Tangent Ampster TV II Manual de usuario
Ampster TV II
Mini stereo amplifier
User’s manual
Brugermanual
Mode d’emploi
Bedienungsanleitung
Bruksanvisning
Käyttöopas
Manual del usuario
Brukermanual
(UK)
Amplier:
1. Power Indicator
2. TV Input Indicator
3. Bluetooth Input Indicator
4. Remote Sensor
5. Volume Knob/Input Selector
6. Antenna
7. HDMI Input
8. SUB Out
9. Speaker Output -&+ L&R
10. Power Input
11. On/O Switch
Including in the package:
Remote Control
Instruction Manual
67
78
9
10
13
11
6
1 2 3
45
1. On/O Button
2. BT pair
3. Volume +/-
4. Previous/Next (BT mode)
5. Play/Pause (BT mode)
6. Treble +
7. Treble -
8. Mode
9. Bass +
10. Bass -
1. Connect the power cord to the back of the
amplier then connect it to a wall outlet.
2. Connect your TV with a HDMI cable,
remember to select the HDMI ARC/CEC on your TV.
(only works on compatible TV’s)
3. Turn the power button to the On position, after two
seconds the unit will enter working status and the
input indicator will lit up.
4. Press the Mode on the remote or push the volume
knob to choose between TV or BT source.
Note: The amplier will shut o automatically if the
temperature exceeds 85°C, to indicate this the Power
indicator will turn orange. The amplier will re-start
automatically when the temperature has dropped
below 60±10°C.
Bluetooth Pairing:
1. Choose Bluetooth input on the remote (or push the
selector button) to activate the Bluetooth source.
2. Activate Bluetooth on your phone/tablet and
start searching for new Bluetooth devices.
3. When your phone/tablet nds the Tangent
Ampster TV II, choose this unit and begin pairing up.
(You can force the Ampster TV II into pairing mode, with a press on BT pair)
Remote control: Connect:
(UK)
2
1
3
8
6
7 10
9
454
Connect your speakers:
Connect your loudspeakers to the Speaker
Output.
Connect the -/black from left loudspeaker
to the -/black left input.
And connect the +/red from left loud-
speaker to the +/red left input.
Connect the -/black from right loudspeak-
er to the -/black right input.
And connect the +/red from right loud-
speaker to the +/red right input.
Connect your subwoofer to SUB out.
Note:
Remember to change into the desired
input source on the amplier.
(UK)
EQ Setting:
Treble + = Push button to increase treble,
with 2dB each time. (max.8dB)
Treble - = Push button to decrease treble,
with 2dB each time. (max.8dB)
Bass + = Push button to increase bass,
with 2dB each time. (max.8dB)
Bass - = Push button to decrease bass,
with 2dB each time. (max.8dB)
Reset EQ: Long press (2-3sec) on MODE/EQ reset and
it will reset the EQ settings.
Each time that you adjust or reset, you can see the standby LED
make a conrmation blink.
Button/Indicator Function
Power/Standby indicator
Power: Power on-The product in power o status, then push the power source button on rear panel at
“ON” position the LED indicator blinks one time and the startup sound from electric relay in the unit,
after about 2 seconds the amplier will be in working status.
Power o:
Push the power source button at “OFF” position, then the close sound from the electric relay and unit
go into power o status.
Standby:
Press the standby button on the remote control, or push the Volume/selector button (3-4sec).
Then the unit will go into standby, and the standby LED will be red color. The unit is in standby status.
(When the Ampster TV II goes into auto standby when inactive (no signal) in 15min, you can wake it up via blue-
tooth signal).
Power on (from standby mode):Press standby on the remote control or push the Volume/selector button.
And after about 2 seconds the amplier will be in last time working status before standby.
In TV mode using HDMI arc/cec, the Ampster TV II will power ON & OFF when you turn your TV on &
o.
Bluetooth input indicator
When Bluetooth mode is selected indicator lights. Solid when connected to a device and ashing when
in pairing mode.
Volume and input switch button
This selector can adjust volume (turn left or right) and also switch the input mode (push)
(For standby push and hold the button)
In TV mode using HDMI arc/cec, the volume is controlled by your TV.
(UK)
Important Safety Instructions:
To reduce the risk of electrical shock, fire, etc.:
1. Do not place unit near any heat source such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
2. Do not block any ventilation openings of unit.
3. The unit shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the unit.
4. Do not place any heavy loads onto the unit, and do not step on it, the load may fall and cause serious injury to the unit.
5. Never unplug your unit by pulling on the power cord. Always grap the plug firmly and pull straight out from the outlet.
6. Repair or replace all electric service cords that have become frayed or otherwise damaged immediately. Do not use a cord that
shows cracks or abrasion damage along its length, the plug, or the connector end.
