Tekmar 561 Manual de usuario
User Manual
WiFi Thermostat 561
2 of 12
Current time
Current temperature
Equipment operation
(Heat On)
Change operating mode
Touch or to
adjust temperature
Hold overrides the
programmed schedule
until the time shown
'Save to schedule' applies
the new temperature to the
current schedule event.
Go to settings
Swipe to view:
• Weather
• Outdoor temperature
• Floor temperature
• Heat To setting
Go to schedule
After 60 seconds of inactivity, the thermostat home screen displays only the time and
the temperature.
Save
Cancel
Mode
Off
Heat
Temperature Adjustment
Hold Until 5:00 PM
Save to Schedule
70
Heat To
MENU SELECTION
AWAY SCHEDULE
DISPLAY TIME
WIFI SETUP
WIFI: Connected
Home Screen
3 of 12
Set heating temperature
Select skip if you don't want
a temperature change.
Set schedule start time
Operates normally
Operates using the Away
temperature selected in
the Setup menu
Use the Away setting to
save energy when the
building is unoccupied
•
The Away temperature can
be adjusted in the Setup /
Temps menu.
• Selecting the Away
setting on a thermostat or
the mobile app will affect
all devices linked to that
location through the app.
Save Info
Home / Away
At Home
Away
Heating temperature
Go to the next group
of program days.
Current group of
program days.
Early Start anticipates the
time required to heat
a room
and starts early.
Set to On to follow the
schedule. Set to Off to use
the same temperature all
of the time.
Creates a new schedule.
New
Schedule
Early Start
On
Schedule
On
Wake 6:00 AM 70°
Leave 8:00 AM 65°
Return 6:00 PM 70°
Sleep 10:00 PM 65°
Schedule
Mon Tue Wed Thu Fri
On
Skip
Wake
Schedule Setup
Mon Tue Wed Thu Fri
6:00 AM
Heat to 70°
User Settings
Away
--------------------------------------------------------------- ---------------------------------------------------------------
Schedule
------------------------------------------------------------ ------------------------------------------------------------
4 of 12
Select °F or °C
Brightness when
touching the display
Choose the
background color
Select English, French
or Spanish
Brightness after 60 second
timeout of no use
Energy use. See below.
DISPLAY 1/2
Temperature Units: °F
Brightness - Active: 80%
Theme: Light
Energy Use: Monthly
Brightness - Inactive: 50%
Language: English
Daily Usage
Monthly
Usage
Today 0 hrs
Yesterday 0 hrs
Tue 0 hrs
Mon 0 hrs
Sun 0 hrs
Sat 0 hrs
Fri 0 hrs
View each day's run
time for heating.
Toggle between Daily
and Monthly Usage.
Energy Use
10 second count down
to allow the screen
to be cleaned with a
moist cloth. Select if the time is
shown when inactive
Select if the outdoor
temperature is shown
when inactive
DISPLAY OPTIONS 2/2
Clean Screen: Off
Inactive Time Display: On
Inactive Outdoor Display: Off
Display
------------------------------------------------------------- -------------------------------------------------------------
5 of 12
When connected to the Internet, the time can be set
automatically.
The time and date can be manually set by highlighting
a field and then using the or buttons.
Incorrectly setting the time and date manually may prevent the thermostat from
communicating to the mobile app. Automatic time source is recommended when using
an Internet connection.
TIME & DATE
1 30 PM
Aug 25 2016
OPTIONS
Time options are:
• 12 hour or 24 hour time format
• Automatic or manual time setting
• Time zone
• Daylight savings time
Time
---------------------------------------------------------------- ----------------------------------------------------------------
6 of 12
The thermostat includes a step by step tutorial to setup the WiFi connection.
Step 1
Agree to Terms of Use
Step 2
Turn on WiFi
Step 3
Enter wireless network
name. It must support
WPA2 security encryption.
Step 4
Enter WiFi password.
Step 6
Select if the time is set
automatically from the
Internet or manually.
Step 5
Enter ZIP or postal code.
This determines your location
for weather information.
Tutorial
DISAGREE AGREE
Before first using wi-fi features
of this product, you must accept
the Terms of Use available at
https://www.watts.com/terms-
of-use
by pressing AGREE below.
If you do not accept these terms.
this product can still be used
without wi-fi features.
WIFI
NEXT
Off
On
Time Source
NEXT
Automatic
Manual
NETWORK SSID
CONNECT
Select a network
from the list:
Your House
A C EB D F
M O QN P R
Y A/1ZShft Del
G I KH J L
S U WT V X
Enter Password
CONNECT
135246
: ( $; ) &
' A/1\Shft Del
7 9 -8 0 /
@ . ?" , !
ZIP/Postal
OK
WiFi
---------------------------------------------------------------- ----------------------------------------------------------------
Before using the WiFi features of this product, you must accept the Terms of Use, as
amended from time to time and available at Watts.com/terms-of-use. If you do not accept
these terms, this product can still be used without WiFi features.
7 of 12
To view and adjust the WiFi Thermostat using a mobile phone or tablet, download the
Watts Home mobile app from the Apple® iTunes® Store or from the Google Play® Store.
Step 1
Create a new account. Then
login using your username and
password.
Step 4
Press the Location
name and Add New
Device.
Step 3
Swipe left (Apple) or
long hold (Android)
to edit the Location
name.
Step 2
On the thermostat, go
to WiFi menu and press
Register Device.
Step 5
Enter the 8 digit code from
the thermostat into the
mobile app. Then enter the
thermostat's room name.
The thermostat is
now listed on the
Devices page.
Add Thermostat to App
---------------------------------------------- ----------------------------------------------
REGISTRATION
To finish registering your
thermostat, enter the code
displayed below in the
Watts Home mobile app.
The registration code will
expire in 30:00 minutes.
12345678
Watts®Home App
Sign In
Create Account
8 of 12
Using the App
------------------------------------------------------- -------------------------------------------------------
Toggle to
Away to
save energy
when you
are away
for a day or
more
Change
temperature
setting
Limits
Mode
Current
temperature
Press for settings Swipe left or long hold to
edit or remove location
Swipe left or long hold to
edit or remove device
Edit schedule
Energy use
Refresh
Thermostat settings
Settings Locations
Devices Thermostat
9 of 12
Change the notification
and unit settings for your
account
Invite other users to
access all the devices at
a location
Update your user name
Settings
Invite Users
My Account
user name
1555 555 5555
10 of 12
Page left intentionally blank
