tektronix-patented Timing and Lightning displays to make
facility and interchannel timing easy
Includes a waveform display of the external reference (Black Burst or
Tri-Level Sync) and LTC signals which allows for a quick diagnosis of
potential issues in the video sync and timing distribution system
Includes extensive alarms, status reporting, and error logging for 10,000
events to simplify error correction tasks
Includes voltage and timing cursors to allow for precise signal measurements
Includes user definable Safe Area graticules and an AFD graticule to facilitate
editing and format conversion tasks
Unmatched display
versatility
Includes a flexible quad-tile display to provide four concurrent views
of a monitored signal (with a maximum of two trace displays at once);
also provides the flexibility to configure each of the four display tiles
independently, enabling you to increase productivity
Includes a full screen mode that maximizes display size for precise
adjustments
Displays a thumbnail picture for content verification
Unmatched usability Includes 32 instrument presets for quick recall of commonly used
configurations tailored to colorists, editors, or operators
Includes a USB port for easy transfer of presets, screen shots, and error logs
Includes an internal speaker and headphone port for easy monitoring of audio
channels
Provides an intuitive menu structure and context sensitive help
Includes a high-brightness display with crisp, high-resolution LED backlight,
ideal for indoor and outdoor usage
4WFM2200 Release Notes
Release notes
Includes SNMP and Ethernet remote interface capabilities to facilitate
centralized monitoring and control
The super lightweight and low power consumption design supports portable,
battery powered applications
General limitations
This release has the following general limitations. Topics are listed in alphabetical
order.
Audio outputs High headphone volume levels can cause clipping with high audio level
programs. To prevent possible ear damage, it is recommended to lower the
volume before connecting headphones to the instrument.
Test tone generation from AES output will be muted for a moment
when the input video channel is switched or input video signal is
connected/disconnected.
Genlock If the reference frequency error is greater than 80 ppm, then the lock indicator
may falsely indicate that the instrument is locked. In this case, the SDI OUT
can be temporarily connected to an SDI input and the actual lock condition
can be viewed on the Timing display using external reference.
USB Always press the MAIN button and select USB Status > Unmount before you
remove the USB memory device from the USB port. You risk permanent loss
of any files saved on the USB device if you do not use the “Unmount” feature.
It is recommended that you use a well known brand to prevent a slow
instrument boot-up and/or response.
Web browser We recommend using Java Runtime Engine (JRE) version 1.6 or above.
WFM2200 Release Notes 5
