Technoline WS 9257-IT Manual de usuario

WIRELESS 868 MHz WEATHER STATION

Instruction Manual

INTRODUCTION

Congratulations on purchasing this state-of-the-art weather station as an example of innovative design and

quality piece of engineering. Providing time, date, calendar, moon phase, sunrise/sunset time, indoor and

outdoor temperature, indoor and outdoor relative humidity, and air pressure history information, this unit will

never keep you guessing on current and future weather conditions. Operation of this product is simple and

straightforward. By reading this operating manual, the user will receive a better understanding of the

weather station together with the optimum benefit of all its features.

FEATURES

The weather station

24 hour time display (seconds displayed by pressing the SUN key)

Weekday, day and month display (year in setting mode)

Daylight saving time (DST) function selectable

Daily alarm function

Weather forecast with weather tendency indicator

Temperature display in degree Celsius (°C)

Indoor temperature display with MIN/MAX recordings

Outdoor temperature display with MIN/MAX recordings, time and date

All MIN/MAX temperature recordings can be reset

Indoor and outdoor relative humidity display in RH%

Display of relative or absolute air pressure in hPa

Relative air pressure with adjustable reference value

LCD

Display

Battery

compartment

cover

Foldout

stand

Hanging hole

Function

Keys

Relative air pressure history bar graph for the past 12 hours

Display of sunrise time, sunset time and sun duration in 150 European cities

Display 8 moon phase icons with indicator throughout the year

LCD contrast setting

Indoor and outdoor low battery indicators

Table standing/wall mounting

Thermo-hygro Transmitter

Remote transmission of outdoor temperature and humidity to weather station by

868MHz

Wall mounting case

Mounting at a sheltered place. Avoid direct rain and sunshine

HOW TO INSTALL AND REPLACE BATTERIES IN THE THERMO-HYGRO TRANSMITTER

The outdoor thermo-hygro transmitter uses 2 x AAA, IEC LR3, 1.5V batteries. When the

batteries need to be replaced, the low battery symbol will appear on the LCD. To install and

replace the batteries, please follow the steps below:

1. Remove the cover.

2. Insert batteries, observing the correct polarity (see marking).

3. Replace the battery cover on the unit.

HOW TO INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION

The weather station uses 2 x C, IEC LR14, 1.5V batteries. To install and replace the batteries, please follow

the steps below: 1. Remove the cover at the back of the weather station.

2. Insert batteries, observing the correct polarity (see

marking).

3. Replace the compartment cover.

Note: Always wait for 2 minutes after removing the batteries

before reinserting, otherwise start up and transmission

problems may occur. In the event of changing batteries in any

of the units, all units need to be reset by following the setting

up procedures.

BATTERY CHANGE

It is recommended to replace the batteries in all units regularly to ensure optimum accuracy of these units

(Battery life See Specifications below).

Please participate in the preservation of the environment. Return used batteries to an

authorized depot.

SETTING UP

Note: This weather station receives only one outdoor transmitter.

1. First, insert the batteries in the transmitter (see “How to install and replace batteries in the thermo-

hygro transmitter”above).

2. Within 30 seconds of powering up the transmitter, insert batteries in the weather station (see “How to

install and replace batteries in the weather station”above). Once the batteries are in place, all

segments of the LCD will light up briefly and a short signal tone will sound. Then the indoor

temperature, humidity and the time as 0:00 will be displayed. If these information are not displayed on

the LCD after 60 seconds, remove the batteries and wait for at least 60 seconds before reinserting

them. Once the indoor data is displayed user may proceed to the next step.

3. After the batteries are inserted, the weather station will start receiving data signal from the transmitter.

The outdoor temperature and humidity data should then be displayed on the weather station. If this

does not happen after 2 minutes, the batteries will need to be removed from both units and reset from

step 1.

4. In order to ensure successful 868 MHz transmission, the distance between the weather station and

the transmitter should be within 100 meters (see notes on “Positioning” and “868 MHz Reception”).

FUNCTION KEYS

Weather station:

The weather station has five easy to use function keys:

SET key

Press and hold for 3 seconds to enter manual setting modes: LCD contrast, Daylight Saving Time

ON/OFF, manual time, calendar and relative air pressure reference value

To stop the alarm sound

SET key

+key

MIN/MAX key

ALARM key

SUN key

To exit alarm setting mode and country/city setting mode

To toggle between relative and absolute air pressure display

+ key

To increase/change values in setting modes

To stop the alarm sound

MIN/MAX key

To switch among the display of MIN/MAX indoor temperature and MIN/MAX outdoor temperature

records

To decrease/change values in setting modes

At normal mode, press and hold the key for 3 seconds to reset ALL indoor/outdoor MAX/MIN

temperature recordings to current readings

To stop the alarm sound

ALARM key

To activate/deactivate the alarm and display alarm time

Press and hold for 3 seconds to enter the alarm setting mode

To stop the alarm sound

To exit manual setting mode and country/city setting mode

SUN key

To switch among the display of date (normal mode), seconds, sun duration and city

Press and hold for 3 seconds to enter country/city setting mode

To stop the alarm sound

To exit manual setting mode and alarm setting mode

LCD SCREEN

The LCD screen is split into 3 sections displaying the information for time/calendar, indoor

temperature/humidity, moon phase, sunrise/sunset time, weather forecast, air pressure, and outdoor

temperature/humidity.

* When the signal is successfully received by the weather station, the outdoor reception icon will be

switched on. (If not successful, the icon will not be shown in LCD) So the user can easily see whether the

last reception was successful (icon on) or not (icon off). On the other hand, the flashing of the icon shows

that a reception is being done now.

MANUAL SETTINGS

The following settings can be changed when pressing the SET key:

LCD contrast

Daylight saving time (DST) ON/OFF

Manual time

Calendar

Relative air pressure reference value

Press and hold the SET key for about 3 seconds to advance to the setting mode:

Summer time

indicator

Low battery indicator

(Weather Station)

Calendar

Weather

forecast icon

Air pressure

history bar

graph

Outdoor data signal

reception indicator *

Weather

Tendency indicator

Outdoor

Temperature

in °C

Sunset Time

Weekday

Indoor

Temperature

in °C

Time

Alarm icon

Moon

phase

indicator

Sunrise Time

Outdoor humidity

display in RH%

MIN/MAX outdoor

temperature records

Indoor humidity

display in RH%

Air pressure in hPa

(relative or absolute)

Low battery

indicator (Outdoor

transmitter)

Weekday

Year (flashing)

Day. Month.

LCD CONTRAST SETTING

The LCD contrast can be set within 8 levels, from LCD 0 to LCD 7 (Default is LCD 3):

1. The digit starts flashing

2. Press the +key or MIN/MAX key to set the level of contrast desired.

3. Press the SET key to enter “Daylight Saving Time On/Off setting,” or exit the setting mode by

pressing the ALARM key or SUN key.

DAYLIGHT SAVING TIME ON/OFF SETTING

The daylight saving time (DST) function can be set ON/OFF. Default setting is “ON”:

1. “ON” will flash on the LCD with "dSt" displayed.

2. Use the +key to turn the daylight saving time function ON or OFF.

3. Press the SET key to enter “Manual Time setting” or exit the setting mode by pressing the ALARM

key or SUN key.

MANUAL TIME SETTING

To set the clock:

1. The hour digit will start flashing.

2. Use the +key to increase or MIN/MAX key to decrease the value. Keep holding the key allows the

value to advance faster.

3. Press the SET key to enter minute setting.

4. The minute will be flashing. Use the +key to increase or MIN/MAX key to decrease the value.

5. Press the SET key to enter “Calendar Setting” or exit the setting mode by pressing the ALARM key

or SUN key.

CALENDAR SETTING

Minutes

Hour (flashing)

Digit flashing

Flashing

1. The year digits will start flashing.

2. Use the +key to increase or MIN/MAX key to decrease the value. The range runs from 2011 to 2025.

3. Press the SET key to enter the month setting mode.

4. The month digit will be flashing. Use the +key to increase or MIN/MAX key to decrease the value.

5. Press the SET key to enter day setting, or exit the setting mode by pressing the ALARM key or SUN

key.

6. The day digit will be flashing. Use the +key to increase or MIN/MAX key to decrease the value. Keep

holding the key allows the value to advance faster.

7. Press the SET key to enter the “Relative Air Pressure Reference Value Setting”, or exit the setting

mode by pressing the ALARM key or SUN key.

Note:

The corresponding weekday is displayed above the time in short form (from Monday to Sunday): MO / TU /

WE / TH / FR / SA / SU

RELATIVE AIR PRESSURE REFERENCE VALUE SETTING

The default relative pressure value is 1013 hPa (29.92 inHg). This can be manually set to another value

within the range of 960 –1040 hPa (28.35 –30.72 inHg) for a better reference.

1. The current relative pressure value will start flashing

2. Use the +key or MIN/MAX key to increase or decrease the value. Keep holding the key will allow the

value to change faster.

