Taylor RD30 Manual de usuario

OPERATOR’S 

MANUAL

Model RD30 and RC25

Remote Slush Freezer

11/99 (Original Publication)

(Updated 10/16/2020)

Original Operating Instructions

051060-M

Complete this page for quick reference when service is required:

Taylor Distributor: __________________________________________________________

Address:_________________________________________________________________

Phone: __________________________________________________________________

Service: _________________________________________________________________

Parts: ___________________________________________________________________

Date of Installation: ________________________________________________________

Information found on the data label:

Model Number: ___________________________________________________________

Serial Number: ____________________________________________________________

Electrical Specs: Voltage__________________ Cycle__________

Phase__________________________________

Maximum Fuse Size: ______________________________________________________ A

Minimum Wire Ampacity: ___________________________________________________ A

Note: Continuing research results in steady improvements. Therefore, information in this manual is subject

to change without notice.



Only instructions originating from the factory or its authorized translation representative(s) are considered to

be the original set of instructions.

051060-M

Any unauthorized reproduction, disclosure, or distribution of copies by any person of any portion of this work may be

a violation of Copyright Law of the United States of America and other countries, could result in the awarding of

Statutory Damages of up to $250,000 (17 USC 504) for infringement, and may result in further civil and criminal

penalties. 

Taylor Company

750 N. Blackhawk Blvd.

Rockton, IL 61072

Table of Contents

051060-M i

Section 1: To the Installer

Installer Safety ................................................................................................... 1-1

Site Preparation ................................................................................................. 1-1

Electrical Connections........................................................................................ 1-2

Beater Rotation .................................................................................................. 1-3

Refrigerant ......................................................................................................... 1-3

Setup Procedures .............................................................................................. 1-3

Section 2: To the Operator

Compressor Warranty Disclaimer ...................................................................... 2-2

Section 3: Safety

Section 4: Operator Parts Identification

Model RD30 ....................................................................................................... 4-1

Beater Door Assembly ....................................................................................... 4-2

Section 5: User Interface

Control Switch.................................................................................................... 5-1

Fill Switch........................................................................................................... 5-1

Mix Out Light...................................................................................................... 5-1

Viscosity Control ................................................................................................ 5-1

Section 6: Operating Procedures

Assembly............................................................................................................ 6-1

Sanitizing (Without Post Mix Valve) ................................................................... 6-5

Sanitizing (With Post Mix Valve) ........................................................................ 6-5

Priming (Without Post Mix Valve)....................................................................... 6-7

Priming (With Post Mix Valve)............................................................................ 6-8

Closing Procedure.............................................................................................. 6-8

Draining Product from the Freezing Cylinder ..................................................... 6-8

Rinsing ............................................................................................................... 6-8

Cleaning............................................................................................................. 6-9

Disassembly....................................................................................................... 6-9

Brush-Cleaning .................................................................................................. 6-9

Section 7: Operator Checklist

During Cleaning and Sanitizing.......................................................................... 7-1

Troubleshooting Bacterial Count........................................................................ 7-1

Regular Maintenance Checks............................................................................ 7-1

Winter Storage ................................................................................................... 7-2

ii 051060-M

Table of Contents

Section 8: Troubleshooting Guide

Section 9: Parts Replacement Schedule

Section 10: Limited Warranty on Equipment

Section 11: Limited Warranty on Parts

Section 1

1-1

Models RD30/RC25

To the Installer

The following information has been included in the

manual as safety and regulatory guidelines. For complete

installation instructions, please see the Installation

Checklist.

Installer Safety

IMPORTANT! In all areas of the world,

machines should be installed in accordance with existing

local codes. Please contact your local authorities if you

have any questions.

Care should be taken to ensure that all basic safety

practices are followed during the installation and

servicing activities related to the installation and service

of Taylor®machines.

• Only Taylor service personnel should perform

installation, maintenance, and repairs on Taylor

machines.

• Authorized service personnel should consult

OSHA Standard 29CFRI910.147 or the

applicable code of the local area for the industry

standards on lockout/tagout procedures before

beginning any installation or repairs.

• Authorized service personnel must ensure that

the proper personal protective equipment (PPE)

is available and worn when required during

installation and service.

• Authorized service personnel must remove all

metal jewelry, rings, and watches before

working on electrical equipment.

DANGER! The main power supply(s) to the

machine must be disconnected prior to performing any

installation, maintenance, or repairs. Failure to follow this

instruction may result in personal injury or death from

electrical shock or hazardous moving parts, as well as

poor performance or damage to the machine.

Note: All repairs must be performed by a Taylor service

technician.

