SETUP AND USER GUIDE
MediaConnect TG234
Copyright
Copyright ©1999-2015 Technicolor. All rights reserved.
Distribution and copying of this document, use and communication of its contents are not permitted without written authorization from
Technicolor. The content of this document is furnished for informational use only, may be subject to change without notice, and should not
be construed as a commitment by Technicolor. Technicolor assumes no responsibility or liability for any errors or inaccuracies that may
appear in this document.
TECHNICOLOR WORLDWIDE HEADQUARTERS
1-5 rue Jeanne d’Arc
92130 Issy les Moulineaux
France
http://www.technicolor.com
Trademarks
The following trademarks may be used in this document:
AutoWAN sensing™ is a trademark of Technicolor.
Qeo™ is a trademark of Qeo LLC, a subsidiary of Technicolor.
Adobe®, the Adobe logo, Acrobat® and Adobe Reader® are trademarks or registered trademarks of Adobe Systems, Incorporated,
registered in the United States and/or other countries.
Apple® and Mac OS® are registered trademarks of Apple Computer, Incorporated, registered in the United States and other countries.
Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.
CableLabs® and DOCSIS® are registered trademarks of CableLabs, Inc.
DECT™ is a trademark of ETSI.
DLNA® is a registered trademark, DLNA disc logo is a service mark, and DLNA Certified™ is a trademark of the Digital Living
Network Alliance. Digital Living Network Alliance is a service mark of the Digital Living Network Alliance.
Ethernet™ is a trademark of the Xerox Corporation.
EuroDOCSIS™, EuroPacketCable™ and PacketCable™ are trademarks of CableLabs, Inc.
HomePNA™ and HPNA™ are trademarks of HomePNA, Inc.
Linux™ is a trademark of Linus Torvalds.
Microsoft®, MS-DOS®, Windows®, Windows NT® and Windows Vista® are either registered trademarks or trademarks of the Micro-
soft Corporation in the United States and/or other countries.
MoCA® and the MoCA logo are registered trademarks of the Multimedia over Coax Alliance.
UNIX® is a registered trademark of UNIX System Laboratories, Incorporated.
UPnP™ is a certification mark of the UPnP Implementers Corporation.
Wi-Fi Alliance®, Wi-Fi®, WMM® and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. Wi-Fi CERTIFIED™, Wi-Fi
ZONE™, Wi-Fi Protected Access™, Wi-Fi Multimedia™, Wi-Fi Protected Setup™, WPA™, WPA2™ and their respective logos are trade-
marks of the Wi-Fi Alliance.
Other brands and product names may be trademarks or registered trademarks of their respective holders. All other logos, trademarks and
service marks are the property of their respective owners, where marked or not.
Document Information
Status: v1.0 (December 2015)
Reference: DMS3-CTC-25-221
Short Title: Setup and User Guide MediaConnect TG234 (R10.5.x)
i
Contents
DMS3-CTC-25-221 v1.0
About this Setup and User Guide..................................................................................1
1 Getting started.......................................................................................................... 2
1.1 Features at a glance ...................................................................................................................................3
1.2 Components .............................................................................................................................................. 4
1.2.1 Power ............................................................................................................................................................................... 5
1.2.2 Local network connection .............................................................................................................................................6
1.2.3 Buttons............................................................................................................................................................................. 8
1.2.4 Mode switch.................................................................................................................................................................... 9
1.2.5 Status LEDs .................................................................................................................................................................. 10
2 Setup ........................................................................................................................12
2.1 Set up the TG234 as access point.......................................................................................................... 13
2.2 Set up the TG234 as repeater ................................................................................................................14
2.3 Set up the TG234 as station ...................................................................................................................16
3 Configuration tools..................................................................................................18
3.1 Configure the TG234 via its GUI ..........................................................................................................19
3.1.1 Access the TG234 GUI...............................................................................................................................................20
3.1.2 GUI Components ........................................................................................................................................................ 22
3.1.3 Wireless settings configuration page ......................................................................................................................... 23
3.1.4 WPS configuration page .............................................................................................................................................26
3.1.5 The MAC address list.................................................................................................................................................. 27
3.1.6 Protecting access to the TG234................................................................................................................................. 28
3.1.7 Upgrading and restarting your TG234 ...................................................................................................................... 29
3.2 Configuring the TG234 via your Technicolor Gateway .....................................................................31
3.3 Connecting the TG234 directly to your device....................................................................................33
4 The TG234 wireless access point............................................................................ 36
4.1 Connecting via WPS................................................................................................................................37
4.2 Starting WPS on the TG234 GUI......................................................................................................... 39
4.2.1 WPS Push Button method (PBC)..............................................................................................................................40
4.2.2 WPS PIN method (PIN) ..............................................................................................................................................41
4.3 Connecting manually without WPS...................................................................................................... 42
4.4 Securing your wireless connection ........................................................................................................ 43
5 Support.................................................................................................................... 44
5.1 Setup troubleshooting ............................................................................................................................ 45
5.2 General TG234 troubleshooting........................................................................................................... 46
5.3 Wired connection troubleshooting ....................................................................................................... 47
5.4 Wireless connection troubleshooting ................................................................................................... 48
5.5 Reset to factory defaults......................................................................................................................... 50
1
About this Setup and User Guide
DMS3-CTC-25-221 v1.0
About this Setup and User Guide
In this Setup and User Guide
The goal of this Setup and User Guide is to show you how to:
Set up your MediaConnect TG234 and local network.
