TCL 8111 Series Manual de usuario

User Manual

8111 Series

2.1 Dolby Atmos Sound Bar

with Built-in Subwoofers

1

Contents

2Welcome

1Before you begin ................................................

............................................................. 4

3

What’s in the box .......................................................... 4

Overview of the Sound Bar .......................................... 6

Set up your Sound Bar system .................................... 8

8

9Mount your Sound Bar on the wall ...............................

Overview of the Remote Control ...................................

13Install/replace the remote control batteries....................

14

3Connect your Sound Bar system ..................... 16

Connect with the HDMI cable ...................................... 16

Connect with an optical cable ..................................... 20

Optional: Connect your Blu-ray player ........................ 18

Connect with a 3.5mm-to-3.5mm audio cable ............. 22

Connect your Sound Bar to power supply ................... 23

Connect the Sound Bar with your Bluetooth device .... 24

4 Use your Sound Bar system............................. 26

Use your Sound Bar with the top panel or remote

control ..........................................................................

26

Direction for setting up your Sound Bar using an

optical cable ..................................................................

21

Position Your Sound Bar ..............................................

2

31

6

5

Notice ................................................................. 32

Declaration of conformity ............................................. 32

Disposal of your old product and battery ..................... 32

Trademarks ................................................................... 34

7 FAQ ..................................................................... 35

Specifications ....................................................

Listen to music from your Bluetooth device ...............

29

Use the USB device for music playback ..................... 30

3

•

•

•

•

•

•

•

•

1 Before you begin

for your listening comfort.

as this may affect the performance.

4

2 Welcome

Congratulations on the purchase of your new TCL Sound Bar!

After it is set up and connected, you can experience a superb

sound quality and state-of-the-art design to best fit your

home entertainment system. You are recommended to read

through this user manual which helps you set up, connect

and operate the product easily and properly.

Let’s get started.

What’s in the box

AC power cord

AAA battery x 2Remote control

Sound Bar

5

Wall anchor x 2

Wall mount template

Wall mount bracket x 2

HDMI cable

QSG

Sleeve x 2

Safety

instructions

Safety leaflet

Quick Start Guide

Wall mounting screw x 2

AC IN

6

Overview of the Sound Bar

5

1 2 3 4

USB

7 8 9 10 12

~AC IN

1

Short press to enter Sleep or Standby mode.

Long press to enter Standby mode.

2

Press to switch the audio source among

HDMI ARC/HDMI IN/OPT/BT/AUX/USB modes.

3

Press to select the Bluetooth function. Press and hold

to enter the pairing mode.

HELLO

11

6

7

4

Press to increase or decrease the volume level.

5

6

LED indicator

It indicates the Sound Bar status (e.g. volume level,

sound bar status).

7AC input power connector

HDMI IN connector

HDMI OUT (ARC) connector

8

AUX input connector

9

Optical input connector

10

USB Type A connector

11

12

White LED:

It indicates standby/sleep (solid/blinking) mode.

8

Set up your Sound Bar system

Notes

Make sure you read all the safety information before

you mount the Sound Bar main unit on the wall.

TCL Overseas Marketing Limited bears no responsibility

for accidents or damage caused by improper wall mounting

and screws installation or insufficient wall strength, etc.

Additional tools (not supplied) are required for

installation.

Position Your Sound Bar

You are recommended to place the Sound Bar on the top of

the cabinet and right below the center of your TV.

TV

Make sure you use screws provided or specified by the

authorized manufacturer.

You can choose to place your Sound Bar on a cabinet

under your TV or mount it on the wall.

TV

1 Place the supplied wall mount template on the wall.

Make sure the wall mount template is at least 5cm

below the center of the TV.

2Use a level to make sure the wall mount template is

positioned accurately.

3

4 Mark on the wall using each marking on the template

through the mounting holes.

5Take away the wall mount template.

6Drill a screw hole at each marking on the wall.

9

Use the tape to stick the wall mount template firmly on

the wall.

Mount your Sound Bar on the wall
