Technica Engineering MEDIAGATEWAY Manual de usuario

Page 1of 63

BroadR-Reach –Standard Ethernet

MEDIAGATEWAY

User Manual

Version 4.2.98

March 2018

Page 2of 63

Changelog

Version 4.2.98 –March 2018

•Added ARL status

•MediaGateway Remote control revised

•Added SFP port information and new SFP Modules compatibility

•CANGateway Chapter updated

•Removed bootloader update chapter

You can download the latest firmware and documentation for the MediaGateway here:

http://www.technica-engineering.de/en/products/media-gateway/

IMPORTANT: Basic software is provided. Additional functionalities can be activated through

this email: order@technica-engineering.de

Page 3of 63

Contents

CHANGELOG .................................................................................................................................................... 2

CONTENTS ....................................................................................................................................................... 3

1. FEATURE LIST........................................................................................................................................... 5

2. WARRANTY AND SAFETY INFORMATION ................................................................................................. 6

3. PINNING .................................................................................................................................................. 7

POWER CONNECTOR (TOP LEFT) ..................................................................................................................................8

SWITCH CONNECTORS ...............................................................................................................................................9

RJ45 ETHERNET CONNECTORS ....................................................................................................................................9

SFP SLOT ................................................................................................................................................................9

4. STATUS LEDS AND PUSHBUTTON........................................................................................................... 10

LEDS...................................................................................................................................................................10

PUSH BUTTON........................................................................................................................................................10

5. CONFIGURATION WEBSITE .................................................................................................................... 11

WEBSITE HOME .....................................................................................................................................................12

SYSTEM INFORMATION TAB......................................................................................................................................12

CONTROL PANEL TAB ..............................................................................................................................................13

MEDIAGATEWAY FEATURE LICENSE ACTIVATION ..........................................................................................................14

SWITCH STATUS TAB...............................................................................................................................................15

Global Configuration .....................................................................................................................................15

ARL Table status............................................................................................................................................16

Dynamic ARL table ........................................................................................................................................17

Static ARL table .............................................................................................................................................17

Ports ..............................................................................................................................................................24

6. ETHERNET CAN GATEWAY (EXTRA LICENSE NEEDED) ............................................................................ 30

BASIC SETTINGS......................................................................................................................................................30

ADVANCED SETTINGS ..............................................................................................................................................30

ETHERNET CAN GATEWAY CONFIGURATION (UDPMODE): ...........................................................................................31

ETHERNET CAN GATEWAY CONFIGURATION (RAW MODE):...........................................................................................32

ETHERNET CAN GATEWAY SYNC FRAMES .......................................................................ERROR!BOOKMARK NOT DEFINED.

STRUCTURE OF A CAN/ETHERNET PACKET...................................................................................................................34

STRUCTURE OF A TIMESTAMP PACKET .............................................................................ERROR!BOOKMARK NOT DEFINED.

STRUCTURE OF A UDP PACKET /RAW FRAME:............................................................................................................35

7. 802.1AS ................................................................................................................................................. 36

PROTOCOL ............................................................................................................................................................36

Transport of time-synchronization information ............................................................................................36

Propagation delay measurement..................................................................................................................37

USING 802.1 AS ...................................................................................................................................................38

LIMITATIONS .........................................................................................................................................................39

8. VLAN CONFIGURATION ......................................................................................................................... 40

VLAN BASICS........................................................................................................................................................40

PORT-BASED VLAN................................................................................................................................................40

SINGLE TAGGING -IEEE 802.1Q (VLAN) MODE..........................................................................................................41

Single Tagging Example ................................................................................................................................43

DOUBLE TAGGING -IEEE 802.1Q (VLAN) MODE ........................................................................................................45

Double Tagging Example...............................................................................................................................48

9. MAC FILTERING FOR MIRRORING .......................................................................................................... 50

Page 4of 63

10. MEDIAGATEWAY REMOTE CONTROL ................................................................................................ 52

RESET DEVICE ........................................................................................................................................................53

IMPORT CONFIGURATION .........................................................................................................................................53

EXPORT CONFIG.....................................................................................................................................................54

DYNAMIC CONFIG ..................................................................................................................................................54

CHECK STATUS.......................................................................................................................................................55

SET WAKEUP LINE STATUS.......................................................................................................................................55

GET WAKEUP LINE STATUS ......................................................................................................................................55

PORT ENABLE (OABR)............................................................................................................................................56

