SUTO S505 Manual
English
Instruction and operation manual
S505
Dew point meter (portable)
Dear Customer,
Thank you for choosing our product.
Please read the operating instructions in full and carefully observe it
before starting up the device. The manufacturer cannot be held liable
for any damage that occurs as a result of non-observance or non-
compliance with this manual.
Should the device be tampered with in any manner other than a
procedure that is described and specified in the manual, the warranty is
cancelled and the manufacturer is e empt from liability.
The device is designed e clusively for the described application.
SUTO offers no guarantee for the suitability for any other purpose.
SUTO is also not liable for consequential damage resulting from the
delivery, capability or use of this device.
2 S505
Table of contents
1 Safety instructions......................................................................4
2 Registered trademarks.................................................................6
3 Application.................................................................................6
4 Features....................................................................................7
5 Technical data.............................................................................7
5.1 General................................................................................7
5.2 Electrical data.......................................................................8
5.3 Accuracy .............................................................................8
6 Dimensional drawing..................................................................10
7 Installation ..............................................................................11
7.1 Installation procedure .........................................................11
7.2 Electrical connection ..........................................................13
8 Operation ................................................................................14
8.1 Buttons and connectors........................................................14
8.2 Symbols on screen..............................................................15
8.3 Main screen .......................................................................16
8.4 Basic operations .................................................................16
8.5 Data logger.........................................................................17
8.6 File menu ..........................................................................18
8.7 Print menu .........................................................................18
8.8 Bluetooth menu ..................................................................18
9 Application software .................................................................19
9.1 S4A...................................................................................19
9.2 S4C-Handheld.....................................................................19
10 Optional accessories................................................................20
10.1 Portable bluetooth printer CS2.............................................20
10.1.1 Paper loading..............................................................20
10.1.2 Basic operations..........................................................21
10.2 Measuring chambers for the S505........................................22
10.2.1 Standard measuring chamber (A699 3500).....................22
10.2.2 By-pass measuring chamber (A699 3501).......................22
10.3 4G SD card.......................................................................23
11 Calibration..............................................................................23
11.1 Dew point calibration..........................................................24
11.2 Pressure calibration ...........................................................25
12 Maintenance...........................................................................25
13 Disposal or waste....................................................................26
S505 3
Safety instructions
1 Safety instructions
Please check if this instruction manual matches with the
product type.
Please observe all notes and instructions indicated in this
manual. It contains essential information which must be
observed before and during installation, operation and
maintenance. Therefore this instruction manual must be read carefully
by the technician as well as by the responsible user / qualified
personnel.
This instruction manual must be available at the operation site of the
dew point meter at any time. In case of any obscurities or questions,
regarding this manual or the product, please contact the manufacturer.
ARNING!
Compressed air!
Any contact with quickly escaping air or bursting
parts of the compressed air system can lead to
serious injuries or even death!
•Only use pressure tight installation material.
•Avoid that persons get hit escaping air or bursting parts of the
instrument.
•The system must be pressureless during maintenance work.
ARNING!
Voltage used for supply!
Any contact with energized parts of the product, may
lead to a electrical shock which can lead to serious
injuries or even death!
•Consider all regulations for electrical installations.
•The system must be disconnected from any power supply during
maintenance work.
•Any electrical work on the system is only allowed by authorized
qualified personal.
4 S505
Safety instructions
ATTENTION!
Permitted operating parameters!
Observe the permitted operating parameters, any
operation exceeding this parameters can lead to
malfunctions and may lead to damage on the
instrument or the system.
•Do not e ceed the permitted operating parameters.
•Make sure the product is operated in its permitted limitations.
•Do not e ceed or undercut the permitted storage and operation
temperature and pressure.
General safety instructions
•It is not allowed to use the product in e plosive areas.
•Please observe the national regulations before/during installation
and operation.
Remarks
•It is not allowed to disassemble the product.
•Always use spanner to mount the product properly.
ATTENTION!
Measurement values can be affected by malfunction!
The product must be installed properly and
frequently maintained, otherwise it may lead to
wrong measurement values, which can lead to
wrong results.
Storage and transportation
•Make sure that the transportation temperature of the dew point
meter is between -30 ... +70°C.
•For transportation it is recommended to use the packaging that
comes with the sensor.
•Please make sure that the storage temperature of the sensor is
between -40 ... +65°C.
•Avoid direct UV and solar radiation during storage.
•For the storage the humidity must be <95% rH, no condensation.
S505 5
Registered trademarks
2 Registered trademarks
SUTO®
Registered trademark of SUTO iTEC
MODBUS®
Registered trademark of the Modbus Organization, Hopkinton, USA
HART®
Registered trademark of the HART Communication Foundation, Austin,
USA
PROFIBUS®
Registered trademark of the PROFIBUS User Organization, Karlsruhe,
Germany
3 Application
The S505 is a dew point meter which is designed to monitor the dew
point in industrial application within the permissible operating
parameters. These parameters can be found in the technical data
section.
The S505 can measure and display the following values:
•Dew point of the compressed air or gas.
•Temperature of the compressed air or gas.
•Pressure of the compressed air or gas.
The default factory settings are: dew point in °C Td. temperature in °C,
and pressure in bar.
The S505 dew point meter is mainly used in compressed air systems in
industrial environment.
The S505 dew point meter is not developed to be used in e plosive
areas. For the use in e plosive areas please contact the manufacturer.
6 S505
Features
4 Features
•Measures dew point, temperature and pressure.
•3 sensor solution available:
◦Sensor Q: -100 ... -30°C Td for trace moisture applications
◦Sensor P: -50 ... +50°C Td for standard applications.
◦Sensor Q+P: Covering the full range of dew point
measurement.
•Fast response time.
•Modern colour touch screen interface.
•Data logger, USB interface, Bluetooth connection to portable
printer.
•Measuring / parking chamber, designed for fast sensor response.
•Application software included.
5 Technical data
5.1 General
Parameters Standard unit dew point: °C Td
Standard unit temperature: °C
other units: °F, K
Standard unit humidity: % rH
Standard unit pressure: bar
Principle of measurement Capacitive method, Oscillating crystal
Sensor Sensor Q: QCM technology
Sensor P: Polymer
Measuring medium Non-corrosive gases
Measuring range Sensor Q: -100 ... -30°C Td
Sensor P: -50 ... +50°C Td
Pressure: -0.1 ... 1.5 MPa
Temperature: -30 ... +50°C
Operating temperature 0 ... 50°C
Operating pressure -0.1 ... 1.6 MPa *
S505 7
Technical data
Relative humidity 0 ... 90% rH
Casing material PC + ABS
Charging time 7 h (if switched on), 4 h (if switched off)
Protection class IP65
Dimensions See dimensional drawing on the page 10
Display 2.8” colour graphic display
Weight 0.7 kg (with measuring chamber), 0.45 kg
(without measuring chamber)
* At least 0.3 MPa is needed for the measuring chamber supplied with
the instrument. For low-pressure measuring below 0.3 MPa, choose the
optional bypass measuring chamber A699 3501.
5.2 Electrical data
Power supply USB charger: 5 V, 2 A
5.3 Accuracy
Accuracy Dew point: ± 2°C Td @ -50°C
Temperature:± 0.3°C
Pressure:± 0.005 MPa
Repeatability ± 0.5°C
Stated accuracy at Ambient/process temperature: 23°C ± 3°C
Ambient humidity: 0 ... 80% rH, no
condensation
Accuracy:
8 S505
