WS 6449

GB 1

Environmental reception effects

The station obtains the accurate time with wireless technology. Same as all wireless devices, the reception is

maybe affected by the following circumstances:

long transmitting distance

nearby mountains and valleys

near freeway, railway, airports, high voltage cable etc.

near construction site

among tall buildings

inside concrete buildings

near electrical appliances (computers, TV’s, etc) and metallic structures

inside moving vehicles

Place the station at a location with optimal signal, i.e. close to a window and away from metal surfaces or

electrical appliances.

Precautions

This main unit is intended to be used only indoors.

Do not subject the unit to excessive force or shock.

Do not expose the unit to extreme temperatures, direct sunlight, dust or humidity.

Do not immerse in water.

Avoid contact with any corrosive materials.

Do not dispose this unit in a fire as it may explode.

Do not open the inner back case or tamper with any components of this unit.

Batteries safety warnings

Use only alkaline batteries, not rechargeable batteries.

Install batteries correctly by matching the polarities (+/-).

Always replace a complete set of batteries.

Never mix used and new batteries.

Remove exhausted batteries immediately.

Remove batteries when not in use.

Do not recharge and do not dispose of batteries in fire as the batteries may explode.

Ensure batteries are stored away from metal objects as contact may cause a short circuit.

Avoid exposing batteries to extreme temperature or humidity or direct sunlight.

Keep all batteries out of reach from children. They are a choking hazard.

WS 6449

GB 2

Use the product only for its intended purpose!

Consideration of duty according to the battery law

Old batteries do not belong to domestic waste because they could cause damages of health

and environment. You can return used batteries free of charge to your dealer and collection

points. As end-user you are committed by law to bring back needed batteries to distributors

and other collecting points!

Consideration of duty according to the law of electrical devices

This symbol means that you must dispose of electrical devices separated from the General

household waste when it reaches the end of its useful life. Take your unit to your local waste

collection point or recycling centre. This applies to all countries of the European Union, and to

other European countries with a separate waste collection system.

Features:

Calendar (Date/month,2000-2099 Default Year 2016)

Indoor Temperature and Humidity

Outdoor Temperature and Humidity

12/24 h time format selectable

Alarm and snooze function

Low battery icon

Weather forecast: sunny, partly sunny, cloudy, rainy and stormy

Maximum and minimum temperature/humidity

Seven languages for week (GER, ITA, DUT, SPA, DAN, ENG, FRA)

Time zone：-12/+12HR

DCF Radio clock receiver function

White backlight

Batteries:

Receiver : 2x AAA (only for back-up) / TX960-TH sensor: 2x AAA

LCD Display:

WS 6449

GB 3

Quick setup

1. Keep your weather station and wireless outdoor transmitter next to each other.

2. Make sure the Channel selector switch on sensor is at 1 position.

3. Open the battery cover at the back of your wireless outdoor transmitter and insert 2 x AAA new alkaline

batteries to the battery compartment. Replace the battery cover.

4. Connect the included power supply with the socket on the backside of the weather station or alternatively

you can use batteries: Open the battery cover at the back of your weather station and insert 2x AAA new

alkaline batteries to the battery compartment. Replace the battery cover. Please note, without adapter and

only batteries the backlight is always set off and you need to press the “SNOOZE/LIGHT” button to turn on

backlight for 10 seconds.

5. Make sure Channel 1 is displayed on the weather station. Your weather station will receive data signal

from the outdoor transmitter in a few seconds.

6. Place your outdoor transmitter in a dry and shaded area once the weather station receives the data of this

sensor.

Power On:

1. Display full segment for 2 second.

2. The weather station searching starts wireless sensor via 433MHz.

3. If the outdoor temperature is not displayed after 3 minutes, hold the “CH”button on the main unit to search

for outdoor sensor. Then press the “TX”button on the sensor to send signal. If it still does not receive the

outdoor temperature, remove the batteries from the transmitter and go back to step 1 of the set up

Sensor Reception

Press and hold the CH/+ button for 3 seconds while viewing an empty channel to search for the sensor.

The strength signal icon will flash until the sensor signal is received or for 3 minutes if no signal available.

Adding additional sensors

1. Make sure Channel 2 or 3 is displayed on the weather station. Press the “CH” button to change channels

on the weather station.

2. Make sure the Channel selector switch on the sensor is at 2 or 3 position

3. Once the Channel numbers on weather station and sensor are the same, proceed by opening the battery

cover at the back of your wireless sensor and insert 2 x AAA new alkaline batteries to the battery

compartment. Replace the battery cover.

4. Your weather station will receive the data signal from the outdoor transmitter in a few seconds.

5. Place your outdoor transmitter in a dry and shaded area once the weather station receives the data of this

sensor.

Note:

If the weather station is used with 2 or 3 transmitters, press “CH” button shortly to display Channel 1,

Channel 2, Channel 3 or cyclic display.

