Systembuild Evolution 6777015COM Manual de usuario

6777015COM

GymStorage

B346777015COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

ForthelatestinformationonSystemBuildproducts

followusatAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐866‐452‐4081(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.systembuild.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

systembuild.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐866‐452‐4081

Monday‐Friday

9am‐5pmCST

Visitsystembuild.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

systembuild.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You



Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.

PressCAMBOLTintohole.

PresspartstogethersoCAMBOLTinserts

intoedgehole.

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

PressCAMLOCKintohole.

Endhole

Arrowtopointtowardsend

holeinedgeofpart.

4

systembuild.com

BeforeYouStart

Quick

Tip

Assembly

Tube

You

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

systembuild.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

36777015010

RightPanel

36777015020

Partition

36777015030

Top

36777015040

Bottom

36777015050

DEF

BackPanel

K250701500

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

Shelf

36777015060

SupportBack

36777015070

LargeFrontPanel

36777015090

LowerPartition

36777015080

LiftTop

36777015100

RearPanel

36777015110

6

systembuild.com

BoardIdentification

Notactualsize

Tube

You

7

systembuild.com

PartList

ActualSize

Tube

You

(x20)

#A22710

cam bolt

(x20)

#A22700

cam lock

(x18)

#A21670

wood dowel

(x15)

#A23025

confirmat screw

(x8)

#A11080

7/16" screw

(x42)

#A21110

nail

123

(x15)

#A12120

7/16" screw

679

(x2)

#A22770

quickloc

(x1)

#A84050

safety bracket

(not actual size)

8

systembuild.com

Tube

You

PartList

NotActualSize

(x5)

#A44385

foot

(x2)

#A65700

hinge

(x3)

#A81940

hanging hook

(x2)

#A67740

drop leaf stay

10 12

9

systembuild.com

STEP1

Tube

You

(x18)

10

systembuild.com

STEP2

Tube

You

(x4)

Proper orientation of CAM LOCK

Tip

Assembly

Quick
