RX410 User’s Guide

RX41010062010

Table of Contents

TOC

5 Chapter 1: Get Started with RX410

5 Package Contents

6 Hardware Specications

6 Operating Requirements

7 Appearance

8 LED Behavior

9 Safety Instructions

11 Tools and Parts for Hard Disk Installation

11 Install Hard Disks

11 Chapter 2: Set Up RX410

13 Connect with Synology RackStation

15 Work with Synology RackStation

16 Learn More

Congratulations on your purchase of Synology RX410. This product is specially

designed for the storage expansion of Synology RackStation. This user’s guide

will guide you through the installation.

Package Contents

Before installation, please check the package contents to verify that you

have received the items below.

Main Unit AC power Cord

User’s Guide

Rack Mount Kit x 2 eSATA cable for

RS409+/RS409RP+

eSATA cable for

RS810+/RS810RP+

Screws for 3.5”

Hard Drives x 20

Screws for 2.5”

Hard Drives x 20

Rack Mount Kit

Screws x 5

Get Started with RX410

6 Chapter 1: Get Started with RX410

Hardware Specications

Internal HDD 4X SATA(II)

eSATA Port # 1

Max Capacity (Internal HDD) 4X 2TB

Hot Swappable HDD Yes

Size (HxWxD) (mm) 44x430.5x457.5mm

Weight 7.10 kg

System Fan 3X (40x40mm)

Fan Speed High / Middle / Low (Hibernation)

Noise Level (Fan-only) 32dB (5200rpm)

Power Recovery Sync with server

AC Input Power Voltage 100V to 240V AC

Power Frequency 50 / 60Hz, Single Phase

Operating Temperature 5°C ~ 35°C (40°F ~ 95°F)

Storage Temperature -10°C ~ 70°C (15°F ~ 155°F)

Relative Humidity 5% to 95% RH

Maximum Operating Altitude 10,000 feet

Certication FCC Class A, CE Class A

Operating Requirements

Synology RackStation RackStation series with Synology DSM2.3-1142

and onwards

Chapter 1: Get Started with RX410 7

Appearance

Front View

LED

Indicators

Hard Drive Tray

Power

Button

Reset

Button

Back View

Power Port eSATA Port

RESET Button

Fan

Article Name Location Description

POWER Button Front

The POWER button is used to turn RX410 on or off.

Press and hold the button for 7 seconds to shut down

RX410.

Note: RX410 will be turned on or off automatically when

the connected Synology RackStation powers on or off.

LED Indicators Front

The LED indicators are used to display the status of

the internal disks and the system. For complete details,

please refer to the next table: LED Behavior.

Hard Drive Tray Front The hard drive tray is designed for loading the hard

drives with RX410.

8 Chapter 1: Get Started with RX410

Article Name Location Description

RESET Button Front &

Back

The RESET button is used to restore the settings to the

factory default.

eSATA Port Back The eSATA port is used to connect RX410 to RackStation

servers.

Fan Back

The fan is built to exhaust waste heat out of RX410.

If the fan is not working, RX410 will “beep” every few

seconds.

Power Port Back The power port is where you connect the power cord to

RX410.

LED Behavior

LED Behavior Description

POWER Solid Green Power is on

Off Power is off

eSATA

Solid Green Synology RackStation is connected

Flashing Orange Fan is not working

Off Synology RackStation is disconnected

RAID

Solid Green Volume is created

Flashing Green Volume is degraded

Off Volume is crashed or not created

STATUS Solid Green System is functioning

Off System is not working

Hard Disk

Status

Solid Green Disk is ready and idle

Flashing Green Disk is being accessed

Solid Orange Read/write or other errors are encountered

Off No internal disk is found

Chapter 1: Get Started with RX410 9

Safety Instructions

To use your Synology product safely, please follow these instructions and

warnings at all time.

Keep away from direct sunlight and away from chemicals. Make sure

the environment does not experience abrupt changes in temperature or

humidity.

Keep Synology product upright. Do not lay it down horizontally.

Do not place the Synology product close to any liquid.

Before cleaning, unplug the power cord rst. Wipe Synology product

with damp paper towels. Do not use chemical or aerosol cleaners to

clean it.

Do not place the Synology product on a cart, table, or desk, which is not

stable to avoid the product from falling over.

The power cord must plug in to the right supply voltage. Make sure that

the supplied AC voltage is correct and stable.
