Sven MK-950 Manual de usuario

www.sven.

Wireless Karaoke

Microphone

MK-950

USER’S MANUAL

Wireless Karaoke

Microphone

ENG

Congratulations on your purchase of the SVEN microphone !

BUYER RECOMMENDATIONS

• Unpack the device carefully. Make sure there are no accessories left in the box. Check up the device for

damage; if the product was damaged during transportation, address the rm which carried out the delivery;

if the product functions incorrectly, address the dealer at once.

• Shipping and transportation equipment is permitted only in the original container.

• Does not require special conditions for realization.

• Dispose of in accordance with regulations for the disposal of household and computer equipment.

APPLICATION

SVEN MK-950 wireless karaoke microphone is designed for singing at home. It can also play a sound signal

received from a PC, laptop and other mobile devices via Bluetooth. There is an echo function and a player with

microSD memory cards.

PACKAGE CONTENTS

• Microphone – 1 pc

• USB to micro USB power cable – 1 pc

• User’s Manual – 1 pc

• Warranty card – 1 pc

SPECIAL FEATURES

• Built-in speaker unit

• Built-in player for audio les from microSD card storage device

• Microphone volume and echo level control

• Removable battery

• Metal case

Microphone description (Fig.1)

aVOL +/-: volume control buttons

b: Play/Pause button

cBluetooth search indicator

dMIC VOL +/-: microphone volume control knob

eMODE: switching modes button: Bluetooth/Player (short pressing);

microphone on/o button (long pressing)

f: next track

g: previous track

hBattery indicator

iECHO +/-: microphone echo adjustment knob

jTF: micro SD card slot

kDC 5V IN: micro USB jack for microphone charger connecting, the USB port of laptop / PC

Technical support is on www.sven..

ENG

User’s Manual MK-950

Fig.1.

CONNECTION AND OPERATION

Attention! The built-in battery must be charged completely prior to the application.

Microphone battery charging

• Connect microphone to a USB port of PC or USB charger using micro USB to USB cable (included).

During battery charging the indicator his red. Indicator hgoes out when the battery is charged.

OPERATION MODES

Bluetooth mode

• Wireless data transfer via the Bluetooth protocol enables to connect microphone to compatible devises.

Maximum radius of action of data transfer is 10 m. Such obstacles as walls or other electronic devices can

interfere with the signal transfer.

• Svich the microphone to the Bluetooth mode using button МODE e. Turn on the microphone. The c

indicator will ash blue.

• It is necessary to select the search mode of devices with Bluetooth on a signal source (telephone,

notebook, smartphone, etc.). «SVEN MK-950», massage will be displayed on the screen which is to be

connected to*.

• When connection is successful, there will be a short beep, and the microphone indication of the search

mode cwill shine continuously**.

* You might have to enter “0000” code to connect some models of devices via Bluetooth.

** If the item has been already registered in the device list of a source, then the second search mode

activation is not obligatory. Choose the item name «SVEN MK-950» nd the “connect” command on the

source.

Wireless Karaoke

Microphone

ENG

Fig. 2. Connection diagram

USB to micro USB

power cable

USB jack

Mobile device

Socket

TECHNICAL SPECIFICATIONS

Parameter, measurement unit Value

Frequency response, Hz 100 – 20 000

Output power (RMS), W 6

Speaker diameter, mm Ø 40

Bluetooth supported proles HSP, HFP, A2DP, AVRCP

Radius of operation, m until 10

Battery capacity, mA*h 1200

Power supply, V USB/DC 5V

Weight, kg 400

Dimensions, mm 77 × 77 × 235

Notes:

• Technical specications given in this table are supplemental information and cannot give occasion

to claims.

• Technical specications and package contents are subject to change without notice due to the

improvement of SVEN production.

Player mode

Attention! The le system of a micro SD carrier is FAT32. Maximum volume is 32 GB. It is not

recommended to use the micro SD Ultra Speed.

• The microphone will enter the Player mode automatically when a carrier (USB ash or SD card) is

connected to corresponding ports. Use button bto switch between Play / Pause modes. You can control

tracks by using buttons g(previous track) and f(next track).

Wireless Karaoke

Microphone

MK-950

Model: MK-950

Импортер в России: OOO «РЕГАРД», 105082, РФ, г. Москва,

ул. Фридриха Энгельса, д.75, стр. 5.

Уполномоченная организация в России: ООО «РТ-Ф»,

105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите в га-

рантийном талоне или на сайте www.sven..

Гарантийный срок: 12 мес.

Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед», 176 Джу Чиат

Роуд, № 02-02, Сингапур, 427447. Произведено под

контролем «Свен Скандинавия Лимитед», 48310, Фин-

ляндия, Котка, Котолахдентие, 15. Сделано в Китае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road, № 02-

02, Singapore, 427447. Produced under the control of Oy

Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka, Finland,

48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
