Technetix AIMA3000.RT5S Manual operacional

May/2016 - Version 1.0

AIMA3000.RT5S

1550 nm Return Transmitter - Standard

Product User Manual

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 2

AIMA3000.RT5S

1550 nm Return Transmitter - Standard

Product User Manual

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 3

Contents

1 About This Manual....................................................................................................................................................5

1.1 Chapter Overview ..................................................................................................................................................................................5

1.2 Related Documentation........................................................................................................................................................................5

1.3 Document Conventions........................................................................................................................................................................6

1.4 Technical Support...................................................................................................................................................................................6

2 Precautions.................................................................................................................................................................7

3 Overview.....................................................................................................................................................................8

3.1 Product Description ...............................................................................................................................................................................8

3.2 Product Key Features............................................................................................................................................................................9

3.3 Speciﬁcations...........................................................................................................................................................................................10

3.4 Block Diagram .........................................................................................................................................................................................12

3.5 Order Details............................................................................................................................................................................................13

4 Module Characteristics ............................................................................................................................................14

4.1 Module Appearance and Port Layout..............................................................................................................................................14

4.1.1 Overview ..........................................................................................................................................................................................14

4.1.2 Front Panel Layout ........................................................................................................................................................................15

4.1.3 Rear Panel Layout..........................................................................................................................................................................17

5 Installation ..................................................................................................................................................................19

5.1 Preparatory Work for Installation .......................................................................................................................................................19

5.2 Unpacking.................................................................................................................................................................................................19

5.3 Module Installation .................................................................................................................................................................................20

5.4 Connecting Optical Cables .................................................................................................................................................................21

5.4.1 Using the Sliding Fibre Guide....................................................................................................................................................21

5.4.2 Using the Fibre Tray......................................................................................................................................................................24

5.4.3 Cleaning the Fibre Connector Ends and Front-panel Optical Ports.............................................................................26

5.4.4 Connecting the Optical Fibres ..................................................................................................................................................27

5.5 Check Module LEDs..............................................................................................................................................................................27

5.6 Test the RF Input Signal........................................................................................................................................................................27

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 4

5.7 Test the Optical Output Signal............................................................................................................................................................27

5.8 RT5S Initial Setup....................................................................................................................................................................................29

6 Module Conﬁguration & Alarm setup....................................................................................................................32

6.1 Alarms Monitoring ..................................................................................................................................................................................32

6.1.1 Alarm Status Pages .......................................................................................................................................................................32

6.1.2 Module operating voltage and temperature alarm ............................................................................................................33

6.1.3 Module Port Alarms.......................................................................................................................................................................34

6.1.4 Alarm Monitoring Conﬁguration................................................................................................................................................35

6.1.5 Input / Output Status Monitoring...............................................................................................................................................36

6.2 Logs Management..................................................................................................................................................................................39

6.3 Device Upgrade......................................................................................................................................................................................40

6.4 Restoring Factory Defaults ..................................................................................................................................................................41

6.5 Reboot........................................................................................................................................................................................................43

7 Troubleshooting.........................................................................................................................................................44

8 Declaration of Conformity .......................................................................................................................................46

Appendix A: Default Alarm Limit Settings ...................................................................................................................47

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 5

1 About This Manual

1.1 Chapter Overview

1. About This Manual: Preface

2. Precautions

3. Overview: Application module overview, including the module features, technical speciﬁcations, and

ordering information.

4. Module Characteristics: The appearance of the equipment, port and introduction of other components

5. Installation: Installation procedure

6. Module Conﬁguration & Alarms: Web management conﬁguration instructions.

7. Troubleshooting

8. Product Warranty

9. Declaration of Conformity.

Appendix A: Default Alarm Limit Parameters

Appendix B: Factory Default Settings

1.2 Related Documentation

The following documents may be used in conjunction with this manual:

• Technetix.AIMA3000 - Product User Manual

• Technetix.AIMA ASMM - Product User Manual

• AIMA3000 NMS Web Management System Product User Manual

- Technetix.NMS3-EPSM - Basic Inventory Management

- Technetix.NMS3-EPSM - Basic Alarm Management

- Technetix.NMS3-EPSM - Basic System Management

- Technetix.NMS3-EPSM - Basic Template Management

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 6

1.3 Document Conventions

Before you use the manual, please familiarise yourself with the format used in this manual.

‘*’ Asterisk: Points marked with an asterisk means there is a corresponding note on the page

1.4 Technical Support

If you need help in the process of setting up and maintaining an RT5S, please contact Technetix’s technical

support sta:

Europe:

Technetix BV

Kazemat 5

NL-3905 NR Veenendaal

P.O. Box 385

NL-3900 AJ Veenendaal

The Netherlands

Phone: +31 318 58 59 59

Email: customer.service.[email protected]

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 7

2 Precautions

WARNING!