Configure and use the main features of your MediaConnect TG234.
Used Symbols
Terminology
Generally, the MediaConnect TG234 will be referred to as TG234 in this Setup and User Guide.
Typographical Conventions
Following typographical convention is used throughout this manual:
This sample text indicates a hyperlink to a website.
Example: For more information, visit us at www.technicolor.com.
This sample text indicates an internal link.
Example: If you want to know more about guide, see “About this Setup and User Guide” on page 1.
This sample text indicates an important content-related word.
Example: To enter the network, you must authenticate yourself.
This sample text indicates a GUI element (commands on menus and buttons, dialog box elements, file names, paths and
folders).
Example: On the File menu, click Open to open a file.
The danger symbol indicates that there may be a possibility of physical injury.
The warning symbol indicates that there may be a possibility of equipment damage.
The caution symbol indicates that there may be a possibility of service interruption.
The note symbol indicates that the text provides additional information about a topic.
2
1 Getting started
DMS3-CTC-25-221 v1.0
1 Getting started
Introduction
This chapter gives you a brief overview of the main features and components of the TG234. After this chapter we will start
with the installation.
In this chapter
This chapter covers the following topics:
Do not connect any cables to the TG234 until instructed to do so.
Topic Page
1.1 Features at a glance 3
1.2 Components 4
3
1 Getting started
DMS3-CTC-25-221 v1.0
1.1 Features at a glance
Real-time data and video bridge
The TG234 features a IEEE 802.11ac 5 GHz wireless interface with four transmitting and four receiving antennas (4x4) that
can be used as access point, repeater, station (client).
This makes it the ideal solution for transmitting HD video over wireless to other 4x4 IEEE 802.11ac 5 GHz wireless devices.
The TG234 supports up to four High Definition (HD) TV channels, and as such reduces wiring complexity within the entire
home.
Wireless Protected Setup (WPS)
The TG234 supports WPS. This means that you can easily connect the TG234 to other devices just by pressing a few
buttons. No need to enter lengthy and complex passwords!
TG234 advanced configuration
If you are a more advanced user and you want to further fine-tune the TG234 to your needs, you can use the TG234
Graphical User Interface (GUI) to configure your TG234 via your web browser. For more information, see “3.1 Configure the
TG234 via its GUI” on page 19.
Selected Technicolor gateways (for example, the Technicolor MediaAccess TG799vn v2) allow you to access and
configure the wireless settings of the TG234 via the MediaAccess Gateway GUI, instead of via the TG234 GUI.
For more information, see “3.2 Configuring the TG234 via your Technicolor Gateway” on page 31.
4
1 Getting started
DMS3-CTC-25-221 v1.0
1.2 Components
Overview
This section provides an overview of the different components of the TG234:
Topic Page
1.2.1 Power 5
1.2.2 Local network connection 6
1.2.3 Buttons 8
1.2.4 Mode switch 9
1.2.5 Status LEDs 10
5
1 Getting started
DMS3-CTC-25-221 v1.0
1.2.1 Power
Overview
Power inlet
The power inlet ()allows you to connect the power supply.
Power switch
The power switch ()allows you to power on/off your TG234.
TG234
Only use the power supply delivered with your TG234.
6
1 Getting started
DMS3-CTC-25-221 v1.0
1.2.2 Local network connection
Introduction
The TG234 provides your local network connection through:
5 GHz wireless access
Ethernet port
Wireless access point
The IEEE 802.11ac 5 GHz wireless access point adds 5 GHz wireless access to your home network, or allows to set up
wireless connections between different devices.
For more information, see “4 The TG234 wireless access point” on page 36.
Ethernet port
The Ethernet ports (GbE1 and GbE2) allow you to connect an Ethernet device to the wireless video bridge.
TG234
GbE2GbE1
This Ethernet port requires the use of a full-wired CAT-5(E) (or better) Ethernet cable (like the one that delivered
with your TG234) to guarantee network connectivity.
If you are not sure of your Ethernet cables, you can use the Ethernet cable that is delivered with your TG234.
7
1 Getting started
DMS3-CTC-25-221 v1.0
Each Ethernet port has a LED to indicate link integrity (or activity).
LED Colour State Description
Green Solid on Device connected
Blinking Device connected and sending/receiving data
Off No device connected