WARNING! This machine has many sharp

edges that can cause severe injuries.

Site Preparation

Review the area the machine is to be installed in before

uncrating the machine, making sure that all possible

hazards the user or equipment may experience have

been addressed.

WARNING! Only install this machine in a

location where its use and maintenance is restricted to

trained personnel. Failure to comply may result in

personal injury.

For Indoor Use Only: This machine is designed to

operate indoors, under normal ambient temperatures of 

70°F to 75°F (21°C to 24°C). The freezer has

successfully performed in high ambient temperatures of

104°F (40°C) at reduced capacities.

WARNING! This machine must NOT be

installed in an area where a water jet or hose can be

used. NEVER use a water jet or hose to rinse or clean

the machine. Failure to follow this instruction may result

in electrocution.

CAUTION! This machine must be installed on

a level surface to avoid the hazard of tipping. Extreme

care should be taken in moving this machine for any

reason. Two or more persons are required to safely move

this machine. Failure to comply may result in personal

injury or damage to the machine.

The authorized installer should inspect the machine for

damage and promptly report any damage to the local

authorized Taylor distributor.

This machine is made using USA sizes of hardware. All

metric conversions are approximate and vary in size.

1-2

TO THE INSTALLER

Models RD30/RC25 To the Installer

Electrical Connections

IMPORTANT! In the United States, this

machine is intended to be installed in accordance with

the National Electrical Code (NEC), ANSI/NFPA 701987.

The purpose of the NEC code is the practical

safeguarding of persons and property from hazards

arising from the use of electricity. This code contains

provisions considered necessary for safety.

In all other areas of the world, the machine should be

installed in accordance with the existing local codes.

Please contact your local authorities if you have any

questions.

Each machine requires one power supply for each data

label on the machine. Check the data label(s) on the

machine for branch circuit overcurrent protection or fuse,

circuit ampacity, and other electrical specifications.

See the wiring diagram provided inside the electrical box

for proper power connections.

WARNING! This machine must be properly

grounded. Failure to do so can result in severe personal

injury from electrical shock.

IMPORTANT! An equipotential grounding lug is

provided with this machine. Some countries require the

grounding lug to be properly attached to the rear of the

frame by the authorized installer. The installation location

is marked by the equipotential bonding symbol (5021 of

IEC 60417-1) on both the removable panel and the

machine's frame.

WARNING! Avoid injury.

•DO NOT operate the machine unless it is

properly grounded.

•DO NOT operate the machine with fuses larger

than specified on the machine's data label.

• All repairs should be performed by an

authorized Taylor service technician.

• The main power supplies to the machine must

be disconnected prior to performing installation,

repairs, or maintenance.

•For Cord-Connected Machines: Only Taylor

service technicians or licensed electricians may

install a plug or replacement cord on the

machine.

• Machines that are permanently connected to

fixed wiring and for which leakage currents may

exceed 10 mA, particularly when disconnected

or not used for long periods, or during initial

installation, shall have protective devices to

protect against the leakage of current, such as a

GFI, installed by the authorized personnel to

local codes.

• Stationary machines that are not equipped with

a power cord and a plug or another device to

disconnect the appliance from the power source

must have an all-pole disconnecting device with

a contact gap of at least 0.125 in. (3 mm) in the

external installation.

• Supply cords used with this machine shall be 

oil-resistant, sheathed flexible cable not lighter

than ordinary polychloroprene or other

equivalent synthetic elastomer-sheathed cord

(code designation 60245 IEC 57) installed with

the proper cord anchorage to relieve conductors

from strain, including twisting, at the terminals

and protect the insulation of the conductors from

abrasion.

• If the supply cord is damaged, it must be

replaced by the manufacturer, service agent, or

a similarly qualified person to avoid a hazard.

• Secure supply cord ground lead to machine in a

location where if the cord is pulled the main

power leads become taut before the ground

lead can break loose.

Failure to follow these instructions may result in

electrocution. Contact your local authorized Taylor

distributor for service.

FOLLOW YOUR LOCAL ELECTRICAL CODES.

TO THE INSTALLER

1-3

Models RD30/RC25

To the Installer

Beater Rotation

NOTICE! Beater rotation must be clockwise as

viewed looking into the freezing cylinder.

To correct the rotation on a three-phase machine,

interchange any two incoming power supply lines at the

freezer main terminal block only. To correct rotation on a

single-phase machine, exchange leads inside the beater

motor. (Follow the diagram printed on the motor.)

Electrical connections are made directly to the terminal

block provided in the main control box located behind the

service panel.

It is recommended that beater rotation adjustment be

performed by a Taylor service technician.

