TAC 200
User’s Manual
0-004-6921-0(GB),2000-02-09
TAC AB, Feb 2000
Contents
TAC 200 User’s Manual
TAC 200
User’s Manual
Thisdocumentcontainsproprietary informationof TACand ismade availablesolely tothose whooperate andmaintain TACequipment.
Disclosure,reproduction or useof eitherthe documents orthe informationcontained herein forany otherpurpose is strictlyprohibited.
TA reserves the right to make changes or additions to material as necessary.
©1993TAC AB
Contents
1 Introduction
1.1 The TAC 200 Heating Controller ...........................................................................................1:1
1.2 This manual ...............................................................................................................................1:1
1.3 More information .....................................................................................................................1:2
2 General
2.1 Mounting ..................................................................................................................................2:1
2.2 Connections ..............................................................................................................................2:3
2.3 The Operator Panel ..................................................................................................................2:5
2.4 Commissioning .........................................................................................................................2:7
3 Dailyoperations,P:00-P:15
3.1 List of available functions .........................................................................................................3:1
3.2 Description ...............................................................................................................................3:2
4 Special functions, P:16 -
4.1 List of available functions .........................................................................................................4:1
4.2 Reset .........................................................................................................................................4:2
4.3 Control functions ......................................................................................................................4:3
4.4 The Control Curve ...................................................................................................................4:4
4.5 Power limit function ..................................................................................................................4:6
4.5.1 Measuring the power ...................................................................................................................................... 4:6
4.5.2 Limiting the power .......................................................................................................................................... 4:7
4.6 Room temperature control ......................................................................................................4:7
4.7 Night setback and Morning boost ...........................................................................................4:9
4.8 Extended day/night operation ............................................................................................... 4:10
4.9 Time control of external units ............................................................................................... 4:11
4.10 Pump control .......................................................................................................................... 4:11
4.11 Time functions ....................................................................................................................... 4:12
4.12 Test functions ........................................................................................................................ 4:13
TACAB, Feb 2000
Contents
TAC 200 User’s Manual
5 Technicaldata
5.1 Electrical ...................................................................................................................................5:1
5.2 Mechanical ................................................................................................................................ 5:2
5.3 Default values ...........................................................................................................................5:2
5.4 Part numbers ............................................................................................................................5:4
TAC200 Commissioning protocol
Reply form
This manual contains in all 21 leaves.
TAC AB, Feb 2000 1:1
Introduction
TAC 200 User’s Manual
1 Introduction
1.1 TheTAC 200 Heating Controller
The TAC 200 is a controller for different heating systems.
TAC 200 may be operated with or without a room sensor.
It also compensates for the outdoor temperature in different ways.
The controller has an easy-to-use operator interface and needs virtually
no maintenance.
1.2 This manual
This manual has the following contents.
Chapter 2
Shows how the TAC 200 is mounted, connected and commissioned.
There is also a description of the operator interface with its symbols. To
show the usage of the operating keys, there is a detailed description on
how to set the date and time.
After the time has been set, the TAC 200 immediately starts working with
default values.
Chapter 3
This chapter describes the daily operations on the TAC 200. You can
read temperature values, enter setpoint values and change the time
programs for day and night time operation.
Chapter 4
When a plant is commissioned and fine-tuned, it may be necessary to
adjust some of the parameters. The controller function and available
parameters are described in chapter 4.
Chapter 5
This is a summary of the technical data of the TAC 200. There is also a
list of all the default values used at a restart.
At the end of the manual there is a commissioning protocol, where
entered values should be noted.
1:2
Introduction
TAC 200 User’s Manual
TAC AB, Feb 2000
1.3 More information
TAC 200 is also described in the following documents, available in
Swedish, English and several other languages:
•Data sheet TAC 200
The data sheet contains a comprehensive specification of the controller
and should be read together with the User’s Manual.
•List of functions in TAC 200
A small leaflet normally placed in a slot in the operator’s panel.
