Sylvania SMPK7954 Manual de usuario
User Manual - SMPK7954
4GB Video MP3 player
Table of Contents
Table of contents…………………………………………………………………...…1
Basic Features……………………………………………………………………..….3
Accessories……………………………………………………………………………3
Basic Operation…………………………………………………………………..…..4
Power On ………………………..……………………………..…………………...4
Power Off ………………………..…………………………….…………..……….4
Lock/ Unlock……………………..…………………………….…………..……….4
Reset…… ………………………..…………………………….…………..……….4
How to insert and pull out Micro SD Card…………………………………………4
Connection to PC and Data Exchange…………...…………….…………..……….4
Charging...………………………..…………………………….…………..……….5
Low Power……………...………..…………………………….…………..……….5
Calibrate…………………………………………………………………………….5
File Storage...……………………..…………………………….…………..……….6
General Button/ Icon Description.…..………………………….…………..……….6
Main Menu Interface…………………………………………………………….…..7
Music Mode……………………………………………………………………….…..8
Music Interface Description...…..……………………..……….…………..……….8
Music Setting Interface....………..…………………………….…………..……….9
Lyrics Display...…………...……..…………………………….…………..……...10
Video Mode……………………………………………………………………….…11
Photo Mode……………………………………………………………………….…13
Camera Mode………...……………….………………………………………….…15
Ebook Mode…………………………………………………………………….…...17
Application………..…………………………………………………………….…...20
Recorder……....…………...……..…………………………….…………..……...21
Explorer…….....…………...……..…………………………….…………..……...22
Caculator……...…………...……..…………………………….…………..….......22
System Setting………………………………………………………………….…....23
Player Information...………….…..…………………………….…………..…...…23
Set Time……....…………...……..…………………………….…………..…...…23
Language……...…………...……..…………………………….…………..……...24
Display………...…………...……..…………………………….…………..……..24
Calibrate……....…………...……..…………………………….…………..……...24
Power Off Setting…………...…....…………………………….…………..……...25
Default Settings….………...……..…………………………….…………..……...25
Upgrade………...……..…...……..…………………………….………………….25
Video Conversation Tool……………...……………………………………….…...26
Version1.0 Page 1
Operating Platform…...…………..…………………………….…………..……...26
What format can files be converted into…..….…………….….…………….……26
Software Installation…………………...…..….…………….….…………..……...26
Automatic Installation…………………..….…………….….…………….……26
Manual Installation………………….…..….…………….….…………..……...26
Video File Conversion…………………......….…………….….…………..…...…27
Firmware Upgrade…………….……………………………………………….…...30
Technical Specification………………………………...……...…………...……….32
Trouble Shooting…………….....…………………………………………………...33
Version1.0 Page 2
Basic Features
zBrand new touch screen OS for direct and convenient operation
zBuild in Camera/ Camorder
zMusic player: compatible with MP3，WMA, WAV and ACT formats
zRecorder: MIC recording and compatible with ACT and WAV
formats
zPicture browser: for JPG, BMP and GIF formats
zVideo player: for playing video of ASF, MPG, DAT, VOB, AVI,
WMV, RMVB and MOV format
zEBook browser
zCompatible with Micro SD
zSettings: for setting and activating various features
zUSB2.0 high speed transmission
Accessories
zUser manual,
zUSB Cable
zEarphone and Adaptor
zCD Driver
Version1.0 Page 3
Basic Operation
Power On
Press the Power button and hold for 3 second to turn on the player. It will prompt
"Welcome" and then enter the main interface.
Power Off
When the player is on, press the power button and hold for 3 seconds to turn off the
player.
Lock / Unlock
Lock: Press the lock button to the lock position to lock the player so as to avoid
careless button operation.
Unlock: Press the lock button to unlock the player then touch operation will be
enabled again.
Reset
If the player encounters dead halt during use, press RESET button to restart the
player.
How to insert and pull out Micro SD card
How to insert: with the front (the side with characters) of the Micro SD card up
(towards the screen of the player), slightly push to insert into the card holder of the
player to connect. After the card is inserted, the player can play the files in the Micro
SD card.
How to pull out: slightly push the Micro SD card and the Micro SD card will partly
come out, and then pull the card out.
Note: please insert or pull out the card when the player is off, or the internal files of
the player will be lost or damaged.
Version1.0 Page 4
Connection to PC and Data Exchange
Connect the player to PC with the USB cable, and the player will enter “U disk” mode.
Press MENU button or safely remove U disk, and the player will be under USB
charging mode. In USB charging mode, touch the screen or press MENU to enter the
main applications interface.
Charging
This player has high capacity lithium battery. For charging, connect the player to the
USB port of the PC or to a charger. When the charger is used for charging, its
indicator light is in red color; when the indicator light turns into green color, it
indicates that the charging finishes. .
Low Power
When battery power is low, the player will prompt and power off and enter Standby
mode automatically. Do not power on and charge the player instead.
Charger current specification recommended: 400-500mA.
Calibrate
Before using this product, initial touch screen adjustment is required. Enter the
Calibrate mode in system setting to calibrate the touch screen position with centering
of calibrate sign +.
Version1.0 Page 5
File Storage
Files of different types should be stored under different directories. For example,
music file should be stored under MUSIC dir. Record file stored under RECORD dir.
Picture files under PICTURE dir. Video files VIDEO dir. Text files TXT dir. the
corresponding application unable to find the file If it is not saved in this way,
General Button /Icon Description
Button /Icon Description
Return to upper directory
Return to main menu
Delete file or file folder
Return to previous operation interface
Version1.0 Page 6
Main Menu Interface
This player provides a touch screen OS for direct operation. The main menu interface
is shown in the picture below:
1．The system date and time is shown on the upper left corner of the main menu
interface . The battery is shown on the upper right corner of the main
menu interface .
2．Under the main menu interface, touch an icon on the screen, and the player will
enter the selected mode.
3．After the player enters a mode, touch the icon on the bottom right corner
or press and hold the MENU button to return to the main menu interface.
Version1.0 Page 7
Music Mode
In the main interface, touch the “Music” icon to enter music mode.
Music Interface Description
Version1.0 Page 8
Button /icon Description
Number of the song being played / Total
songs.
Playing mode
Playing sequence
Playing style
Song playing progress bar. Drag the bar
to adjust playing progress.
Volume bar. Drag the bar to adjust
volume.
Touch it to switch to previous song, long
press for fast rewind.
Play / pause the current song. Click the
play button, and the button will be change
to pause button.
Touch it to switch to the next song, press
and long press for fast forward.
Music Setting Interface
Click one of the 4 buttons at the bottom of the interface to enable an appropriate
function.
Icon Description
Click Browser to enter different song lists - main directory, card
directory, all songs, ID3 list, play list, and tag list.
Click Settings to choose
SRS setting: WOW, WOWHD, USER
Click USER to enter user setting interface. Drag the bar or chick the
options to set the functions. Click OK to confirm the settings.
EQ setting: click to enter User EQ setting interface, move up or down
the bar to select sound effect, and click OK to confirm.
Version1.0 Page 9
