Day & Night

PTZ Dome Camera

For use with Swann 4400 Series HD DVRs

INSTRUCTION MANUAL

Congratulations on your purchase of this Day

& Night PTZ Dome Camera. A state-of-the-art

high resolution camera with 10x optical zoom.

The camera can pan a full 360 degrees and can

focus on key locations with multiple pre-set

viewing points. The 720p resolution is perfect

for close up detail such as license plates, facial

detail, and more. With the latest infrared cut fil-

ter, it has amazing night vision to 196ft/60m and

excellent clarity in low light. It’s ready to go with

a pre-installed mounting bracket.

Important note - All jurisdictions have specific

laws and regulations relating to the use of cam-

eras. Before using any camera for any purpose,

it is the buyer’s responsibility to be aware of all

applicable laws and regulations that prohibit or

limit the use of cameras and to comply with the

applicable laws and regulations.

Important safety instructions

1) Make sure the camera is fixed correctly and

stable if fastened in place.

2) Do not operate if wires and terminals are ex-

posed.

3) This camera can only be used in combination

with Swann’s DVR4-4400, DVR8-4400 or DVR16-

4400 digital video recorders.

4) Only use the supplied power adapter (24V).

5) Do not manually pan and tilt the camera when

it is turned on.

6) Use a small flat-head screwdriver to connect

the PTZ module that is attached to the rear of your

DVR, to the red and black PTZ wires on the video

& power cable.

Warning - Modifications not approved by the

party responsible for compliance could void us-

er’s authority to operate the equipment.

Introduction

Choosing a location for your PTZ Camera

With a PTZ camera, you have some flexibility on

where the camera can be mounted. Some things to

consider when choosing a location -

1) What you want to monitor and where you’ll get the

best view of it.

2) How you’re going to connect the camera to your

DVR; remember that cables and connections should

be kept out of the weather.

3) It’s recommended to mount your cameras at an

elevated position to keep out of harm’s way.

4) Make sure your camera has minimal sky in it as

the light in daylight can make the foreground of the

image darker.

5) Think about the most likely way a potential offender

may approach your home.

6) The camera’s casing is resistant to water and

tampering. However, the cable and connector are

vulnerable and require protection.

7) Prolonged exposure to adverse weather conditions

such as sunlight or excessive moisture, may

eventually damage the internal components of the

camera and adversely affect its performance.

8) When running your cable, try to avoid bending it at

sharp angles.

9) Don’t put your cable near live electrical wiring.

AC electricity generates radio “noise” which can

interfere with the signal from your camera.

10) As the camera can pan a full 360 degrees, this

means that (for example) installing it in a tight corner

is probably not an ideal utilization of its potential. A

freestanding pole of sufficient height and integrity

to reliably hold the camera securely is an ideal

choice, as is the centre of a wall in a larger room or

a warehouse.

Connecting your PTZ Camera

Power Input

Video Output

PTZ

Red

Black

Power Input

Video Output

Video Input

Power Output

PTZ

Video & Power Cable

Power Adapter

PTZ

75 3 1

86 4 2

eSATA

HDMI LAN & USB B A DC 12V

VGAVIDEO IN AUDIO OUT

AUDIO IN

Connecting your PTZ Camera (cont.)

1) Connect the PTZ connection on the camera to

the PTZ connection on the video & power cable

(the connection is keyed so it connects in one

orientation). Connect the video output and power

input on the camera to the corresponding connec-

tions on the video & power cable.

2) Connect the video output on the video & power

cable to a spare video input on the DVR.

3) Disconnect the PTZ module on your DVR. Using

a flat-head screwdriver, attach the PTZ wires (red

& black) to the PTZ module. The red cable con-

nects to “A” and the black cable connects to “B”

(as illustrated). Ensure the wires are held firmly

then tighten (don’t use too much force). Recon-

nect the PTZ module to the DVR when finished.

4) Connect the power input on the video & power

cable to the provided power adapter. Connect the

power adapter to a spare power connection.

When the camera is turned on, it will initialise

a self-test then display some information about

itself on-screen -

S/N: 201504031002

VERSION : V1.22AN

MODEL : DOME

PROTOCOL : PELCO

DOME ID : 001

BAUDRATE : 9600

The DVR’s default PTZ settings should allow you

to use the camera without any configuration.

However, there are many options that can be ac-

cessed using the DVR’s menu as well as the on-

screen menu on the camera. Download our com-

prehensive user manual available at our website.

Mounting & controlling your PTZ Camera

The PTZ camera can be mounted onto a flat sur-

face using the supplied mounting hardware. Ma-

terials such as hardwood, brick or concrete are

good options, and we’ve included all the gear

you’ll need for mounting.

1) Position the camera in the location you want to

mount it. Make sure the location is rigid to prevent

vibration.

2) Using a pencil or felt tip maker, mark the 4

screw holes on the surface to position the screws.

3) Using the appropriate screws for the surface

you’re fixing the camera to, screw the camera into

place. Make sure the camera’s bracket is aligned

straight, otherwise the image on the DVR will ap-

pear on an angle.

4) For wooden surfaces, screw the camera direct-

ly to the surface. For masonry surfaces (bricks or

concrete) you’ll need to use the wall plug.

To control the PTZ camera, use the mouse and

click the channel the camera is connected to.

Click the “PTZ” button on the camera toolbar. Ap-

pearing on-screen is the PTZ controls –

1) Click the directional buttons to move the cam-

era in the direction selected.

2) This determines how fast the camera will move.

3) The ability to zoom into an object and to con-

trol the level of focus (the “Iris” controls are not

available).

Limited Warranty - Terms & Conditions

Swann Communications warrants this product

against defects in workmanship and material for

a period of one (1) year from its original purchase

date. You must present your receipt as proof of

purchase for warranty validation. Any unit which

proves defective during the stated period will

be repaired without charge for parts or labour

or replaced at the sole discretion of Swann. The

end user is responsible for all freight charges in-

curred to send the product to Swann’s repair cen-

tres. The end user is responsible for all shipping

costs incurred when shipping from and to any

country other than the country of origin.

The warranty does not cover any incidental, ac-

cidental or consequential damages arising from

the use of or the inability to use this product. Any

costs associated with the fitting or removal of this

product by a tradesman or other person or any

other costs associated with its use are the re-

sponsibility of the end user. This warranty applies

to the original purchaser of the product only and

is not transferable to any third party. Unauthor-

ized end user or third party modifications to any

component will render all warranties void. By law

some countries do not allow limitations on certain

exclusions in this warranty. Where applicable by

local laws, regulations and legal rights will take

precedence.

For Australia: Our goods come with guarantees

which cannot be excluded under Australian Con-

sumer Law. You are entitled to a replacement

or refund for a major failure and for compensa-

tion for any other reasonably foreseeable loss or

damage. You are also entitled to have the goods

repaired or replaced if the goods fail to be of ac-

ceptable quality.

FCC Verification

This equipment has been tested and found to comply with the limits for Class B digital device, pursu-

ant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected

• Consult the dealer or an experienced radio/TV technician for help

These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) These devices may not cause harmful interference.

(2) These devices must accept any interference received, including interference that may cause unde-

sired operation.

MA852PTZ060515E | © Swann 2015

Helpdesk/Technical Support

Technical Support E-mail: [email protected]om

Telephone Helpdesk

USA Toll Free 1-800-627-2799

USA Parts & Warranty 1-800-627-2799

(M-F, 9am-5pm US PT)

AUSTRALIA 1800 788 210

NEW ZEALAND Toll Free 0800 479 266

UK 0808 168 9031