•Installation instruction TAC 200
0FL-3492-002 is a description for installation and start-up, packed
together with the unit. The contents are a condensed version of chapter 2
in this manual and a graphic mounting instruction.
TAC AB, Feb 2000 2:1
General
TAC 200 User’s Manual
2 General
2.1 Mounting
Type TAC 200 controller
The TAC 200 has a plastic enclosure with a transparent cover. Install the
controllerinaccordancewiththeenclosedinstructions.Placethecontrollerso
that you can easily adjust and read the display.
Cable entries for cables from sensors and actuators are provided for in the
mountingandterminalplate.
Type EGU outdoor sensor
Mount the sensor on an external wall facing north or northwest. The sensor
should be located about 3 m above the ground and the cable entry should be
orienteddownwards.
Type EGWS/EGA water temperature sensors
Install the EGWS pipe sensor in the riser pipe 0.5-1 m downstream of the
shunt valve. If a clamp-on sensor is fitted, mount this on an uninsulated part of
the riser pipe. Carefully rub down the pipe so that the copper plate of the
sensor will make good contact.
TAC AB, Feb 2000
2:2
General
TAC 200 User’s Manual
Type EGF 1 or EGRL room temperature sensors
To ensure the best possible results, observe the following when installing the
roomtemperaturesensor.
Thesensor mustbelocated ina roomwhichis typicalforthe building.
Theroommustbesufficientlylargesothatnowidetemperaturevariationswill
occur due to local heat sources, such as machines or occupants.
Theroom mustnot beequipped withthermostatic valves.
Locate the room sensor so that its time constant will be as short as possible. To
achievethis:
–Mount the sensor on an inner wall made of lightweight building material,
such as wood or plasterboard. Avoid mounting it on a concrete wall.
–Mount the sensor in an open location to ensure good circulation of air
aroundit.
–Locate the sensor within 10 m from a radiator, but not directly above a
radiator.Thisisparticularlyimportantinroomswithoutmechanical
ventilation.Theairvelocitiesarethenoftenlow,whichwillcauseasluggish
responseof thecontrol system.
Type M44, M5, M15, M42 actuators
Installation instructions for actuators are supplied together with the actuator
and its its installation kit.
TAC AB, Feb 2000 2:3
General
TAC 200 User’s Manual
Wiring diagram for mixing valve
Connection to a system with a 230 V actuator.
2.2 Connections
Supply temp. sensor
Room sensor
M 10
B1 11
B2 12
B3 13
M 14
X1 15
X2 16
X3 17
M 18
Outdoor sensor
Forced day op.
Forced night op.
Pulse counter
1 L
2 N
3 PE
4 KC1
5 K1
6 K2
7 KC2
8 K3
9 K4
Pump
Other
R
B
W
M15/
M44
(230V)
230 V L
230 V N
Connection to a system with a 24 V actuator.
Supply temp. sensor
Room sensor
M 10
B1 11
B2 12
B3 13
M 14
X1 15
X2 16
X3 17
M 18
Outdoor sensor
Forced day op.
Forced night op.
Pulse counter
1 L
2 N
3 PE
4 KC1
5 K1
6 K2
7 KC2
8 K3
9 K4
Pump
Other
R
B
W
(24
V)
230 V L
230 V N
~
24 V
Supply temp. sensor
Room sensor
M 10
B1 11
B2 12
B3 13
M 14
X1 15
X2 16
X3 17
M 18
Outdoor sensor
Forced day op.
Forced night op.
Pulse counter
1 L
2 N
3 PE
4 KC1
5 K1
6 K2
7 KC2
8 K3
9 K4
Pump
Other
230 V L
230 V N
Stage
2
Stage
1
Wiring diagram for on/off control
Connection to a system with an on/off control.
TAC AB, Feb 2000
2:4
General
TAC 200 User’s Manual
There are two types of on/off control (selected by the DIP-switch settings, see
2.4).
On/off in two steps: Step 1 Step 2
Stage 1 ••
Stage 2 •
On/off in three steps: Step 1 Step 2 Step 3
Stage 1 ••
Stage 2 ••
Connections on the terminal unit.
TAC 200 has six knock-out holes for cable entries:
–2 knock-outs in the rear part for conduit fitting Pr 18.6 (Pg 11)
–2 knock-outs (for cables with rubber bushings) on the upper side of
the case
–2 knock-outs (for cables with rubber bushings) on the lower side of
the case
High voltage cables must be kept well separated from the low voltage
cables.
Connections (also any connections of 24 V to the actuators) must be
performed according to the high voltage regulations.
1 230 V/L Supply voltage, live
2 230V/N Supply voltage, neutral
3 PE Protective earth
4 KC1 Voltage supply, relay K1 and K2
5 K1 Relay K1: increase / stage 1
6 K2 Relay K2: decrease / stage 2
7 KC2 Voltage supply, relay K3 and K4
8 K3 Relay K3: pump
9 K4 Relay K4: universal, time program 2, output
10 M Signalearth(Measuringground)
11 B1 Supplytemperaturesensor,EGWS/EGA
12 B2 Outdoorsensor,EGU
13 B3 Room sensor EGRL or EGF1
(wire 1 or 2; the other, 2 or 1, to M)
14 M Signalearth
15 X1 Forced day time operation (short-circuited to M)
16 X2 Forced night time operation (short-circuited to M)
17 X3 Digital input, pulse counter
18 M Signalearth
Cable length
Up to 200 m, area 0.5 mm2to B1-B3 and X1-X3.
Up to 100 m, area 1.5 mm2to other terminals.
TAC AB, Feb 2000 2:5
General
TAC 200 User’s Manual
TAC 200 List of functions and example on the use of the operating keys.
2.3 The Operator Panel
The Operator panel consists of a semi-graphic display, a leaflet with the
functions and the following operating keys
P
–upward in list (in the text also called Pup)
P
–downward in list (in the text also called pdown)
+
–increasevalue
–
–decreasevalue
0/ l
–toggle switch for the 30 minutes segments
TAC 200 Operator panel.
The keys Pup and Pdown are used to move up or down in the list of func-
tions, and the keys +and –(and in some cases 0/I) are used to change the
value of the selected item.
P:00 12:34
0/ l
–
P
+
P
Display. Normally showing
P:00 followed by the time.
Operating keys
List of
functions
DIP-switch
location
P:05
20.0
°C
–
P
+
P
Operating keys
List of functions
Display
P:
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
Function
Time / Mode
Room temperature
Outdoor temprature
Supply temperature
Calc. supply temp. SP
SetPoint room, day
SetPoint room, night
Night setback SP (°C)
Curve parallel adjustm.
Time pr 1, day-by-day
Time pr 1, 1-7 days
Time pr 2, day-by-day
Time pr 2, 1-7 days
Clock hh:mm
Month.day
Year
20.1
19.9
Tabla de contenidos
Otros manuales de Controladores de t.a.c.
t.a.c.
t.a.c. DuraDrive MS40-717 Series Manual de instrucciones
t.a.c.
t.a.c. Forta M700 Manual de usuario
t.a.c.
t.a.c. MS-83010 Series Manual de instrucciones
t.a.c.
t.a.c. Forta M400A Manual de usuario
t.a.c.
t.a.c. DuraDrive MA40-717 Series Manual de instrucciones
t.a.c.
t.a.c. MZ18L Manual de usuario
t.a.c.
t.a.c. M5 Manual de usuario
t.a.c.
t.a.c. Xenta 280 Manual de usuario
t.a.c.
t.a.c. Forta M1500A Manual de instrucciones
t.a.c.
t.a.c. DuraDrive MS40-7171 Manual de instrucciones
