Tanaka ECS-3351/B Guía de configuración

IllustrIllustr

Illustraa

ated Pted P

ted Pted P

ted Parar

arar

arts Mants Man

ts Mants Man

ts Manualual

ualual

ual

Model Number:

ECS-3351/B

32cc CHAINSAW

P/N 40167

Rev 000

Date 4-02-08

Nikko Tanaka Engineering U.S.A.,Ltd.• 1028 4th Street SW, Bldg B • Auburn, WA98001 • Phone: (253) 333-1200 • Fax: (253) 333-1212

www.tanakapowerequipment.com [email protected]

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

ECS-3351

Page 1

CYLINDER, PISTON, CRANKSHAFT & IGNITION • FIGURE 1

ITEM PART NUMBER DESCRIPTION QTY COMMENTS

1-1 15711666900 CAP,SPARK PLUG 1

1-2 01801805200 PLUG,SPARK 1

1-6 0010174090 CYLINDER SET 1 ~U016860

1-6 0010174091 CYLINDER SET 1 U016861~

1-7 99461050164 BOLT,HEX,5X16,S 4

1-9 0170174020 GASKET,CYLINDER 1

1-10 04101730200 RING,PISTON 2

1-11 0300174090 PISTON SET 1 ~U016860

1-11 0300174190 PISTON SET 1 U016861~

1-12 03701400200 PIN,PISTON 1

1-13 03900000201 CIRCLIP,PISTON PIN 2

1-16 0460174080 CRANKSHAFT 1

1-17 99962091325 BEARING,NEEDLE,F-910 1

1-18 06810100200 KEY,WOODRUFF,3X13X4.5 1

1-31 99416040186 SCREW,WS,4X18 2

1-34 20501700200 TAB,TERMINAL 1

1-35 1672152980 COIL,IGNITION 1 ~U016860

1-35 1672154080 COIL,IGNITION 1 U016861~

1-66 75532050200 TUBE,CORD 1

1-75 1780174080 CORD,STOP 1

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

ECS-3351

Page 2

CRANKCASE / FLYWHEEL • FIGURE 2

ITEM PART NUMBER DESCRIPTION QTY COMMENTS

2-19 0710406321 SHIM,CRANKSHAFT,0.1 1

2-19 0710406323 SHIM,CRANKSHAFT,0.2 1

2-19 0710406324 SHIM,CRANKSHAFT,0.3 1

2-19 0710406325 SHIM,CRANKSHAFT,0.4 1

2-21 06600000200 NUT,FLYWHEEL 1

2-22 99210070012 WASHER,S,7 1

2-23 99201070011 WASHER,7 1

2-24 1552152991 ROTOR,MAGNETO 1 ~U016860

2-24 1552154090 ROTOR,MAGNETO 1 U016861~

2-26 7880174020 PAWL,STARTER 2

2-27 7900174020 SPRING,STARTER PAWL 2

2-28 99355040001 RING,STOP 2

2-36 99461050204 BOLT,HEX,HOLE,5X20,S 4

2-41 0720174093 CRANKCASE,ASS'Y 1

2-42 99966122240 SEAL,OIL,#12227 2

2-43 0900174021 GASKET,CRANKCASE 1 ~R138860

2-43 0900174021 GASKET,CRANKCASE 1 ~Y212500

2-43 0900174120 GASKET,CRANKCASE 1 Y212501~

2-44 99961620106 BEARING,BALL,#6201 2

2-46 99905250980 ROLLER,NEEDLE,2.5X9.8 1

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

ECS-3351

Page 3

ENGINE CASE • FIGURE 3

ITEM PART NUMBER DESCRIPTION QTY COMMENTS

3-51 5603290090 CASE,ENGINE 1

3-52 56204060200 VALVE,AIR VENT,B 1

3-54 6450175090 AIR VENT VALVE SET 1

3-57 99463050204 BOLT,HEX 5X20 4

3-71 16201570900 SWITCH,STOP,ASS'Y 1

3-72 18301300200 NAME PLATE,SWITCH 1

3-73 27401710800 CORD,EARTH 1

3-80 0523290021 GROMMET,

www.tanakapowerequipment.com

PARTSINFORMATION

custsvc@nikko-tanaka-usa.com

Page 4

ECS-3351

AIR BOX, INTAKE, CARBURETOR •FIGURE 4

Units after serial number

C110351~

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]m

Page 5

ECS-3351

AIR BOX, INTAKE, CARBURETOR •FIGURE 4

ITEM PART NUMBER DESCRIPTION QTY COMMENTS

4-1 3800631A200 BOLT,CLEANER COVER 1

4-2 0513290091 SET,CLEANER COVER 1 ~732112Q1MAOF-RIA,RETLIF02047106443-4