This equipment is intended for indoor applications. To prevent ﬁre or electrical shock, or

damage to the equipment, do not expose units to water or moisture.

• You should carefully read and thoroughly understand the contents of the manual before

installing and using this equipment.

• A typical connector is the SC/APC 8°. Note: An 8 ° angle polished optical connectors must

be used.

• At any time, there may be dangerous voltage inside the device.

• DO NOT power up before the cover and the panels of the equipment are installed and the

enclosure is closed.

Cleaning

Only use a damp cloth for cleaning the front panel. Use a soft dry cloth to clean the top of the unit.

DO NOT use any spray cleaners or chemicals of any kind.

Outage or overload requiring service and repairs

Unplug the unit and refer the servicing to Technetix qualiﬁed service personnel only.

Servicing and repairs

DO NOT attempt to service this unit yourself. Refer all servicing needs to Technetix qualiﬁed service

personnel only.

WARNING!

Exposure to class 3A laser radiation is possible. Access should be restricted to

trained personnel only. Do not view exposed ﬁbre or connector ends when handling

optical equipment.

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 8

3 Overview

3.1 Product Description

The RT5S, 1550 nm Return Transmitter - Standard series, is a high-density module with one or two lasers. It is designed

to plug into Technetix’s latest Advanced Intelligent Multi-services Access platform - the AIMA3000. Technetix RT5S is

currently available in either a single or dual transmitter conﬁguration. It features a full-spectrum advanced return path

transmitter designed for multi-service operators (MSOs) to increase network capacity to satisfy an ever-growing subscriber

demand for bandwidth. The module’s operating wavelength conforms to ITU standards and it can work with Technetix

Erbium Doped Fibre Ampliﬁer Module (EDFA). It provides the utmost ﬂexibility for MSOs during the transition to all-digital.

The RT5S employs an advanced RF circuit design and is available with either one or two high quality independent low-

chirp lasers. In addition, it has a cutting-edge optoelectronic design for the delivery of high-quality transmissions, over

passive ﬁbre optic networks.

All RT5S models can also be conveniently monitored and controlled through a computer connected to one of the Ethernet

ports via the ASMM module. All module settings are retained in non-volatile memory to ensure trouble-free operation. Bulk

updating, automatic uploading and Block Diagram downloading of conﬁguration ﬁles can be done when using Technetix

NMSE web-based management system.

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 9

3.2 Product Key Features

• Plug-and-play with the AIMA3000 platform

• High-quality 1550 nm isolated low-chirp analogue DFB lasers

• RF ampliﬁer gain blocks with advanced GaAs technology for better performance

• Conforms to ITU DWDM standards

• Frequency response of 5 MHz to 204 MHz

• Local laser shutdown via web interface

• Totally independent and controllable circuits in one module slot

• Alarm monitoring via ASMM web interface and Technetix NMSE

• Automatic thermo-cooler control (ATC) for a consistent laser temperature

• Automatic power control (APC) for maintaining a consistent amount of power ampliﬁcation for each wavelength

• Remote ﬁrmware upgrade and auto upload/download of conﬁguration ﬁles through the ASMM web interface or

using Technetix NMSE

• Bulk ﬁrmware updates through Technetix NMSE

• Fully FCC, CE and RCM ⁽¹⁾ compliant

(1) See Declaration of Conformity for current status.

AIMA3000.RT5S Product User Manual

Technetix Group Limited

[email protected] •technetix.comMay/2016 - Version 1.0 10

3.3 Speciﬁcations

Optical Performance

Optical wavelength ITU standard wavelength

Optical outputs 1 or 2

Output power 8 dBm, 9 dBm, 10 dBm

Optical connector SC/APC (1), LC/APC, FC/APC, E2000/APC

Laser RIN < -155 dB/Hz

RF Performance

RF bandwidth 5 MHz to 204 MHz

RF ﬂatness ± 0.5 dB

RF input return loss > 18 dB

RF nominal input level (2) 15 ~25 dBmV per channel

RF impedance 75 Ω

RF test point relative to RF input port -20 ±1 dB

Isolation between Transmitters > 60 dB

RF inputs connectors Single: 1 x GSK-type female

Dual: 2 x GSK-type female

RF test points Single: 2 x Mini-SMB (3)

Dual: 4 x Mini-SMB(4)

Alarms and laser status Front-panel LEDs, SNMP traps

Link Performance (5)

CNR > 53 dB

IMD2 < -60 dBc

General

Power supply Powered via AIMA3000 backplane

Power consumption Single: < 8.0 W

Dual: < 15.0 W

Operating temperature -5 ~ +55 oC

Operating humidity 90 % (Non-condensing)

Storage temperature -25 ~ +70 oC

Storage humidity 90 % (Non-condensing)

Dimensions (W*D*H) 24.6 mm * 410 mm * 152.5 mm

Weight 0.88 kg

Network management Technetix NMSE or through ASMM’s web interface