7. To prevent fire or shock hazard, do not expose unit to rain or moisture.
8. During lightning or raining days, unplug the unit for additional protection dur ing thunderstorms or when the unit is not used
for prolonged periods. This will prevent damage to the unit from lightning and power surges.
9. Do not attempt to carry out any service work yourself. By opening or removing the cabinet, you may be exposed to dangerous
voltage or other hazards. Any service work should be carried out by qualified technicians.
10. In the interests of safety and to avoid unnecessary energy consumption, never leave the unit switched on while unattended for
long periods of time, e.g. overnight, while on holiday or while out of the house. Switch it off and disconnect the mains plug
from the mains socket.
11. Clean only with dry cloth
12. Please pay attention to the environmental aspects of battery disposal. Battery must be recycled or disposed of properly. This
product must not be disposed together with the domestic waste. This product has to be disposed at an authorized place for
recycling of electrical and electronic appliances. By collecting and recycling waste, you help save natural resources, and make
sure the product is disposed in an environmental friendly and healthy way.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG,. Inc. and any use of such marks is
under license. Other trademarks and trade
names are those of their respective owners.
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end of its
life separately from your household waste.There are separate collection
systems for recycling in the EU. For more information, please contact
the local authority or your retailer where you purchased the product.
(UK)
(DK)
Forstærker forside/bagside:
1. Strømindikator
2. Indikator for tv-indgang
3. Indikator for Bluetooth-indgang
4. Fjernbetjeningssensor
5. Lydstyrkeknap/indgangsvælger
6. Antenne
7. HDMI-indgang
8. SUB-udgang
9. Højttalerudgang -&+ L&R
10. Strømindgang
11. Tænd/sluk-kontakt
Inkluderet i pakken:
Fjernbetjening
Instruktionsbog
67
78
9
10
13
11
6
1 2 3
45
(DK)(UK)
1. Tænd/sluk-knap
2. BT-parring
3. Lydstyrke +/-
4. Forrige/næste(BT-mode)
5. Afspil/pause(BT-mode)
6. Diskant +
7. Diskant -
8. Tilstand
9. Bas +
10. Bas -
1. Tilslut netledningen til bagsiden af forstærkeren
og tilslut den til en stikkontakt.
2. Tilslut dit TV med et HDMI-kabel,
Husk at vælge HDMI ARC/CEC på dit TV.
(Virker kun på kompatible TV)
3. Drej tænd/sluk-knappen til positionen On, efter to
sekunder vil enheden gå i driftsstatus, og input-
indikatoren vil lyse op.
4. Tryk på Mode på fjernbetjeningen, eller tryk på
volumenknappen for at vælge mellem TV eller BT-
kilde.
Bemærk: Forstærkeren slukker automatisk, hvis temperaturen over-
stiger 85 °C. For at indikere dette bliver strømindikatoren orange.
Forstærkeren genstarter automatisk, når temperaturen er faldet til
under 60±10°C.
Bluetooth parring:
1. Vælg Bluetooth-indgang på fjernbetjeningen (eller
tryk på valgknappen) for at aktivere Bluetooth-kilden.
2. Aktivér Bluetooth på din telefon/tablet, og begynd at
søge efter nye Bluetooth-enheder.
3. Når din telefon/tablet nder Tangent Ampster TV II,
skal du vælge denne enhed og begynde at parre den.
(Du kan tvinge Ampster TV II i parringstilstand med et tryk på BT pair)
Fjernbetjening: Tilslut:
2
1
3
8
6
7 10
9
454
(DK)
Tilslut dine højttalere:
Tilslut dine højttalere til højtalerudgangen.
Tilslut den negative (sorte) ledning fra ven-
stre højttaler til den negative (sorte) vens-
tre indgang.
Og tilslut den positive (røde) ledning fra
venstre højttaler til den positive (røde) ven-
stre indgang.
Tilslut den negative (sorte) ledning fra
højre højttaler til den negative (sorte) højre
indgang.
Og tilslut den positive (røde) ledning fra
højre højttaler til den positive (røde) højre
indgang.
Tilslut din subwoofer til SUB-udgangen.
Bemærk:
Husk at skifte til den ønskede indgangskilde
på forstærkeren.
EQ-indstilling:
Treble + = Tryk på knappen for at øge diskant med 2 dB ad
gangen. (maks. 8 dB)
Treble - = Tryk på knappen for at mindske diskant med 2 dB
ad gangen. (maks. 8 dB)
Bass + = Tryk på knappen for at øge bas med 2 dB ad gan
gen. (maks. 8 dB)
Bass - = Tryk på knappen for at mindske bas med 2 dB ad
gangen. (maks. 8 dB)
Nulstil EQ: Hold MODE/EQ reset-knappen nede i 2-3 sekunder,
og det vil nulstille EQ-indstillingerne.
Hver gang du justerer eller nulstiller, vil standby-LED’en blinke
som en bekræftelse.