Refrigerant

CAUTION! This machine contains fluorinated

greenhouse gases (F-Gas) to provide refrigeration using

a hermetically sealed circuit or within foam insulation.

This machine’s type of gas, quantity, Global Warming

Potential (GWP), and CO2tonnes equivalent information

is recorded on the machine’s data label. The refrigerant

used is generally considered nontoxic and

nonflammable. However any gas under pressure is

potentially hazardous and must be handled with caution.

NEVER fill any refrigerant cylinder completely with liquid.

Filling the cylinder approximately 80% will allow for

normal expansion.

CAUTION! Use only approved refrigerant

listed on the machine's data label or authorized through a

manufacturer's technical bulletin. The use of any other

refrigerant may expose users and operators to

unexpected safety hazards.

WARNING! Refrigerant liquid sprayed onto the

skin may cause serious damage to tissue. Keep eyes

and skin protected. If refrigerant burns should occur,

flush the area immediately with cold water. If burns are

severe, apply ice packs and contact a physician

immediately.

NOTICE! Taylor reminds technicians to be

aware of and in compliance with local government laws

regarding refrigerant recovery, recycling, and reclaiming

systems. For information regarding applicable local laws,

please contact your local authorized Taylor distributor.

IMPORTANT! Refrigerants and their

associated lubricants may be extremely moisture

absorbent. When opening a refrigeration system, the

maximum time the system is open must not exceed 15

minutes. Cap all open tubing to prevent humid air or

water from being absorbed by the oil.

Refrigeration Charging and Line

Construction

The dispensing machine is shipped with a refrigerant

holding charge that is sufficient enough to prevent

moisture contamination (8 oz. [227 g] R404A). This

holding charge will become part of the total system

charge.

The condensing unit is shipped with the total amount of

refrigerant required for a typical installation of 75 ft.

(22.86 m) or less with a single dispenser.

1-4

TO THE INSTALLER

Models RD30/RC25 To the Installer

Setup Procedures

Standard Fill Module

1. Connect the product supply line to the 1/4 in. barbed

fitting on the fill module. Adjust the fill system

pressure to deliver product to the hopper at 1.5 oz. to 

2.5 oz. (42.5 g to 70.9 g) per second. (Approximately

15 PSIG to 20 PSIG [103 kPa to 138 kPa] for most

products.)

2. Lubricate, assemble, sanitize, and prime the

dispenser as outlined in “Assembly” on page 6-1.

3. Place the fill switch in the FILL position. Allow the

product to fill the cylinder and the hopper until the mix

level float is satisfied.

4. Place the control switch in the AUTO position.

5. To observe the suction pressure, attach refrigeration

gauges to the suction access fitting in the dispenser.

Pressures should read approximately 32 psi. 

(221 kPa) for non-alcoholic application and 28 psi.

(193 kPa) for alcoholic application.

Note: Connection to the condensing unit suction

access can give an improper reading.

6. Allow the dispenser to run until the condensing unit

cycles off.

7. If necessary, adjust viscosity to produce satisfactory

product. Adjustments are made by turning the

viscosity adjustment screw (located on the front

panel) clockwise for a thicker product or

counterclockwise for a thinner product.

Machines Equipped with Post Mix Valve

1. Connect syrup and water lines.

Note: Adjust the syrup supply pressure to maintain

60 PSIG. Water pressure between 40 PSIG and 100

PSIG may require regulated water supply.

2. Turn the fill switch in the front of the RD30 to the FILL

position.

3. Press and hold the area on the front of the post mix

valve marked PUSH to prime the fill system. Priming

is required until the BIB switch and the float switch

are both satisfied. Priming is complete when product

will flow without pressing the PUSH button.

4. To adjust either the syrup or water flow rate, turn the

flow adjustment screw clockwise to increase flow, or

counterclockwise to decrease flow. Adjust the screws

until the desired brix is obtained. The flow rate should

be 1.5 oz. to 2.5 oz. (43 mL to 74 mL) per second.

Note: Both syrup and water flow adjustment screws

are located inside the post mix valve cover. Viewed

from the front, the syrup adjustment screw is on the

right and water adjustment is on the left.

Section 2

2-1

Models RD30/RC25

To the Operator

The freezer you have purchased has been carefully

engineered and manufactured to give you dependable

operation. The Taylor Model RD30/RC25, when properly

operated and cared for, will produce a consistent quality

product. Like all mechanical products, this machine will

require cleaning and maintenance. A minimum amount of

care and attention is necessary if the operating

procedures outlined in this manual are followed closely.

IMPORTANT! This manual should be read

before operating or performing any maintenance on the

machine.

