Tecnosicurezza Pulse Manual de usuario

Pulse

User Instructions

2 of 12 IU_Pulse_01_eng

User instructions

Pulse

Company

Founded in 1983 with the aim of providing a complete range of professional products,

Tecnosicurezza is now a consolidated reality in the field of locks and security systems for safes.

The experience gained in over 35 years of activity in the security sector has allowed the

designing and manufacturing of high technology and reliability systems, which continue to

receive the approval of an increasingly demanding clientele.

TECNOSICUREZZA is present directly on the Italian, Spanish and US markets and, through a

extensive distribution network, in many EU and extra-EU countries.

TECNOSICUREZZA is aimed at national and international customers of primary importance, such

as banks, safe manufacturers, cash in transit companies, mass market retailers and post offices.

Today TECNOSICUREZZA is a leading company focused on the customers’ needs and

constantly in step with technology.

IU_Pulse_01_eng 3 of 12

User instructions

Pulse

Table of contents

COMPANY 2

TABLE OF CONTENTS 3

IMPORTANT NOTES! 4

GENERAL INFORMATION 5

OVERVIEW FUNCTIONS 6

LOCK OPENING 7

CHANGE CODE 7

INSTALL/DISABLE/DELETE USERS 8

INSTALL USERS (FUNCTION #1) 8

DISABLE/ENABLE USERS (FUNCTION #2) 8

DELETE USERS (FUNCTION #3) 8

TEST MODE 8

USERS STATUS 9

AUDIT/CONFIGURATION DOWNLOAD 9

TIME DELAY AND OPEN WINDOW 9

LOCK RESET 10

CORRECT DISPOSAL OF THIS PRODUCT: 12

CONTACTS 12

Before operating the lock,

please read this manual thoroughly,

and retain it for future reference.

4 of 12 IU_Pulse_01_eng

User instructions

Pulse

Important notes!

Before installing this product, please read carefully the installation and operating

instructions.

Locks have been designed to correctly operate in a temperature range from -5°C (23°F)

to + 50°C (122°F) and in an environment with non-condensing humidity between 25%

and 90%.

The lock must not be oiled/lubricated/greased.

If installed in normal domestic or office environments, the locks do not require particular

maintenance; in any case, after 10,000 opening/locking cycles, it is recommended to run

a test that verifies the correct and complete operation of the product.

Use only DURACELL™ 9 Volt Alkaline batteries, or battery holders with DURACELL™ 1.5

Volt Alkaline batteries. Alternatively, it is possible to use a 12VDC - 1A power adapter

(p.n. N1212) with relative power supply interface (p.n. T6005/W or p.n. T6005).

A series of multiple beeps indicate a low battery level which need immediate replacing.

It is strongly recommended to change the default codes before usage and to keep the

new codes safe.

Do not use codes easily guessed such as 123456, birth dates or based on personal

information.

After changing a code, perform several opening/closing tests before closing the door.

Should the lock label be removed, warranty is void.

IU_Pulse_01_eng 5 of 12

User instructions

Pulse

General information

Using the keypad

To start a time delay counting (if programmed), enter an opening

combination: LED flashes every 2s, indicating the counting.

Press any key to stop the time delay counting.

The opening window is indicated by a flashing and a beep alternating at

1s intervals.

The led remains on if the system is in programming mode.

2 short beeps are produced if an operation/code is correct.

A long beep is produced if an operation/code is incorrect.

If an incorrect operation is performed, wait 5 seconds until the led switches off and try again.

Pre-setup & Configurations

In pre-setup mode, press 1 to open the lock and activate the silent alarm. It’s possible to open

also by inputing 555555 code, in this case the silent alarm is activated by increasing the last

digit by one number of the code (555556).

In pre-setup mode, programming can be performed through a Dallas key or by selecting one of

the following 4 preloaded configurations:

No. configuration

Maximum number of users

Dual code

Note: this programming procedure is not valid for EM6050 locks.

Silent alarm option can be activated in pre-setup mode thanks to a setup Dallas key, or by simply

connecting an alarm interface to the lock and entering an opening code.

Select a keypad configuration (only in pre-setup status)

Hold press the 2 key for few seconds, enter the code 555555 and select the desired

configuration number.

At the end of the configuration only the Manager is installed, with code 123456.

If all users are blocked and only the manager is enabled, time delay and dual code (if

programmed) are not available.

6 of 12 IU_Pulse_01_eng

User instructions

Pulse

Users characteristics & default codes

Manager

123456 +

optional Dallas key

Main user : open, program and change its own code.

Standard users

XXXXXX +

optional Dallas key

Users from 2 to 8 : opens and change their own code.

