INTRODUCTION TO MATRIXTM AND CL230
The MATRIXTM and Centerline 230BP are combined Guidance and Automatic Boom Section Control
(ABSC) devices that features control of up to 15 boom sections. The MATRIXTM or the Centerline
230BP connects in parallel to the existing wiring loom to the section valves.
Principle of Operation
The MATRIXTM or Centerline 230BP control the sections valves according to the GPS position and
the GPS guidance makes it possible to avoid overlaps or skips.
The MATRIXTM or Centerline 230BP controls the section valves in automatic mode, and the section
switches should be set to off unless the operator wants to override the auto mode and thus force
spraying.
The MATRIXTM or Centerline 230BP monitors the section switches that controls the valves in manual
mode. The Master switch can be used both in automatic mode as well as in manual mode.
This installation manual covers installation of MATRIXTM or CenterLine 230BP with Berthoud
TELEVOLUX Switcbox. We have endeavoured to deliver a fault free product. To ensure optimal
use of the equipment, we ask you to pay great attention when reading this manual. Regarding
responsibility for use of the product, we refer to our sales and delivery terms - especially paragraph
7, which follows:
Product usage.
7.1 Any use of the product is at the sole risk of the buyer. The buyer
is therefore not entitled to any form for compensation caused by, for
example, any of the following:
• Disturbance to/from any electronic services or products that do
not confirm to the standards for CE marking,
• Missing or poor signal coverage or a succession hereof from
external transmitters/receivers, used by the buyer,
• Functional faults, which apply to or from a PC-program or PC-
equipment, not delivered by the seller.
• Faults that may arise from the buyers negligence to react to
warnings and fault messages from the product, or which can be
traced to negligence and/or absent constant control of the work
carried out in comparison to the planned job.
7.2 When implementing any new equipment the buyer must take great care
and pay attention. Any doubts as to correct operation/use should result
in contacting TeeJet Technologies.