Your Taylor machine will NOT compensate for and/or

correct any errors made during the setup or filling

operations. Thus, the initial assembly, setup, and priming

procedures are of extreme importance. It is strongly

recommended that all personnel responsible for the

machine's operation, including assembly and

disassembly, go through these procedures together in

order to be properly trained and to make sure that all

personnel understand their role in using and maintaining

the machine.

In the event you should require technical assistance,

please contact your local authorized Taylor distributor.

Note: Your Taylor warranty is valid only if the parts are

authorized Taylor parts, purchased from the local

authorized Taylor distributor, and only if all required

service work is provided by a Taylor service technician.

Taylor reserves the right to deny warranty claims on units

or parts if unapproved parts or incorrect refrigerant were

installed in the unit, system modifications were performed

beyond factory recommendations, or it is determined that

the failure was caused by abuse, misuse, neglect, or

failure to follow all operating instructions. For full details

of your Taylor warranty, please see the Limited Warranty

section in this manual.

Note: Constant research results in steady

improvements. Therefore, information in this manual is

subject to change without notice.

IMPORTANT! If the crossed-out wheeled-bin

symbol is affixed to this machine, it signifies that this

machine is compliant with the EU Directives as well as

other similar end-of-life legislation in effect after August

13, 2005. Therefore, it must be collected separately after

its use is completed and cannot be disposed as unsorted

municipal waste.

The user is responsible for delivering the machine to the

appropriate collection facility, as specified by your local

code.

For additional information regarding applicable local

disposal laws, please contact the municipal waste facility

and/or local authorized Taylor distributor.

2-2

TO THE OPERATOR

Models RD30/RC25 To the Operator

Compressor Warranty Disclaimer

The refrigeration compressor(s) on this unit are

warranted for the term stated in the Limited Warranty

section in this manual. However, due to the Montreal

Protocol and the U.S. Clean Air Act Amendments of

1990, many new refrigerants are being tested and

developed, thus seeking their way into the service

industry. Some of these new refrigerants are being

advertised as drop-in replacements for numerous

applications. It should be noted that in the event of

ordinary service to this unit’s refrigeration system, only

the refrigerant specified on the affixed data label

should be used. The unauthorized use of alternate

refrigerants will void your Taylor compressor warranty. It

is the unit owner’s responsibility to make this fact known

to any technician he/she employs.

It should also be noted that Taylor does not warrant the

refrigerant used in its equipment. For example, if the

refrigerant is lost during the course of ordinary service to

this machine, Taylor has no obligation to either supply or

provide its replacement either at billable or unbillable

terms. Taylor does have the obligation to recommend a

suitable replacement if the original refrigerant is banned,

obsoleted, or no longer available during the five-year

warranty of the compressor.

Taylor will continue to monitor the industry and test new

alternates as they are being developed. Should a new

alternate prove, through our testing, that it would be

accepted as a drop-in replacement, then the above

disclaimer would become null and void. To find out the

current status of an alternate refrigerant as it relates to

your compressor warranty, call the local Taylor distributor

or the Taylor factory. Be prepared to provide the 

model/serial number of the machine in question.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Dispensador de bebidas de Taylor

Taylor

Taylor 432 Manual de usuario

Taylor

Taylor C302NP Manual de usuario

Manuales populares de Dispensador de bebidas de otras marcas

PEGAS

PEGAS Evolution Manual de usuario

Ugolini

Ugolini MT micro Manual de usuario

Bunn

Bunn SLCA-7 Instrucciones de instalación

Gekkeikan

Gekkeikan Sake Machine Manual de usuario

Olympia

Olympia DH709 Manual de usuario

Marco

Marco ECOSMART PB10 Manual de usuario

Marvel

Marvel ML24BN Series Manual

Cecilware

Cecilware 2K-GB-LD Manual

Sure Vend

Sure Vend 673 Manual de usuario

Cornelius

Cornelius 2 Flavor Post-Mix Cold Coffee Dispenser Quest... Manual de usuario

Nostalgia Electrics

Nostalgia Electrics KEG7000SS Manual de usuario

Bunn

Bunn LCR-3 HV Guía de solución de problemas

Servend

Servend SV-200 Manual de usuario

EdgeStar

EdgeStar VBR440 Manual de usuario

Cornelius

Cornelius A.B.S. Unit Manual de usuario

CDS AUTOMATEN

CDS AUTOMATEN ML-16C2-C Manual de usuario

Siemens

Siemens GA 3000 Manual de instrucciones y seguridad

Cornelius

Cornelius FCB V4 Especificaciones