In cyclic display, the channel will be changed every 25 seconds in overview all channels in a short period of

time

Deleting sensors / clearing channels

Press and hold the “CH”button for 3 seconds to clear the current channel to re-register

WS 6449

GB 4

Display / Keys Details:

There are six function buttons:

DCF Reception icon with full signal strength will appear on screen if the reception of atomic time is

successful.

In normal display mode, press this “-/RCC” button to start/stop time searching (DCF).

The tower icon will show solid when the station has received the DCF signal.

No tower icon displayed. The station was unable to receive a signal at this time.

Reposition the station for better signal reception and wait an overnight.

automatically receive Hours: Daily 1:00,2:00,3:00,4:00,5:00 DCF automatically receive, at any time once

received 3,4,5:00 no longer receive the same day

Only if the unit receives summer time, it will display the “DST” icon.

If there is no signal or too much interference the receiver will only be on for 2 minutes.

If the signal is good it may catch a signal in ABOUT 2-3 minutes.

If the signal is marginal it will try to catch a signal for up to 10 minutes.

Manual Time Setting:

1. Press and hold the “SET” button for 3 seconds in normal display mode to enter time setting mode.

2. 12Hr or 24Hr will flash. Press the “+” or “-“button to select between the 12-hour or 24-hour time format.

Press the “SET” button to confirm and continue.

3. The time zone will flash on the display. Press the “+” or “-“ button to set the desired time zone( setting

range is 0~ +12,0~ -12). Press the “SET” button to confirm and continue.

4. The hour will flash. Press the “+” or “-“button to select the hour. Press the “SET” button to confirm and

continue.

5. The minutes will flash. Press the “+” or “-“button to select the minutes. Press the “SET” button to

confirm and continue.

6. The year will flash. Press the “+” or “-“button to select the year. Press the “SET” button to confirm and

continue.

7. The month will flash. Press the “+” or “-“button to select the month. Press the “SET” button to confirm

and continue.

8. The date will flash. Press the “+” or “-“button to select the date. Press the “SET” button to confirm and

continue. The day of the week will set automatically after YEAR, MONTH, DATE.

9. The language will flash, the default is GER. Press the “+” or “-“button to select the desire language: GER,

FRE, ITA, DUT, SPA, DAN, ENG. Press the “SET” button to confirm and continue.

WS 6449

GB 5

10. The value of air pressure will flash. Press the “+” or “-“button to enter the relative value of air pressure.

The relative air pressure can be requested from a local meteorological service. Press the “SET” button to

confirm and return to the normal display mode.

Note:

If no buttons are pressed in a 20 seconds period, time setting mode will time out and return to normal

display mode, reflecting whatever adjustments were made by user before timed out

+/- buttons: Press once to adjust by 1 unit, hold for fast scroll adjustment

Activating and deactivating the alarm

1. Press the “ALARM” button once to enter the alarm mode and “ALM” will be shown on the display.

2. Press the “+” or “-“button to activate or deactivate the alarm. The alarm icon will be displayed

permanently as long as the alarm is activated and the alarm icon will no longer be displayed as soon as

the alarm is deactivated.

3. Press the “ALARM” button once again to confirm and return to the normal display mode. “ALM” will no

longer be shown on the display.

Alarm setting

1. Press and hold the “ALARM” button for 3 seconds in normal display mode to enter alarm setting mode.

2. The alarm hour will flash. Press the “+” or “-“button to select the alarm hour. Press the “ALARM” button

to confirm and continue.

3. The alarm minutes will flash. Press the “+” or “-“ button to select the alarm minute. Press the “ALARM”

button to confirm and return to the normal display mode.

Note:

If no buttons are pressed in a 20 seconds period, alarm setting mode will time out and return to live display

mode, reflecting whatever adjustments were made by user before timed out

+/- buttons: Press once to adjust by 1 unit, hold for fast scroll adjustment

When the alarm sounds, it continues for 2 minute and then shuts off completely.

WS 6449

GB 6

Snooze function

1. Press “SNOOZE/LIGHT” button and the white backlights activates for 10 seconds.

2. When alarm sounds, press the “SNOOZE/LIGHT” button to trigger snooze for 10 minutes. The alarm icon

flashes when the snooze feature is active.

Note:

To stop alarm for one day, press any button but “SNOOZE/LIGHT” button, while in snooze mode. The

alarm icon will stop flashing.

Backlight function

With adapter, the display will always have backlight on.

Without adapter, press the “SNOOZE/LIGHT” button to turn on backlight for 10 seconds.

MAX/MIN values:

In normal display mode, press the “MIN/MAX” button to display maximum temperature/humidity. Press

the “MIN/MAX” button once more to display minimum temperature/humidity.

Press and hold the “MIN/MAX” button for 3 seconds in the corresponding interface to clear max or min

temperature/humidity memory.

After 5 seconds the display will return back to the normal display mode.

The MIN/MAX values will also be automatically cleared at every midnight (0:00).

