Technoline WS 9130 Manual de usuario
30
LCD Display
FEATURES:
The Weather station
Function keys
Foldout stand
Battery
compartment
cover
Hanging hole
31
• DCF-77 Radio controlled time function with manual time setting options
• DCF time reception ON/OFF
• 24 hour display
• Alarm function with snooze
• Temperature display in degree Celsius (°C)
• Indoor and outdor temperature with MIN/MAX records
• Manual reset of MIN/MAX records
• 4 weather forecast symbols with 2 weather tendency indicator arrows
• Wireless transmission at 433 MHz
• Signal reception intervals at 60 seconds
• Low battery indicator
• Wall mounting or table standing (foldout stand)
The Outdoor Temperature Transmitter
• Remote transmission of outdoor temperature to Temperature Station by 433
MHz signals
• Shower proof casing
• Wall mounting and table-standing
32
SETTING UP:
Note: This weather station receives only one outdoor transmitter.
1. First, insert the batteries into the Temperature transmitter. (see “Install and replace batteries in
the Temperature transmitter“).
2. Immediately after and within 30 seconds, insert the batteries into Weather station (see “Install and
replace batteries in the Weather station”). Once the batteries are in place, all segments of the
LCD will light up briefly. Following the time as 0:00 and the weather icon will be displayed. If these
are not displayed after 60 seconds, remove the batteries and wait for at least 10 seconds before
reinserting them.
3. After inserting the batteries, the Weather station will start receiving data from the transmitter. The
outdoor temperature and the signal reception icon should then be displayed on the Weather station.
If this does not happen after 3 minutes, the batteries will need to be removed from both units and
reset from step 1.
4. In order to ensure sufficient 433 MHz transmission however, this should under good conditions be a
distance no more than 100 meters between the final position of the Weather Station and the
transmitter (see notes on “Mounting ” and “433 MHz Reception ”).
5. Once the remote temperature has been received and displayed on the Weather station, the DCF
time (radio controlled time) code reception is automatically started. This takes typically between 3-5
minutes in good conditions.
33
Note:
Daily DCF reception is done at 01:00, 02:00 and 03:00 every day. If the reception at 03:00 is not successful,
then at 04:00 and 05:00 there are other tries, until one is successful. If the reception at 05:00 is still
not successful, then the next try takes place at 01:00 next day.
If reception is successful, the received time will override the manually set time. (Please refer also to notes
on “DCF-77 Radio Controlled Time ” and “Manual Time Setting ”)
HOW TO INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION
The Weather Station uses 2 x AAA, IEC LR3, 1.5V batteries. When batteries
will need to be replaced, the low battery icon will appear on the LCD. To
install and replace the batteries, please follow the steps below:
1. Lift up the battery compartment cover.
2. Insert batteries observing the correct polarity (see marking).
3. Replace compartment cover.
34
HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER
The Temperature Transmitter uses 2 x AAA, IEC LR03, 1.5V battery. To install and
replace the batteries, please follow the steps below:
1. Remove the battery compartment cover at the back of the transmitter.
2. Insert the batteries, observing the correct polarity (see marking).
3. Replace the battery compartment cover on the unit.
Note:
In the event of changing batteries in any of the units, all units need to be reset by
following the setting up procedures. This is because a security code is assigned by
the transmitter at start-up and this code must be received and stored by the Weather
station in the first 3 minutes of power being supplied to it.
BATTERY CHANGE:
It is recommended to replace the batteries in all units regularly to ensure optimum accuracy of these units
(Battery life See Specifications below).
Please participate in the preservation of the environment. Return used batteries to an
authorised depot.
35
FUNCTION KEYS:
Weather station:
The weather station has four easy to use function keys.
SET key
• Press the key to enter manual setting modes: Time zone, Time reception ON/OFF and Manual time
• Stop the alarm
+ key
• To make adjustment for various settings
• Stop the alarm
SET key MIN/MAX RESET key
ALARM key
+ key
36
ALARM key
• Enter the alarm setting mode
• Switch the alarm ON/ OFF
• Stop the alarm
MIN/MAX RESET key
• Press and hold to reset the MIN/MAX temperature records
• Activate the snooze
• Exit manual setting modes
37
Outdoor Reception
Signal icon*
MIN/MAX indoor
temperature
MIN/MAX outdoor
temperature
LCD SCREEN AND SETTINGS:
Time
Indoor
Temperature in °C
Outdoor
Temperature in °C
Weather tendency
indicator
Weather
forecast icon
Low battery indicator
(weather station)
Low battery indicator
(transmitter)
Radio controlled time
reception icon
Alarm icon
38
* When the outdoor signal is successfully received by the Weather Station, this icon will be switched on.
(If not successful, the icon will not be shown in LCD) So user can easily see whether the last reception
was successful (icon on) or not (icon off).
For a better display clarity, the LCD screen is split into 4 sections.
Section 1 - TIME AND ALARM
• In normal mode display of radio controlled time
• A reception tower symbol will be shown indicating that the DCF-77 time signal is scanned for
(flashing) or received (steady).
Note: The symbol will not be shown when radio time reception is not successful or when time
reception function is turned off.
• In normal display, the alarm icon will be shown when the alarm is turned on. Or when the snooze
function is activated, the alarm icon will be flashing.
Section 2 - INDOOR TEMPERATURE
• Display the current indoor temperature and indoor MIN/MAX records
• Display of low battery indicator (weather station)
39
Section 3 - WEATHER FORECAST AND WEATHER TENDENCY ICONS
• Display of the weather to be expected in form of four weather symbols and two weather tendency
indicators in form of an arrow, which change their appearance depending on the air pressure
development
Section 4 - OUTDOOR TEMPERATURE
• Display the current outdoor temperature and outdoor MIN/MAX records
• A signal reception symbol will be shown indicating that receiver is receiving outdoor temperature
• Display of low battery indicator (transmitter)
MANUAL SETTINGS:
The following manual settings can be done in the setting mode:
• Time zone
• Time reception DCF ON/OFF
• Manual time
Press and hold the SET key for about 3 seconds to advance to the setting mode:
