TechnoKom AutoGRAPH STEALTH Manual de usuario

VERSION

2015

AutoGRAPH-ST •USER MANUAL

Table of contents

Introduction................................................................................................................................................................4

Basic information ............................................................................................................................................. 4

Scope of Supply....................................................................................................................................................6

Technical Specication....................................................................................................................................7

ComponentsofAutoGRAPH-ST...............................................................................................................9

Getting Started.....................................................................................................................................................11

Installation of a SIM card....................................................................................................................... 11

Inserting the battery....................................................................................................................................12

Settings..................................................................................................................................................................13

Device Functions...............................................................................................................................................15

«Test» button....................................................................................................................................................15

Coordinate acquisition..............................................................................................................................16

Recording the data......................................................................................................................................16

Data transmission .......................................................................................................................................16

Motion detection............................................................................................................................................17

Additional functions.....................................................................................................................................17

Real-time tracking........................................................................................................................................18

Proles........................................................................................................................................................................19

Device Indicators..............................................................................................................................................22

Drivers Installation...........................................................................................................................................23

Connection to PC.............................................................................................................................................24

AutoGRAPH-STMessages.......................................................................................................................25

Recommendations on proper operation........................................................................................28

AutoGRAPH-ST •USER MANUAL

Introduction

This User Manual applies to the AutoGRAPH-ST autonomous anti-thief device

(hereafter - device, AutoGRAPH-ST) produced by TechnoKom Ltd. It contains

installation and connection procedures of this device, as well as its function

and control. This Manual constitutes the Operating Rules to be observed to

ensure successful operation of the controller and its compliance with TU 6811-

004-12606363-2013 and warranty provisions.

All information on functions, functional capabilities and other specications related to

AutoGRAPH-ST tracking devices as well as all information contained in this User Manual is based

on current data (at time of writing) and is deemed to be valid as of the date of publication.

TechnoKom reserves the right to modify the information or specications without prior notice

or commitment.

IMPORTANT

Basic information

• AutoGRAPH-ST is an autonomous anti-thief device intended for acquisition

of the exact coordinates of assets and delivery of the coordinates to the

customer by SMS, Email and GPRS.

• The customer can track asset in real-time using the AutoGRAPH-Web

application.

• The compact form factor makes the device easy to install and difcult to

detect.

• The autonomous power supply is enough to send 1200 messages. Under

normal usage the battery life time is up to 2 years.

• Operation of the device is organized in such way that the device is in

Standby mode most of time. The AutoGRAPH-ST switches to Operation

mode for acquisition of asset coordinates and delivery to the customer.

The device will then switch to Standby mode until next period of Operation

mode. First of all such behaviour extends battery life time. Secondly, it makes

detection by GSM/GPS scanners more difcult by limiting operational time.

AutoGRAPH-ST •USER MANUAL

• All operation parameters of AutoGRAPH-ST are congurable, so the

device can be customized for a great number of applications. Standard

proles provide quick setup of the device for most common applications by

sending a short command to device.

• Remote setting allows the customer to control the device by sending

settings in an SMS from anywhere without device removal and connection

to a PC.

• In addition to location, the AutoGRAPH-ST sends information on current

battery voltage, SIM balance, ambient temperature and asset speed to the

customer.

• A built-in accelerometer detects start of motion, overturning, vibrations and

other forces on the device which could be an attempt at wilful damage of the

asset. The AutoGRAPH-ST can be customized to send a notication to the

customer if the device detects acceleration above a preset threshold.

AutoGRAPH-ST •USER MANUAL

Scope of Supply

№Description Qty

1«AutoGRAPH-ST» 1 pc.

2Battery Set (Li-SOCI2)* 1 pc.

3Password Card 1 pc.

4User Sheet 1 pc.

5Warranty Certicate 1 pc.

* installed in device.

AutoGRAPH-ST •USER MANUAL

Technical Specification

Description Value

GNSS chipset Mediatek MT3333

Supported GNSS GPS+GLONASS /

GALILEO / Beidou

Accuracy, when using GPS/GLONASS GNSS*:

• position, m

• velocity, m/s

• time (typ), µs

3.0

0.02

Type of GPS/GLONASS antenna Internal

Position accuracy when using LBS**:

• in city

• in the countryside

200...1000 m

1...30 km

Communication GSM / GPRS / SMS /

SMTP (Email)

SIM holders 1

Type of GSM antenna Internal

Connection to PC USB 2.0

Internal FLASH memory, records > 270.000

Built-in accelerometer Optional

Power consumption in Standby mode, µA 15

Battery type Li /SOCI2

Rated battery voltage, V 7.2

Battery capacitance, mА/h 1700

AutoGRAPH-ST •USER MANUAL

Description Value

Battery life up to 2 years / approx.

1200 messages***

Time to rst position x (typ.), s 23*

Operating temperature, °С от - 40 до + 85

Dimensions, mm 74 х 48 х 21

Weight (with battery), g 80

* With nominal signal levels - 130 dBm.

** A wide specied range is supplied as the position accuracy when using LBS depends on base stations location around asset.

*** Battery capacity is enough to send 1200 messages with coordinates (Email, SMS and data to server). Under normal use battery

life time amounts up to 2 years.

AutoGRAPH-ST •USER MANUAL

Components of AutoGRAPH-ST

The small form factor of the device makes it easy to install and prevents easy

discovery.

Battery placement

(projected part)

GPS/GLONASS

antenna placement

Fastening screws

(4 pc.)

Manufacturer’s label

(with device’s serial number)

Front view

Back view

AutoGRAPH-ST •USER MANUAL

Internal view

Operation Mode LED

(red)

GPS/GLONASS LED

(green)

Power connector

Battery

GSM LED

(blue)

GPS / GLONASS

antenna

«Test» button

For more information see the

«Device Functions» section

SIM card holder

Insert SIM matching the key

displayed under the holder

Unscrew four fastening screws and remove the back cover of the device.

Remove device PCB from the case. The following components are on the

rear:

Micro USB

connector

Detailed information on LEDs’indication is given in the «AutoGRAPH-ST Indication» section of the User Manual.