PORT MASTER/SLAVE (OABR).................................................................................................................................56

RESET TO DEFAULT..................................................................................................................................................56

GET SYSTEM INFORMATION......................................................................................................................................57

11. HARDWARE VARIANTS...................................................................................................................... 58

BROADR-REACH ANALOG FILTER: .............................................................................................................................58

DEBUG CONNECTOR................................................................................................................................................58

STARTUP TIME.......................................................................................................................................................59

12. APPLICATION FIRMWARE UPDATE .................................................................................................... 60

13. FREQUENTLY ASKED QUESTIONS –FAQ ............................................................................................. 62

14. CONTACT..................................................................................... ERROR! BOOKMARK NOT DEFINED.

Page 5of 63

1. Feature List

The Technica Engineering MediaGateway has the following basicfeatures:

12 Ports Broadcom BroadR-Reach

100 MBit/s Fullduplex on a single unshielded twisted pair

3 Ports Gigabit Ethernet 10/100/1000 BaseTX Fullduplex

1 Port Gigabit Ethernet SFP module socket

✓Broadcom BroadR-Reach Technology

✓Tyco MQS Connectors for BroadR-Reach and Power Supply

✓Webserver for easy configuration:

Master / Slave

Port Mirroring

VLAN Tagging

Port Status Display

✓Import and Export of Configurations

✓WakeUp functionality

✓CAN, LIN and FlexRay interfaces (requires customer specific software)

✓Power output for attached devices: VBAT max. 1,2 Ampere in total (Fused)

✓19 Status LEDs

✓Possibility to reset to default settings by pushbutton

✓Robust steel case

Power requirement: 7 to 16 Volt DC (nominal 12 Volt DC) Power consumption: 7 to

12 Watt

Size: 195 x 143 x 33 mm

Weight: 0,77 kg

International Protection: IP 2 0

Operating Temperature: -40 to +80 °Celsius

Page 6of 63

2. Warranty and Safety Information

Before operating the device, read this manual thoroughly and retain it for your

reference.

You can download the latest firmware and documentation for the MediaGateway here:

http://www.technica-engineering.de/MediaGateway

Use the device only as described in this manual. Use only in dry conditions.

Do not apply power to a damaged device.

Do not open the device. Otherwise warranty will belost.

This device is designed for engineering purposeonly. Special care has to be taken for

operation.

Do not use this device in a series production car.

As this device is likely to be used under rough conditions, warranty is limited to 1

year.

Manufacturer liability for damage caused by using the device is excluded.

Page 7of 63

3. Pinning

The pinning of the ECU connectors is listed on the label on top of thedevice. The Tyco Electronics

(TE) Micro Quad Lock System (MQS) isused.

Name

Type

Part Number

Tyco, MQS Abdeckkappe

2x9 Pol, black

1-967416-1

Alternatively

1-1355350-1

Tyco, MQS Abdeckkappe

2x9 Pol, blue

3-967416-1

Tyco, MQS Buchsenge-

häuse

2x9 Pol

965778-1

Alternatively

962108-2

Tyco crimp contact

928999-1

Note: You can use the official Tyco tool for these crimp contacts. A cheap variant is the crimp

tool for “PSK” contacts.

Page 8of 63

Power connector (top left)

Connector color: Black

Power supply for the device is supplied by Pin 1 (12Volt) and Pin 2 (Ground). Requirements

for the MediaGateway itself: 12 Volt DC up to 1 Ampere (typical600mA)

If the 12 Volt camera power output is used, this current is also sourced of Pin 1 and2.

Warning: If you apply a voltage higher than 16 Volt, the device will bedamaged!

A wakeup-line may be connected on pin 7or 8. The wakeup-line should have the same voltage level

as the power supply (12 Volt). A high level on one of these pins wakes up the ECU from sleep mode

and keeps it active. If the voltage on this pin drops below approx. 6 Volt for more than about 3 seconds

the ECU will enter sleep mode. It will wake up on a high level again.

Alternatively the “Prevent sleep” checkbox in the control panel of the website can be enabled.

Note: Ethernet Traffic on any port will prevent sleep mode. Timeout is set to 100seconds.

The LIN interface on pin 9 can be used to communicate with the Microcontroller by LIN bus. In the

default software there is no data transmission specified. This interface may only be used in customer

specific software.

