Surface Concept HVPS-HC Manual de usuario
19“ HVPS-HC Module
1Channel/2Channel
(Release R012)
Manual
2
email:
User Manual for the
19” HVPS-HC Module 1Channel/2Channel
Release: R012
Manual Version 2.3
Printed on 2021-06-11
19“ HVPS-HC Module R012 Manual | Surface Concept GmbH
Surface Concept GmbH
Am Saegewerk 23a
55124 Mainz
Germany
phone: +49 6131 62716 0
fax: +49 6131 62716 29
email: info@surface-concept.de
web: www.surface-concept.de
All rights reserved. No part of this manual may
be reproduced without the prior permission
of Surface Concept GmbH.
3
Manual 19“ HVPS-HC Module
19“ HVPS-HC Module R012 Manual | Surface Concept GmbH
1 Table of Contents
1 Table of Contents ................................................................................................................................................3
2 Introduction..........................................................................................................................................................5
2.1 General Information...........................................................................................................................5
2.2 Safety Instructions..............................................................................................................................5
2.3 General Overview ...............................................................................................................................6
3 Introduction..........................................................................................................................................................7
3.1 Initial Inspection..................................................................................................................................7
3.2 Installation.............................................................................................................................................7
4 Device Layout & Operation .............................................................................................................................9
4.1 Device Layout.......................................................................................................................................9
4.2 General Device Operation ............................................................................................................10
4.3 Schematic Layout of the 19”HVPS-HC Module R012..........................................................11
4.4 Floating Operation .......................................................................................................................... 12
4.5 Limitations Floating Operation................................................................................................... 12
5 List of Figure..................................................................................................................................................... 13
419“ HVPS-HC Module R012 Manual | Surface Concept GmbH
This side has been left blank on purpose.
5
Manual 19“ HVPS-HC Module
19“ HVPS-HC Module R012 Manual | Surface Concept GmbH
2 Introduction
2.1 General Information
This manual is intended to assist users in the installation, operation and maintenance of Release Version
012 of the 19” HVPS-HC Module. It is divided into 5 chapters.
2.2 Safety Instructions
Please read this manual carefully before performing any electrical or electronic operations and strictly
follow the safety rules given within this manual.
The following symbols may appear throughout the manual:
The“caution symbol”marks warnings, which are given to prevent an accidental damaging
of the device. Do NOT ignore these warnings and follow them strictly. Otherwise no
guarantee is given for arose damages.
Note
The “note symbol” marks text passages that contain important information/hints about
the operation of the device. Follow this information to ensure a proper operation of the
device.
The “high voltage symbol” marks warnings, given in context with the description of the
operation/use of high voltage supplies and/or high voltage carrying parts.
Hazardous voltages are present that can cause serious or fatal injuries. Therefore only
persons with the appropriate training are allowed to carry out the installation, adjustment
and repair work.
619“ HVPS-HC Module R012 Manual | Surface Concept GmbH
2.3 General Overview
The Surface Concept 19” HVPS-HC Module R012 is a high voltage module especially designed for the
Surface Concept 19”Basic Unit, a modular supply system.
The 19”HVPS-HC Module R012 comes as a 1 channel/ 2 channel version, which provides one/two separate
high voltages with a switchable polarity (must be manually switched by the user). It also provides the
capability to oat on a reference potential. Hereby each channel has its own, individual reference input. For
the 2 channel version, the both channels work absolutely independent on reference potential and output
polarity.
Depending on the maximum output voltage the 19” HVPS-HC Module R012 comes with either SHV
connectors (maximum output voltage <= 5kV) or with 10kV LEMO connectors type ERA.1S.405.CTL
(maximum output voltage > 5kV).
The device can produce lethal high voltages of up to several kV. Hazardous voltages are
present, therefore only persons with the appropriate training are allowed to carry out
the installation, adjustment and repair work.
Do not open the power supply, while it is in operation. Hazardous voltages are present.
In case that the device must be opened, turn o the device rst AND pull out the power
plug.
Note
The 19” HVPS-HC Module R012 is available with dierent output voltages and dierent
maximum oating voltages. Check the specication sheet of your specic 19” HVPS-HC
Module R012 for detailed information on those parameters.