Barometer and bar and data of history for the past 12 hour of air pressure

Air pressure history can be displayed in hPa , for the past 12 hours

The bar graph indicates the air pressure history trend over the last 12

hours in 6 intervals: 0h, -1h, -2h, -3h, -6h, and -12h. The “0h” represents

the current full hour air pressure recording. The columns represent the

“hPa” (0, ±2, ±4, ±6) at a specific time. The “0” in the middle of this scale

is equal to the current pressure and each change (±2, ±4, ±6 ) represents

how high or low in “hPa“ the past pressure was compared to the current

pressure.

For accurate barometric pressure trends, the weather station should

operate at the same altitude for recordings (i.e. it should not be moved from the ground to the second floor

of the house). When the unit is moved to a new location, discard readings for the next 12 hours.

Weather forecast

5 Weather forecast symbols can be displayed: sunny, partly sunny, cloudy, rainy, stormy

Note:

The weather forecast is determined by temperature, humidity and air pressure. The forecast symbol may

not match with the current weather.

Changing temperature unit

WS 6449

GB 7

Press the “°C/°F” button to choose temperature unit from °C or °F.

Low battery indicator

The weather station displays the low battery condition symbol to remind that the batteries of the weather

station or the outdoor sensor need to be exchanged.

Battery icon by indoor temperature-Change batteries in the clock.

Battery icon by outdoor temperature-Change batteries in the sensor.

Specifications

Indoor temperature:

Operating temperature range = -9.9°C to 50°C (14°F to 122°F)

Accuracy ± 1 degrees Celsius 0°C to 50°C (32°F to122°F)

Resolution = 0.1 degree Celsius

When above 50°C (122°F), the LCD will display HI

When below- 9.9°C (14°F) the LCD will display LO

Indoor Humidity:

Operating humidity range =20% RH to 95%

Accuracy +/- 5% RH

Resolution = 1 % RH

Outdoor temperature:

Operating temperature range = -40°C to 60°C (-40°F to 140°F)

Accuracy ± 1 degrees Celsius from 0°C to 50°C (32°F to122°F)

Accuracy ±1.5 degrees Celsius -40°C to 0°C (-40°F to 32°F) and 50°C to 60°C(122°F to 140°F)

Resolution = 0.1 degree Celsius

When above 60°C (140° F), the LCD will display HI

When below-40°C (-40°F), the LCD will display LO

Outdoor Humidity:

Operating humidity range =20% RH to95%

Accuracy +/- 5% RH

Resolution = 1 % RH

Default SETTING:

Time:00:00

Temperature: ºC

Weather Forecast Icons: partly sunny

German week display

Tabla de contenidos

Otros manuales de Estación meteorológica de Technoline

Technoline

Technoline WS 9123 Manual de usuario

Technoline

Technoline WS 6600 Manual de usuario

Technoline

Technoline Mobile Alerts MA 10920 Manual de usuario

Technoline

Technoline WS 8301 Manual de usuario

Technoline

Technoline WS 6449 Manual de usuario

Technoline

Technoline WS 9069 Manual de usuario

Technoline

Technoline WS 9750 Manual de usuario

Technoline

Technoline WS6446 Manual de usuario

Technoline

Technoline WS9130 Manual de usuario

Technoline

Technoline WS 585 Manual de usuario

Technoline

Technoline WS-6010 Manual de usuario

Technoline

Technoline WS 9255 Manual de usuario

Technoline

Technoline WL 1030 Manual de usuario

Technoline

Technoline WS 6730 Manual de usuario

Technoline

Technoline WS 6710 Manual de usuario

Technoline

Technoline DCF-77 Manual de usuario

Technoline

Technoline WS 7018 Manual de usuario

Technoline

Technoline WS 9257-IT Manual de usuario

Technoline

Technoline WS6447 Manual de usuario

Technoline

Technoline WS6767 Manual de usuario

Technoline

Technoline WS9125 Manual de usuario

Technoline

Technoline WS9470 Manual de usuario

Technoline

Technoline WS6501 Manual de usuario

Technoline

Technoline WS 6750 Manual de usuario

Manuales populares de Estación meteorológica de otras marcas

Auriol

Auriol AHFL 433 A1 Manual de usuario

NexSens

NexSens G2-HYDROMET Manual de usuario

Hyundai

Hyundai WS 2202 Manual de usuario

IROX

IROX HBVR761 UV-X Manual de usuario

La Crosse Technology

La Crosse Technology C86371 Manual de usuario

ADE

ADE WS 1711 Manual de usuario

Auriol

Auriol z29592 Manual de usuario

Auriol

Auriol 296289 Manual de usuario

Hyundai

Hyundai WS 2266 Manual de usuario

La Crosse Technology

La Crosse Technology WS-2210 Manual de usuario

La Crosse Technology

La Crosse Technology WS-811561 Manual de usuario

Ventus

Ventus W177 Manual de usuario

National Geographic

National Geographic VA Colour RC Manual de usuario

Renkforce

Renkforce 1208067 Manual de usuario

Levenhuk

Levenhuk Discovery Report WA40 Manual de usuario

Instant Transmission

Instant Transmission MA 10410 Manual de usuario

Lutron Electronics

Lutron Electronics PHB-318 Manual de usuario

WAREMA

WAREMA EWFS Weather station eco Manual de usuario