Override users

XXXXXX +

optional Dallas key or Dallas key only

User #9 : opens without time delay and changes its own code (or Dallas).

This user only opens in dual mode with Manager and standard users.

Overview functions

Lock opening

After entering an opening code, it is possible to open the lock within 3 seconds. It is not

necessary with motorized locks: in this case, the motor retracts the bolt which remains in the

open position for 8 seconds before returning to the closed position. In the manual closing

version, the bolt can be closed by pressing any key

Penalty

Four consecutive wrong codes initiate a four minutes penalty time. During this period, the LED

flashes once every 10s. Each time a key is pressed, a long beep is produced and no operation is

allowed.

Dallas keys

During the installation (function #1), a Dallas key (model 1982) can be associated to a user by

simply placing it in the Dallas reader after entering the ID and related code. The user is then

identified by numeric code + Dallas key.

Power supply

Lock can be powered with:

an ALKALINE 9V battery located in the battery compartement below the keypad;

an internal battery box provided by Tecnosicurezza (6 ALKALINE 1.5 batteries);

A power adapter (ref. N1212) with power supply interface (ref. T6005/W or T6005) both

provided by Tecnosicurezza.

Low battery warning

A series of beeps while opening indicates a low battery which should be replacing immediately.

Silent alarm

With this function enabled, if user enters an opening code an then increase the last digit by one

number (ex. 030304 instead of 030303): the lock opens and simultaneously the output of the

alarm interface is activated.

Audit

The lock is able to save the last 100 operations with user and operations description.

IU_Pulse_01_eng 7 of 12

User instructions

Pulse

Function access

Standard mode:

Hold press the key corresponding to the function for two seconds. Led

remains on.

Dual code:

Input a valid code that’s not the Manager code, hold press the key

corresponding to the function for two seconds. Led remains on.

Note: for the functions in which the Manager code is needed, it’s possible to access even by

inputing the Manager code and pressing and holding the last digit. Led remains on. Press the

key corresponding the desired function.

Lock opening

It is recommended to change the factory code before use and safely store the new code.

Manager & standard users:

Enter an opening code. The keypad beeps twice.

If programmed, the time delay counting begins.

At the end of time delay, the open window counting begins.

Enter a code during the opening window (2 codes in case of dual code

opening). The keypad beeps twice and the lock can be opened.

Override user:

Enter a opening code. Time delay counting begins.

Input the override user code (and the Dallas key if programmed) or the

override Dallas key (if only Dallas override user). The keypad beeps twice

and the lock can be opened.

Change code

It is recommended to always perform this operation with door open.

Press and hold until the double beep. The led remains on.

Enter the old code (and the Dallas key if programmed). The keypad beeps

twice.

Enter the new code (and the Dallas key if programmed). The keypad

beeps twice.

Confirm the new code (and the Dallas key if programmed). The keypad

beeps twice and led switches off.

Note: it’s possible to associate a new Dallas key and keep the old code. Perform a change

code operation keeping the code unchanged but placing a new dallas key.

8 of 12 IU_Pulse_01_eng

User instructions

Pulse

Install/Disable/Delete users

Install users (function #1)

Hold press util the double beep. Led remains on.

Enter the Manager code (and the Dallas key if programmed). The keypad

beeps twice.

Enter the number of the user to be installed. The keypad beeps twice.

Enter the code (and the Dallas key if needed) of the new user. The

keypad beeps twice.

Confirm the code (and the Dallas key if programmed) of the new user.

The keypad beeps twice and the led switches off.

Note: it’s only possible to install the override user during the open window counting.

Disable/Enable users (function #2)

Hold press util the double beep. Led remains on.

Enter the Manager code (and the Dallas key if programmed). The keypad

beeps twice. All the users (but Manager) are disabled/enabled.

Delete users (function #3)

Hold press util the double beep. Led remains on.

Enter the Manager code (and the Dallas key if programmed). The keypad

beeps twice.

Enter the number of the user to be deleted. The keypad beeps twice and

led switches off.

Test mode

This function allows for verification that the system is operating correctly.

Hold press util the double beep. Led remains on.

Enter the following sequence of keys:

Any working button produces 2 short beeps.

A damaged button produces a long beep and the keypad switches off.

IU_Pulse_01_eng 9 of 12

User instructions

Pulse

Users status

Hold press util the double beep. Led remains on.

Enter the Manager code (and the Dallas key if programmed). The keypad

beeps twice.

Enter the ID of the user to be verified.

A single beep (negative sound) is produced for available users (not

installed) or for disabled/deleted users.

A double beep is produced for installed users.

A long beep is produced for blocked users (not possible to install).