7
Manual 19“ HVPS-HC Module
19“ HVPS-HC Module R012 Manual | Surface Concept GmbH
3 Introduction
3.1 Initial Inspection
Visual inspection of the system is required to ensure that no damage has occurred during shipping. If
there are any signs of damage, please contact SURFACE CONCEPT immediately. Please check the delivery
according to the packing list (see Table 1) for completeness.
• 1x 19“ HVPS-HV Module R012
• 1x Termination Plug (SHV or LEMO 1S) per channel
Table1: Packing list for the 19“ HVPS-HC Module R012.
3.2 Installation
The general connection scheme of the 19”HVPS-HC Module R012 is as follows:
Figure 1: Exemplary basic connection scheme of a 2 channel Module R012 with SHV connectors.
819“ HVPS-HC Module R012 Manual | Surface Concept GmbH
The 19” HVPS-HC Module R012 is specied for the operation with an external reference
voltage. Please check the specication sheet of your specic module for the maximum
allowed reference voltage.
All 19” HVPS-HC Module R012 with a maximum output voltage <= 5kV come with SHV
connectors, independent on their maximum oating voltage.
Therefore it must be taken care o, that the sum of the module output voltage and the
applied oating voltage is not exceeding 5kV in total.
In cases that no reference voltage is applied to the device, the termination plug must
be used to ground the reference input of the 19” HVPS-HC Module R012. With a missing
reference potential the device is not providing any output voltage.
Finish the complete cabling of the 19”HVPS-HC Module R012 before switching on the 19”
Basic Unit and switch o the device rst before performing any changes to the cabling.
• Install the 19” HVPS-HC Module R012 into a free slot of the 19”Basic Unit (if not already installed).
• Use appropriate cables (SHV or LEMO 1S) to connect the outputs with the corresponding polarity
suitable for your application.
• Use the termination plugs (SHV or LEMO 1S) to terminate the output with the opposite polarity to GND
(e.g. terminate the negative output of channel 1 in case that the positive output of channel 1 should
be used).
• Alternatively an external reference potential can be applied instead of using the termination plug for
a termination to GND.
9
Manual 19“ HVPS-HC Module
19“ HVPS-HC Module R012 Manual | Surface Concept GmbH
4 Device Layout & Operation
4.1 Device Layout
The layout of the 19” HVPS-HC Module R012 is given below.
SHV connector for output of operation
voltage with positive polarity for the rst/
second HV channel.
(Must be terminated to GND or to an external
reference potential when using the output
voltage with negative polarity.
Check the specication sheet for the
maximum allowed reference voltage).
SHV connector for output of operation
voltage with negative polarity for the rst/
second HV channel.
(Must be terminated to GND or to an external
reference potential when using the output
voltage with positive polarity.
Check the specication sheet for the
maximum allowed reference voltage).
Figure 2: Layout of the 19”HVPS-HC Module R012.
1(+)/2(+)
1(-)/2(-)
10 19“ HVPS-HC Module R012 Manual | Surface Concept GmbH
4.2 General Device Operation
After switching on the 19” Basic Unit, the display shows the “Surface Concept” animated logo, while the
device is scanning for the 19” HVPS-HC Module R012 and its specic settings. This can take up to several
seconds. If the 19”Basic Unit is ready for operation, it switches into the standby mode and shows an empty
mask for the voltage adjustment (see Figure 3).
Push the“Start/Standby” button in the lower left
corner of the display to switch on the high
voltage.
Alternatively one can press the“Channel”control
knob.
After switching on the high voltage the device
is in the so called operation mode. In operation
mode the display shows the name of the selected
channel in the top line (in this case“HV 1”) as well
as the output voltage of that channel.
The dierent HV channels can be selected by
turning the “Channel” control knob.
Figure 3: Standby mode.
Figure 4: Operation mode.
Figure 5: Operation mode – voltage adjustment.
The “Adjust” control knob is used to adjust
the output voltage. Turn the “Adjust” control
knob clockwise/counter-clockwise to increase/
decrease the value of the output voltage in a step
width as dened in the line “edit step”.
The line “set value” displays the nominal value
for the output voltage as adjusted by the user.
Voltage adjustment can only be made in this line.
