Synco V2 Manual de usuario
V2
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch • Manuel d'utilisation
2
English
3 –9
Čeština
10 –16
Slovenčina
17 –23
Magyar
24 –30
Deutsch
31 –37
Français
38 –44
3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Prague 7, www.alza.cz
4
Caring For Your SYNCO Product
•Please kept the product in a dry, dust-free environment.
•Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanical damage.
•Use only a soft and dry cloth for cleaning the product.
•Malfunction may be cause by dropping, impact external force.
•Do not attempt to disassemble the product. Doing so voids warranty.
•Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
•Failure to follow all the instructions may result in mechanical damage.
•Warranty does not apply to human errors.
1. Condenser Capsule
2. Working Indicator
Green: Working Red: Muting
3. Mic Volume
4. Monitor Volume
5. Mute Mode
First press to initiate mute mode, second
press to turn off mute mode.
6. 3.5mm Monitoring Jack
Used for plug-in earphones to monitor
the recording in real time. Please mind
the loudness.
7. USB Output.
5
Operations
1. The Use of Pop Filter
Please install the pop filter to the microphone for blocking air blasts.
2. The Use of Desktop Mic Holder
3. The Use of Microphone
1) Use with Computer
Connect the mic with the computer via the
USB-A to USB-A cable.
2) Use with smart phone/tablet
Connect the mic with the device via
the USB-A to Type-C cable.
6
Specifications
1. Polar Pattern: Cardioid
2. Performance Parameter
Transducer
Electrical Condenser
Frequency Response
20Hz-20KHz
Sample/Bit Rate
192KHz/24-bit
Signal/Noise
>90Db (1KHz, RL = infinity)
Sensitivity
-36dB (1V/Pa at 1KHz)
THD
<0.05% (1KHz/0dBFS)
Impedance
2.2Ω
Output Connector
USB
Power Requirement
5V 125mA
Dimensions
61 x 61 x 163mm
Cable Length
1.8m
Weight
431g
7
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
8
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
CIN: 27082440
Subject of the declaration:
Title: Wireless system
Model / Type: SYNCO V2
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. 2014/30/EU
Directive No. 2011/65/EU as amended 2015/863/EU
9
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
10
Vážený zákazníku,
Děkujeme vám za zakoupení našeho produktu. Před prvním použitím si prosím pečlivě
přečtěte následující pokyny a uschovejte si tento návod k použití pro budoucí použití.
Zvláštní pozornost věnujte bezpečnostním pokynům. Pokud máte k přístroji jakékoli
dotazy nebo připomínky, obraťte se na zákaznickou linku.
✉www.alza.cz/kontakt
✆+420 255 340 111
Dovozce Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
