Sven E-335B Manual de usuario

www.sven.fi

USER MANUAL

Wireless Stereo Headphones

with Microphone

E-335B

ENG

Wireless Stereo Headphones

with Microphone

Congratulations on your purchase of the SVEN stereo headphones!

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eorts to make this Manual more exact, some discrepancies may oc-

cur. Theinformation in this Manual is given on «as is» terms. The author and the publisher

do not bear any liability to a person or an organization for loss or damage which has arisen

from theinformation contained in this Manual.

BUYER RECOMMENDATIONS

•Unpack the device carefully. Make sure there are no accessories left in the box. Check up

the device for damage; if the product was damaged during transportation, address therm

which carried out the delivery; if the product functions incorrectly, address the dealer

atonce.

•Check up the package contents and availability of the warranty card. Make sure thewar-

ranty card has a shop stamp, a legible signature or the seller’s stamp and purchase date,

and the goods number corresponds to that in the warranty card. Remember: in case

ofwarranty card loss or discrepancy of numbers you forfeit the right for warranty repairs.

•Before installing and using the speaker system, read this Manual carefully and keep

itforfuture reference.

•Shipping and transportation equipment is permitted only in the original container.

•Does not require special conditions for realization.

•Dispose of in accordance with regulations for the disposal of household and computer

equipment.

•The date of manufacture of the product is indicated on the box.

APPLICATION

SVEN E-335B wireless stereo headphones with microphone are designed for operation with

PC, notebookes and other mobile devices by means of data transfer via Bluetooth protocol.

They can be also used in internet telephony, during video conferences, in multimedia

applications, in interactive games, for speech recognition and foreign language teaching.

PACKAGE CONTENTS

•Wireless stereo headphones set — 1 pc

•USB power cord to Type-C — 1 pc

•Charging case — 1 pc

•User Manual — 1 pc

•Warranty card — 1 pc

Technical support is on www.sven..

ENG

E-335B

User Manual

Fig. 1.

DESCRIPTION

a Charging сase LED indicator

bHeadphones LED indicator

c Multifunction sensor button

d Magnetic contact with charging case

e Charging case

f TYPE-C jack for battery charging

SAFETY PRECAUTIONS

•Don’t use the stereo headphones while driving.

•Don’t use the stereo headphones at high volume for a long time (more than 15 minutes),

as this may cause hearing impairment.

SPECIAL FEATURES

•Bluetooth wireless signal transmission

•Touch control of incoming calls and track switching

•Battery operation time up to 3 hours

•Operating time using a charging case up to 12 hours

CONNECTION

First connection

•Remove both headphones from the

charging case, then put them back to the

case to activate the headphones.

•If there is a protective film on the

contacts, you must remove it before

using the headphones.

•The battery in the headphones and

case is used as an integral part of the

device. Before using for the rst time,

make sure that the headphones are

fully charged. If the headphones are

discharged, they need to be fully charged

(see headphone charging section).

Headset to a device interfacing

•It is necessary rst to interconnect

the device with a signal source (see

the connection diagram in Fig. 2) to

transfer signals via Bluetooth. To pair

the headphones with the device, put

them to the charging case, then get them

out. Both earphones are automatically

switched on and connected to each

other. At the same time on the right

earphone LED indicator b will alternate

blue and red glow, and indicator bon

the left earphone will light blue.

ENG

Wireless Stereo Headphones

with Microphone

•It is necessary to select Bluetooth device search mode on a signal source (telephone,

notebook, smartphone, etc.). «SVEN E-335B» massage will be displayed on the screen,

which is to be connected to*.

•If connection successful, there will be a short beep signal in the headphones; the search

mode indication on the headphones is over. If no devices connected, headphones will

turned o automatically in 2 minutes.

Bluetooth Technology

•Wireless data transfer via the Bluetooth protocol enables to connect wireless

headphones to compatible devises. Maximum radi us of action of data transfer is 10 m.

Such obstacles as walls or other electronic devices can interfere with the signal transfer.

OPERATION

Case Charging

•Connect the charging case (jack f) to PC USB port or USB charger using USB

to USB type-C (included). During battery charging indicator a will alternately

flash white. When the case is fully charged, all 4 LEDs will light up continuously.

Each LED symbolizes approximately 25% of the charge.

Case Headset Charging

•Put the headphones to the charging case. During battery charging indicator blights red.

When device is charged full, indicator b is blue within 1 minute, then go out.

•The battery in the headphones and case is used as an integral part of the device,

therefore do not try to extract or replace it, because this can result in the warranty

cancellation or the device damage.

Device switching on

•Remove the headphones from the charging case and they will automatically turn on.

Make sure the headphones are charged.

Device switching off

•Put the headphones to the charging case. They will automatically turn o, or long touch

of button cof the headphones - turn off each headphone separately.

* You might have to enter «0000» code to connect some models of devices via Bluetooth.

Fig. 2. Connection diagram

PC Headphones

Mobile device

ENG

E-335B

User Manual

Headphone control

When connected to a telephone:

•In order to receive an incoming call, touch the earphone once. Long press either of

earphone 2 seconds to reject the incoming call.

•Siri or Google Assistant: touch the either of earphone three times.

•Рlay/pause: touch either of earphone once.

•Previous track: long press the left earphone 2 seconds.

•Next track: long press the right earphone 2 seconds.

•Reset function: touch button c on the two earbuds five times at the same time.

TECHNICAL SPECIFICATIONS

Parameter, measurement unit Value

Sensitivity, dB headphones: 102 ± 3

microphone: -58 ± 3

Frequency range, Hz headphones: 20 – 20 000

microphone: 30 – 16 000

Impedance, Ohm 32

Membrane, mm Ø 14

Connection type Bluetooth

Bluetooth supported proles HSP, HFP, A2DP, AVRCP

Radius of operation, m up to 10

Operation time, h up to 3

Operation time using a charging case, h up to 12

Weight, g 30

Notes:

• Technical specications given in this table are supplemental information and cannot

give occasion to claims.

• Technical specications and package contents are subject to change without notice

due to the improvement of SVEN production.

Wireless Stereo Headphones

with Microphone

E-335B

Model: E-335B

Importer: Tiralana OY, Office 102, Kotolah-

dentie 15, 48310 Kotka, Finland.

Импортер в России: OOO «Регард», 105082,

г. Москва, ул. Фридриха Энгельса, д.75,

стр. 5. Уполномоченная организация

вРоссии: ООО «РТ-Ф», 105082, г.Москва,

ул. Фридриха Энгельса, д. 56,

стр. 1.

Условия гарантийного обслуживания смо-

трите в гарантийном талоне илинасайте

www.sven.fi. Гарантийный срок: 12 мес.

Срок службы: 2 лет.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, № 02-02, Сингапур,

427447. Произведено под контролем

«Свен

Скандинавия Лимитед», 48310,

Финляндия, Котка, Котолахдентие, 15.

Сделано

в Китае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat

Road, № 02-02, Singapore, 427447.

Produced under the control of Oy Sven Scan-

dinavia Ltd. 15, Kotolahdentie, Kotka, Finland,

48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