3. Press the SET key to exit the setting mode.

LOCATION SETTNG FOR SUNRISE/SUNSET TIME

The weather station will automatically update the sunrise, sunset and sun duration time at 00:00, based on

the city location, the date, time and DST settings.

1. Press and hold the SUN key for 3 seconds to enter the Location setting mode.

2. The short form of Country name will start flashing. Use the +key or MIN/MAX key to select the

Country.

Note: 150 European cities can be chosen from. Every country/city is displayed in short code. See the list at

the beginning of this handbook for all the country/ city codes.

Country Code (flashing)

flashing

3. With the desired country selected, press the SUN key to enter City setting mode.

4. The City code will start flashing. Use the +key or MIN/MAX key to select the City. Keep holding the

key allows the value to advance faster.

5. Confirm with the SUN key, or exit the setting mode by pressing the SET key or ALARM key without

saving the changes.

6. The city’s sunrise, sun duration and sunset time will be displayed in a few seconds.

7. Press the SUN key twice to go back to normal date display.

DISPLAY OF SUN DURATION TIME

1. In normal date mode, press the SUN key twice to display the sun duration time (total number of hours

of sunlight on the day).

2. Press the SUN key again will display the City selected. (See “LOCATION SETTNG FOR

SUNRISE/SUNSET TIME”)

3. Press the SUN key again to go back to normal date display.

ALARM SETTING

To set the daily alarm:

1. Press and hold ALARMkey for 3 seconds until the alarm time shown.

2. The hour digit will be flashing. Press the +key or MIN/MAX key to adjust the hour.

3. Press ALARM key once and minute digit will be flashing. Press +key or MIN/MAX key to set the

minute, or exit the setting mode by pressing the SET key or SUN key.

4. Press ALARM key once more to return to normal display.

Note: To activate/deactivate the alarm function, press the ALARM key shortly. The display of the ((())) icon

represents that the alarm is "ON".

Sunrise

time

Sun duration

(hours : minutes)

Sunset

icon

Sunrise

icon

Sunset

time

City Code (flashing)

Alarm time

(flashing)

Alarm On indicator

Note: The duration of alarm sounding is 2 minutes. Press any key will stop the alarm sound.

TO EXIT SETTING MODES

To exit the setting modes anytime, user can wait for automatic timeout to return to normal display.

WEATHER FORECASTING ICONS

Weather icons can be displayed in any of the following combinations:

For every sudden or significant change in the air pressure, the weather icons will update accordingly to

represent the change in weather. If the icons do not change, then it means either the air pressure has not

changed or the change has been too slow for the Weather station to register. However, if the icon displayed

is a sun or raining cloud, there will be no change of icon if the weather gets any better (with sunny icon) or

worse (with rainy icon) since the icons are already at their extremes.

The icons displayed forecasts the weather in terms of getting better or worse and not necessarily sunny or

rainy as each icon indicates. For example, if the current weather is cloudy and the rainy icon is displayed, it

does not mean that the product is faulty because it is not raining. It simply means that the air pressure has

dropped and the weather is expected to get worse but not necessarily rainy.

Note:

After setting up, readings for weather forecasts should be disregarded for the next 12-24 hours. This will

allow sufficient time for the weather station to collect air pressure data at a constant altitude and therefore

result in a more accurate forecast.

Common to weather forecasting, absolute accuracy cannot be guaranteed. The weather forecasting feature

is estimated to have an accuracy level of about 75% due to the varying areas the weather station has been

designed for use. In areas that experience sudden changes in weather (for example from sunny to rain), the

weather station will be more accurate compared to use in areas where the weather is stagnant most of the

time (for example mostly sunny).

If the weather station is moved to another location significantly higher or lower than its initial standing point

(for example from the ground floor to the upper floors of a house), discard the weather forecast for the next

12-24 hours. By doing this, the weather station will not mistake the new location as being a possible change

in air-pressure when really it is due to the slight change of altitude.

WEATHER TENDENCY INDICATOR

Working together with the weather icons is the weather tendency indicator (located on the left of the weather

icons). When the arrow points upwards, it means that the air pressure is increasing and the weather is

expected to improve, but when arrow points downwards, the air pressure is dropping and the weather is

expected to become worse.

Taking this into account, one can see how the weather has changed and is expected to change. For

example, if the indicator is pointing downwards together with cloud and sun icons, then the last noticeable

Sun

Sun with cloud

Cloud with

rain

change in the weather was when it was sunny (the sun icon only). Therefore, the next change in the weather

will be cloud with rain icons since the indicator is pointing downwards.

Note: Once the weather tendency indicator has registered a change in air pressure, it will remain

permanently visualized on the LCD.

