Symbol DS4308 Manual de usuario
DS4308
DIGITAL SCANNER
QUICK START GUIDE
2 DS4308 Digital Scanner Quick Start Guide
We reserve the right to make changes to any product to improve reliability, function, or design.
We do not assume any product liability arising out of, or in connection with, the application or use of any
product, circuit, or application described herein. No license is granted, either expressly or by implication,
estoppel, or otherwise under any patent right or patent, covering or relating to any combination, system,
apparatus, machine, material, method, or process in which our products might be used. An implied license
exists only for equipment, circuits, and subsystems contained in our products.
Note: This Product may contain Open Source Software. For information regarding licenses,
acknowledgements, required copyright notices, and other usage terms, refer to the Documentation at:
http://www.motorolasolutions.com/support.
Warranty
For the complete hardware product warranty statement, go to: http://www.motorolasolutions.com/warranty.
For Australia Only
This warranty is given by Motorola Solutions Australia Pty Limited (ABN16 004 742 312) of Tally Ho Business
Park,10 Wesley Court. Burwood East, Victoria. Our goods come with guarantees that cannot be excluded
under the Australia Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure. Motorola Solutions Australia’s limited warranty above is in addition to any rights and remedies you may
have under the Australian Consumer Law.
If you have any queries, please call Motorola Solutions Australia at 1800457 439. You may also visit our
website: http://www.motorola.com/Business/XA-EN/Pages/Contact_Us for the most updated warranty terms.
Service Information
If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If there is a
problem with the equipment, they will contact the Global Customer Support Center at:
http://www.motorolasolutions.com/support.
For the latest version of this guide go to: http://www.motorolasolutions.com/support.
DS4308 Digital Scanner Quick Start Guide 3
Scanner Features
Presentation Mode
LED
Scan Window
Scan Trigger
4 DS4308 Digital Scanner Quick Start Guide
Connect Host Interface
USB
The digital scanner automatically detects the host interface type and uses the default setting. If the default (*)
does not meet your requirements, scan another host bar code below.
*
USB Keyboard HID
IBM OPOS
(IBM Hand-Held USB with Full Scan Disable)
IBM Hand-Held USB
Symbol Native API (SNAPI) with Imaging Interface
DS4308 Digital Scanner Quick Start Guide 5
RS-232
The digital scanner automatically detects the host interface type and uses the default setting. If the default (*)
does not meet your requirements, scan another host bar code below.
*Standard RS-232
ICL RS-232
Wincor-Nixdorf RS-232 Mode A
Wincor-Nixdorf RS-232 Mode B
6 DS4308 Digital Scanner Quick Start Guide
Keyboard Wedge
The digital scanner automatically detects the host interface type and uses the default setting. If the default (*)
does not meet your requirements, scan the IBM PC/AT & IBM PC Compatibles bar code below.
OPOS/JPOS
Fujitsu RS-232
*IBM AT Notebook
IBM PC/AT & IBM PC Compatible
DS4308 Digital Scanner Quick Start Guide 7
IBM 46XX
The digital scanner automatically detects the IBM host, but there is no default setting. Scan one of the bar
codes below to select the appropriate port.
Non-IBM Scanner Emulation (Port 5B)
Hand-Held Scanner Emulation (Port 9B)
Table-Top Scanner Emulation (Port 17)
8 DS4308 Digital Scanner Quick Start Guide
Set Defaults Bar Code
Return to Factory Defaults
Enter Key Bar Code (Carriage Return/Line Feed)
Add an Enter key after scanned data.
Enter Key (Carriage Return/Line Feed)
Tab Key Bar Code
Add a Tab key after scanned data.
Tab Key
USB Caps Lock Override
USB Override Caps Lock Key (Enable)
*USB Do Not Override Caps Lock Key (Disable)
DS4308 Digital Scanner Quick Start Guide 9
Scanning
Hand-Held and Hands-Free (Presentation) Scanning
Aiming
012345 012345
10 DS4308 Digital Scanner Quick Start Guide
LED Indications
Beeper Indications
Indication LED
Hand-Held Scanning
The scanner is on and ready to scan, or no power to the scanner Off
A bar code is successfully decoded Green
Transmission error Red
Hand-Free (Presentation) Scanning
No power to the scanner Off
The scanner is on and ready to scan Green
A bar code is successfully decoded Off momentarily
Transmission error Red
Indication Beeper Sequence
Power up Low/medium/high beep
A bar code is successfully decoded Short high beep
Transmission error 4 long low beeps
Successful parameter setting High/low/high/low beep
Correct programming sequence performed High/low beep
Incorrect programming sequence, or Cancel bar code scanned Low/high beep