The FlexRay interface on pin 17 and 18 can be used to communicate with the Microcontroller

by FlexRay bus. In the default software there is no data transmission specified. This interface may

onlybe used in customer specific software.

Function

Battery +12 Volt Input

Wake Line 3 (Output only)

Ground Input

CAN E Plus

CAN C Plus

CAN E Minus

CAN C Minus

CAN D Plus

CAN A Plus

CAN D Minus

CAN A Minus

CAN B Plus

Wake Line 2

CAN B Minus

Wake Line 1

FlexRay Plus

LIN Bus

FlexRay Minus

Note: CAN interfaces may only be used in customer specific CAN-Gatewayfirmware.

Page 9of 63

Switch connectors

Connector color: Blue

The pins marked with (P) or (N) are used for the BroadR-Reach ports. Four ports are available

per switch.

You have to connect the (P) pin to the (P) pin of the peripherydevice. You have to connect the (N)

pin to the (N) pin of the peripherydevice.

Note: If you swap these two pins the link LED may be lit on the BroadR-Reach slave side, but

no data transmission will be possible.

The pins marked with (+) or (-) are 12 Volt power output pins. The actual voltage level of these pins

depends on the supply voltage of the ECU. Be aware that the sum of all 12 power output pairs will

deliver a maximum of 1.2 ampere. If more current is used the output will temporary switchoff.

The power output has to be switched on by website configuration (Controlpanel).

Function

Camera +12 Volt nominal output

BroadR-Reach Port 3, Positive

Camera Ground Output

BroadR-Reach Port 3,Negative

BroadR-Reach Port 2,Negative

Camera Ground Output

BroadR-Reach Port 2, Positive

Camera +12 Volt nominal output

n.c.

BroadR-Reach Port 1, Positive

Camera +12 Volt nominal output

BroadR-Reach Port 1, Negative

Camera Ground Output

Camera +12 Volt nominal output

BroadR-Reach Port 0,Negative

Camera Ground Output

BroadR-Reach Port 0, Positive

RJ45 Ethernet connectors

There are three RJ45 Standard Ethernet connectors of the frontside.

SFP slot

There is one SFP cage for a MiniGBIC module.

The following modules have been tested:

•Edimax Mini GBIC (SFP) LC, 1 Gigabit/s, 1000 Base-SX Module

•SFPEX S1GT-A Mini GBIC (SFP) 10/100/100 MBit RJ45 Module

•BEL SFP-1GBT-05 SFP 10/100/100 MBit RJ45 Module

Note: New SFP 100Base-T1 and 1000Base-T1modules are compatible with MediaGateway.

SFP 1000 Base-T1

SFP 100 Base-T1

Page 10 of 63

4. Status LEDs and Pushbutton

The MediaGateway has several status LEDs at the front side of the case.

LEDs

The “Host” LED can toggle at three different speeds:

•Slow toggle (approx. 0.5 sec) during normal operation to show that the microcontroller is

running in normal mode.

•Fast toggle (approx. 0.1 sec) when the microcontroller is in bootloader mode. The bootloader

mode is used for firmware update only (see below in this manual). You cannot access theweb-

site when the device is in bootloader mode.

•When the device is in Bootloader-Update Mode the LED toggles with moderate frequency (ap-

prox. 0.25 sec).

The port status LEDs Switch 1 to 3 and Port 3 to 0 monitors the link status of the corresponding port.

The LEDs are lit when there is BroadR-Reach link detected. They begin to blink when there is data

traffic on this link.

Note: There is an issue when P/N of the bus are swapped. The LED may be on in this

case on BroadR-Reach slave side, but there will be no data transmissionpossible.

The built-in LEDs in RJ45 connector shows the status of the gigabit ports. The left (orange LED) is

lit by a link-up. The right (yellow) will blink on datatraffic.

Push button

The Pushbutton on the left side of the case will reset all settings to factorydefault.

Pressing this button down for 5~6 seconds with a pen whe the Host Led is blinking normally:

•IP Address will be reset to default(192.168.0.49)

•All settings will be lost.

Note: If the device is blocked and all LEDs are lit, device must be sent to Technica

Engineering.

Note: MAC Address will not bechanged.

Otros manuales para MEDIAGATEWAY

Tabla de contenidos

Otros manuales de Puerta de Technica Engineering

Technica Engineering

Technica Engineering 1150 Manual de usuario

Technica Engineering

Technica Engineering MEDIAGATEWAY Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