AIR PRESSURE HISTORY (ELECTRONIC BAROMETER WITH BAROMETRIC PRESSURE

TREND)

The right side of the second section of the LCD shows the air pressure history bar graph.

The bar graph indicates the air pressure history trend over the last 12 hours in 5 intervals: 0h, -3h, -6h, -9h

and -12h. The “0h” represents the current full hour air pressure recording. The columns represent the “hPa”

(0, ±1, ±3, ±5) at specific time. The “0” in the middle of this scale is equal to the current pressure and each

change (±1, ±3, ±5) represents how high or low in “hPa“ the past pressure was compared to the current

pressure.

If the bars are rising it means that the weather is getting better due to the increase of air pressure. If the bars

go down, it means the air pressure has dropped and the weather is expected to get worse from the present

time “0h“.

Note:

For accurate barometric pressure trends, the weather station should operate at the same altitude for

recordings (i.e. it should not be moved from the ground to the second floor of the house). When the unit is

moved to a new location, discard readings for the next 12 hours.

ABSOLUTE/RELATIVE AIR PRESSURE

Press the SET key to toggle between relative (“rel”) and absolute (“abs”) air pressure displays.

Note:

Absolute air pressure provides the display of the true measured air pressure of the current time and location.

This is not programmable and the absolute air pressure range of the weather station is from 300 hPa to

1099 hPa (standard air pressure at an altitude of 9,100 meters is around 300 hPa).

Relative air pressure is the one value that is calculated back to sea level from the local absolute air pressure

and can thus be taken as a reference for weather condition and weather development for the entire country.

It can be programmed to represent your local surroundings. Since the relative air pressure is also the one

value given by various newspapers, TV and radio broadcasting stations in their daily weather forecasts for

Air pressure trend over

the last 12 hours

Absolute air pressure display

Tabla de contenidos

Otros manuales de Estación meteorológica de Technoline

Technoline

Technoline WS 6445 Manual de usuario

Technoline

Technoline WS 9032 Manual de usuario

Technoline

Technoline WS 9273 Manual de usuario

Technoline

Technoline WA3090 Manual de usuario

Technoline

Technoline MOBILE ALERTS MA 10430 Manual de usuario

Technoline

Technoline WS-6010 Manual de usuario

Technoline

Technoline WD 3050 Manual de usuario

Technoline

Technoline WS 6832 Manual de usuario

Technoline

Technoline WS 9069 Manual de usuario

Technoline

Technoline WS 9120 Manual de usuario

Technoline

Technoline WS9767 Manual de usuario

Technoline

Technoline WS 6600 Manual de usuario

Technoline

Technoline WT 245 Manual de usuario

Technoline

Technoline WS9470 Manual de usuario

Technoline

Technoline WS 6502 Manual de usuario

Technoline

Technoline WS 9170 Manual de usuario

Technoline

Technoline WS 6750 Manual de usuario

Technoline

Technoline WS 9910 Manual de usuario

Technoline

Technoline WS 6710 Manual de usuario

Technoline

Technoline WS 6449 Manual de usuario

Technoline

Technoline WS-9632-IT Manual de usuario

Technoline

Technoline WS8014 Manual de usuario

Technoline

Technoline DCF-77 Manual de usuario

Technoline

Technoline WS9132 Manual de usuario

Manuales populares de Estación meteorológica de otras marcas

Auriol

Auriol AHFL 433 A1 Manual de usuario

NexSens

NexSens G2-HYDROMET Manual de usuario

Hyundai

Hyundai WS 2202 Manual de usuario

IROX

IROX HBVR761 UV-X Manual de usuario

La Crosse Technology

La Crosse Technology C86371 Manual de usuario

ADE

ADE WS 1711 Manual de usuario

Auriol

Auriol z29592 Manual de usuario

Auriol

Auriol 296289 Manual de usuario

Hyundai

Hyundai WS 2266 Manual de usuario

La Crosse Technology

La Crosse Technology WS-2210 Manual de usuario

La Crosse Technology

La Crosse Technology WS-811561 Manual de usuario

Ventus

Ventus W177 Manual de usuario

National Geographic

National Geographic VA Colour RC Manual de usuario

Renkforce

Renkforce 1208067 Manual de usuario

Levenhuk

Levenhuk Discovery Report WA40 Manual de usuario

Instant Transmission

Instant Transmission MA 10410 Manual de usuario

Lutron Electronics

Lutron Electronics PHB-318 Manual de usuario

WAREMA

WAREMA EWFS Weather station eco Manual de usuario