To close this function, wait for few seconds without entering any ID. A

long beep is produced. Then, the led switches OFF.

Audit/configuration download

Audit and configuration can be downloaded on a Dallas key previously programmed with

DiaLog software and they can be downloaded on a PC through the USB interface provided

by Tecnosicurezza.

Hold press util the double beep. Led remains on.

Enter the Manager code (and the Dallas key if programmed). The keypad

beeps twice.

Insert the audit Dallas key into the reader and keep it in place (it is

recommended to use a magnetic Dallas key): the keypad beeps twice

and the download begins automatically.

Time delay and open window

Hold press util the double beep. Led remains on.

Enter the Manager code (and the Dallas key if programmed). The keypad

beeps twice.

Enter a time delay value and an opening window value.

The keypad beeps twice.

10 of 12 IU_Pulse_01_eng

User instructions

Pulse

Enter again the time delay and opening window values for confirmation.

The keypad beeps twice and the led switches off.

Time delay can be programmed in between 0 and 99 minutes, the open window in between

1 and 19 minutes.

Note: it’s possible to reduce the time delay only during the open window counting

Lock reset

The reset operation will restore the system in pre-setup mode.

Disconnect the power supply. Press keys to discharge the excess current.

Connect the reset box on the secondary connector of the lock (BAT or 2).

Power up the reset box with a 9V battery. The keypad beeps twice.

Lock is reset.

Otros manuales para Pulse

Tabla de contenidos

Otros manuales de Cerrar de Tecnosicurezza

Tecnosicurezza

Tecnosicurezza Pulse Manual de usuario

Tecnosicurezza

Tecnosicurezza Pulse Pro Manual de usuario

Tecnosicurezza

Tecnosicurezza T6530/DL Manual de usuario

Tecnosicurezza

Tecnosicurezza KL3909 Instrucciones de instalación

Tecnosicurezza

Tecnosicurezza TechMaster Manual de usuario

Tecnosicurezza

Tecnosicurezza Pulse Pro Manual de usuario

Tecnosicurezza

Tecnosicurezza Pulse Pro T6630/GRP Manual de usuario

Tecnosicurezza

Tecnosicurezza MiniRotoboIt UR4020 Guía del usuario

Tecnosicurezza

Tecnosicurezza MiniTech Instrucciones de operación

Tecnosicurezza

Tecnosicurezza MiniTech Manual de usuario

Tecnosicurezza

Tecnosicurezza T9510/BR Manual de usuario

Tecnosicurezza

Tecnosicurezza MiniTech Manual de usuario

Tecnosicurezza

Tecnosicurezza TechMaster Manual de usuario

Tecnosicurezza

Tecnosicurezza Pulse 2 Manual de usuario

Tecnosicurezza

Tecnosicurezza Pulse T6430 Manual de usuario

Tecnosicurezza

Tecnosicurezza DigiTech Manual de usuario

Tecnosicurezza

Tecnosicurezza DigiTech Manual de usuario

Tecnosicurezza

Tecnosicurezza TechMaster T9530/GR Manual de usuario

Tecnosicurezza

Tecnosicurezza TechMaster Manual de usuario

Tecnosicurezza

Tecnosicurezza TechMaster Manual de usuario

Tecnosicurezza

Tecnosicurezza StraightBolt EM3520 Manual de usuario

Tecnosicurezza

Tecnosicurezza DigiTech Series Manual de usuario

Tecnosicurezza

Tecnosicurezza AuditLine T6530/DL Manual de usuario

Tecnosicurezza

Tecnosicurezza Pulse Pro Manual de usuario

Manuales populares de Cerrar de otras marcas

Magic

Magic 105 Manual de usuario

Gantner

Gantner GAT NET.Lock 7020 System Guía rápida

Wittkopp

Wittkopp Insys 7202 Manual de usuario

Dorma

Dorma Studio Classic Manual de usuario

Securam

Securam ECSL-601 Manual de usuario

Sudhaus

Sudhaus 3003 Manual de usuario

Safety 1st

Safety 1st 48517 Manual de usuario

Pado

Pado FDS-10 Manual de usuario

Esco

Esco systeQ Series Manual de usuario

COMPX

COMPX National D8951 Manual de usuario

secureo

secureo Key Box Manual de usuario

Stock Loks

Stock Loks C8713 Manual de usuario

COMPX

COMPX 1T-058 Manual del propietario

Auslock

Auslock T11 Manual de usuario

ELCOM

ELCOM 7205 Manual de usuario

Stealth SAFES

Stealth SAFES ShadowVault Manual de usuario

Knox

Knox KeySecure 5 Manual de usuario

Kwikset

Kwikset 48334/01 Manual de usuario
