Visit our Website at www.targus.com

Features and specications subject to change without

notice.

PA410U-10 / 410-0014-001B

USER GUIDE

notebook security

DEFCON®CL

cable lock

Table of Contents

Introduction ...................................................... 3

Setting the Combination................................... 4

Securing the DEFCON CL ............................... 5

Locking the DEFCON CL to your Notebook Com-

puter................................................................. 6

Using the DEFCON SecureSpacers ................ 8

Unlocking the DEFCON CL ............................. 9

DEFCON Security Base Plate ......................... 9

Specifications.................................................. 11

Technical Support ........................................... 12

Recording Your Combination.......................... 13

TARGUS NOTEBOOK

SECURITY

DEFCON

CL COMBO

CABLE LOCK

Introduction

Thank you for purchasing the Targus Notebook Security

DEFCON®CL Combo Cable Lock. The DEFCON CL

helps protect your valuable notebook computer from theft

using a resettable four-digit combination lock. The

resettable combination lock eliminates the need for keys

and enables you to change your combination periodically

for increased security.

In addition to this user’s guide, this package contains:

• DEFCON CL

• DEFCON SecureSpacers

• DEFCON Security Base Plate

WARNING: TOUSE THE DEFCON CL OR RESET THE COMBINATION YOU

MUST SET THE LOCK TO THE CURRENT COMBINATION.

Targus Notebook Security DEFCON® CL Combo Cable Lock

Setting the Combination

1 Locate the combination dials and windows on the

lock.

DEFCON CL

2 Using the dials, enter the current combination.

If you are setting the combination for the first time,

enter the preset combination 0000.

The combination appears in the windows.

3 Using a small flat-head screwdriver or similar object,

push in and rotate the reset screw 90 degrees

clockwise so that the screw’s groove appears

horizontal.

Unlocking the combination lock

Combination windows Reset screw

Combination dials

Locking button

Targus Notebook Security DEFCON® CL Combo Cable Lock

4 Using the dials, enter the new combination.

5 Rotate the reset screw 90 degrees counterclockwise,

back to its original vertical position, to save the new

combination.

Locking the combination lock

6 Record the combination in either the space provided

at the end of this guide or another secure, easy-to-find

place.

Testing the Combination

Before attaching the lock to your notebook computer:

1 Turn the dials to disguise the combination.

2 Return to the combination you set.

3 Check that the locking button depresses completely.

Securing the DEFCON CL

Select an object in the room to which you will secure your

notebook computer with the DEFCON CL. Choose a

large, heavy piece of furniture such as a table or desk, or

an immovable fixture such as a closet hanging bar.

Targus Notebook Security DEFCON® CL Combo Cable Lock

1 Take the looped end of the cable and wrap it around

the selected object.

NOTE: WRAP THE CABLE AROUND APART OF THE OBJECT THAT WILL DETER

AN INTRUDER FROM SLIPPING THE CABLE OFF (FOR EXAMPLE, ATABLE OR

DESK LEG WITH ACROSS BAR OR ADRAWER HANDLE).

2 Feed the lock through the looped end of the cable as

shown.

Securing the DEFCON CL to an object

Locking the DEFCON CL to

your Notebook Computer

NOTE: HOLD THE DEFCON CL WITH BOTH HANDS FOR ADDITIONAL

STABILITY WHILE INSERTING OR REMOVING THE LOCK.

1 Using the dials, enter the correct combination.

The combination appears in the windows.

Targus Notebook Security DEFCON® CL Combo Cable Lock

DEFCON CL

2 Press and hold the locking button to align the locking

teeth.

NOTE: FOR THE LOCKING BUTTON TO DEPRESS COMPLETELY YOU MUST

ENTER THE CORRECT COMBINATION.

3 Insert the DEFCON CL into your notebook computer’s

lock slot and release the locking button.

NOTE: DUE TO THE VARIATION IN THE SIZE OF THE SECURITY SLOTS ON

VARIOUS NOTEBOOK MODELS, YOU MAY FIND THAT THERE IS SOME SLACK

BETWEEN THE LOCK AND THE COMPUTER. THE SUPPLIED DEFCON

SECURESPACERS ARE THE BEST SOLUTION FOR OPTIMAL FIT AND SECURITY.

4 Turn the dials to conceal your combination.

Due to differences in the size of the security slots on

various notebook computers, you may find that there

is some slack between the DEFCON locking device

and the computer. The DEFCON SecureSpacers

provide optimal fit and security.

Locking button

Locking teeth

SecureSpacer

Targus Notebook Security DEFCON® CL Combo Cable Lock

Using the DEFCON

SecureSpacers

1 Insert your DEFCON locking device into the

computer’s lock slot.

2 Pull the DEFCON locking device away from the

computer and check whether the gap is excessive.

3 If so, try each of the SecureSpacers to determine

which one fits the gap. The SecureSpacers come in

three sizes: 1.6 mm, 0.8 mm, and 0.4 mm.

NOTE: DONOT REMOVE THE ADHESIVE STRIP FROM ANY OF THE

SECURESPACERS UNTIL YOU DECIDE WHICH ONE TO USE.

4 Once you know which SecureSpacer you are going to

use, remove the locking device from the computer.

Targus Notebook Security DEFCON® CL Combo Cable Lock

Then remove the adhesive strip from the back of the

SecureSpacer and attach the spacer to the DEFCON

lock.

Unlocking the DEFCON CL

WARNING: DONOT ATTEMPT TO REMOVE THE DEFCON CL WITHOUT USING

THE COMBINATION. TODO SO WILL PHYSICALLY DAMAGE YOUR NOTEBOOK

COMPUTER.

1 Using the dials, enter the correct combination.

2 The combination appears in the windows.

3 Press and hold the locking button to realign the

locking teeth.

4 Remove the DEFCON CL from your notebook

computer’s lock slot.

DEFCON Security Base

Plate

Included with your DEFCON CL Combo Cable Lock is

the Security Base Plate for the security of desktop

computers.

Using the DEFCON Security Base

Plate

1 Choose a solid location to attach the DEFCON

Security Base Plate: a piece of furniture, or metal

Targus Notebook Security DEFCON® CL Combo Cable Lock

cabinet. If you plan to use the two screws, you can use

the base plate as a template to pre-drill the holes.

2 Use the abrasive pad, then the alcohol wipe to

prepare the area when you will attach the DEFCON

Security Base Plate.

3 After the alcohol dries, remove the backing on the

base plate to expose the adhesive and place it on the

prepared location. If desired, secure the base with the

two screws.

NOTE: WHEN USING THE ADHESIVE BACKING, APPLY AT ROOM TEMPERATURE

-60°F (16°C), AND ALLOW IT TO BOND FOR MORE THAN 24 HOURS. NOT

RECOMMEND TO USE IN OUTDOOR OR HIGH HUMIDITY ENVIRONMENT.

BONDING TO GLASS, CERAMIC TILE, WATER-ABSORBENT MATERIALS, COPPER,

BRASS, OR PLASTICIZED VINYL WITHOUT PRIMER SURFACE ARE NOT