4-4 4200174080 ELEMENT,CLEANER 1

2S/54X5,WERCS154050414995-4 068831R~15,REHSAW110050102997-4

4-7 99200050011 WASHER,SMALL,5 1 R138861~

068831R~208.X8X2.5,MIHS002053238078-4 10.4,EKOHC,EVLAV02819230079-4

4-10 4553290091 CARBURETOR SET 1 ~U016860

4-10 4553290G91 CARBURETOR SET 1 U016861~

4-11 4020174020 GASKET,CARBURETOR 1

4-12 99461050204 BOLT,HEX,HOLE,5X20,S 2

4-14 99200050011 WASHER,SMALL,5 2

1ROTALUSNI,TES190471040451-4

1DEER,EVLAV0020071049361-4

4-17 3950173020 HOLDER,REED VALVE 1

221X3,WERCS1210305109991-4

4-20 40901700200 RUBBER,CARB INSULATOR 1

4-21 4030174021 GASKET,INLET MANIFOLD 1

4-36 99075045144 SCREW, TAPPING,4X14 3

4-39 1523290J21 COVER,CLEANER B 1

1LAES,REVOC020371092154-4 ~100611Z1ELDI,TEMMORG020792319164-4

~C110350

1ROTALUSNI,TESG471040451-4

90 C110351~

~C110350

1DEER,EVLAV02G471049361-4

C110351~

~C110350

4-17 3950174G20 HOLDER,REED VALVE 1

C110351~

~C110350

4-21 4030174G20 1

C110351~

GASKET, INLET MANIFOLD

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

ECS-3351

Page 6

MUFFLER • FIGURE 5

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

ECS-3351

Page 7

MUFFLER • FIGURE 5

ITEM PART NUMBER DESCRIPTION QTY COMMENTS

5-26-1 99011050351 SCREW,5X35 2 ~U016860

5-26 99011050401 SCREW,5X40 2 U016861~

5-27 99201050011 WASHER,5 2

5-28-1 7040171090 SET,MUFFLER 1 ~U016860

5-28 7040174291 MUFFLER SET 1 U016861~

5-29-1 71701712800 BODY,MUFFLER,B 1 ~U016860

5-29 7170174080 BODY,MUFFLER,B 1 U016861~

5-30-1 72401700200 METAL,MUFFLER FITTING 1 ~U016860

5-30 7240174220 MUFFLER METAL 1 U016861~

5-31 7390170920 GASKET,MUFFLER 1 U016861~

5-32-1 71601700800 BODY,MUFFLER A 1 ~U016860

5-32 7160170980 BODY,MUFFLER A 1 U016861~

5-33 73701700200 GASKET,MUFFLER 1

5-34-1 73201710200 ARRESTER,SPARK 1 ~U016860

5-34 7320174020

RRESTER,SPARK 1 U016861~

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

ECS-3351

Page 8

FUEL PIPE, OIL FILTER & CHOKE • FIGURE 6

ITEM PART NUMBER DESCRIPTION QTY COMMENTS

6-1 50532710200 PIPE,OIL,B 1

6-2 68004019210 CLIP,7 3

6-3 99201050011 WASHER,5 1

6-4 48732712201 FILTER,OIL 1

6-5 4863271090 FILTER,ASS'Y 1

6-6 8850174081 WIRE,THROTTLE 1

6-7 96401710200 GROMMET,WIRE 1

6-15 99101060013 NUT,6 1

6-16 6780174020 PIPE,RUBBER 1

6-17 6750404280 FILTER,FUEL 1

6-26 99967018000 O-RING,P18 1

6-28 19032710200 CAP,ADJUSTER 1 ~U016860

6-28 1903290G20 CAP,ADJUSTER 1 U016861~

6-29 70732710200 GROMMET 1

6-30 70432710800 BUTTON,CHOKE 1

6-31 19132710200 GROMMET 1

6-32 99967020000 O-RING,P20 1

6-40 6423271990 CAP,OIL TANK 1

6-42 6353271990 CAP,FUEL ASS'

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

ECS-3351

Page 9

STARTER • FIGURE 7

ITEM PART NUMBER DESCRIPTION QTY COMMENTS

7-0 7560174090 STARTER,RECOIL,ASS'Y 1

7-1 99072050144 SCREW,TAPPING,5X14 1

7-2 36832350200 WASHER,BRAKE SHAFT 1

7-3 7740174020 PULLEY,STARTER 1

7-4 7830174020 ROPE,STARTER,3X890 1

7-5 7780174090 SPRING,RECOIL ASSY 1

7-7 7850174020 HANDLE,STARTER 1

7-9 1120174080 CASE,FAN 1

7-10 99072045204 SCREW,TAPPING,4.5X20 4
