Sureshotgps HERO 150X Manual de usuario
User Manual
Version 1.0
Getting to know your
Up (forward)
Down (backwards) Power On/Off
Page key for
scrolling between
two mapping
screens
Please read the following information in this booklet to ensure you gain the full benet of
all the features in your Sureshotgps™Hero 150x
Table of Contents
Page
1. Getting Started 5
Check the contents of your box 5
Fully charge the Sureshotgps™ battery 5
Registering on line 5
2. How to Download a Course Map 6
3. Understanding GPS 7
What is GPS and how does it work? 7
Satellites and reception 7
Can I use my GPS inside the home or ofce? 7
Best position for accuracy of my Sureshotgps™ 7
4. Navigating around your Sureshotgps™ Hero 150x 8
Start Menu 8
GPS Signal 8
Front, center and back of each green 9
Auto course searching 9
5. Setting Menu 10
Metres or Yards 10
Round Time 10
Backlight Setting 11
Set Time 11
Model Information 12
Course Information 12
6. Measuring Shot Distance 13
Please read the following information in this booklet to ensure you gain the full benet of
all the features in your Sureshotgps™ Hero 150x
Table of Contents
Page
7. Editing, Front, Centre and Rear of Green 14
8. Technical and Product Support 15
7. Frequently Asked Questions 15
8. Limited Warranty 16
9. Declaration of Conformity 18
1. Getting Started
The contents of your Sureshotgps™ Hero 150x Box should include:
• Sureshotgps™ Hero 150x unit with belt clip
• Quick start guide
• USB Cable
Fully Charge your Sureshotgps™ Hero 150x Lithium Ion battery.
• Before you start using your Sureshotgps™ Hero 150x you must fully charge
the internal lithium ion battery for approximately 6 hours or overnight.
A charging icon will appear on the screen when charging begins.
The Hero 150x will charge fastest when it is turned off.
• You cannot over charge the battery so you can leave it charging in between
uses.
• You can charge the Hero 150x using the supplied USB cable and connecting it
to a computer.
Registering on line
To begin using your Sureshotgps™ Hero 150x, the product must rst be registered
online. Registering will activate your warranty.
• You will need to have an internet connection
• You need to go to www.sureshotgps.com
• Click on “register” on the right hand side menu bar and follow the prompts
2. How to Download New Course Maps
Your Sureshotgps™ Hero 150x comes preloaded with Australia and New Zealand
courses, if you wish to delete, update or download more courses please follow the
instructions below.
• Connect to the internet
• Connect your Sureshotgps™ Hero 150x to your computer via the USB
cable provided
• Go to www.sureshotgps.com
• Click on my Sureshotgps™ > Hero 150x
Please note: If this is the rst time you are downloading new courses to the unit you
must install the Sureanalysis software (once you have selected your GPS model,
click download software and follow the prompts to install).
You must also install the software if you change computers.
SureAnalysis works only in conjunction with our website www.sureshotgps.com.
Click on “My SureshotGPS”.
From the menu, you can interact with your Sureshotgps™ Hero 150x.
To interact with the Sureshotgps™ Hero 150x, the unit needs to be connected via the
USB port and turned on.
3. Understanding GPS
What is GPS and how does it work?
Your Sureshotgps™ Hero 150x uses the Global Positioning System [GPS] to work out
how far you are from the front, centre and rear of each green. The system relies on
the Sureshotgps™ 150x receiving signals from orbiting GPS satellites.
How long does it take to gain reception from the satellites?
Always turn your Sureshotgps™ 150x on for at least ve minutes before you wish to
use it.
Can I use my Sureshotgps™ 150x inside the home or ofce?
Your Sureshotgps™ 150x will not generally gain reception inside. For best accuracy,
your Sureshotgps™ should have an unimpeded view of the sky.
When playing, what position is best for accuracy of my Sureshotgps™ Hero
150x?
You should clip your Sureshotgps™ 150x to a position on your buggy or bag that
maximises clear view of the sky. A range of accessories are available such as cart
mount kits and pull cart kits on www.sureshotgps.com.
GPS accuracy is affected by a number of factors, including satellite positions, noise in
the radio signal, atmospheric conditions, and natural barriers to the signal. Noise can
create an error between 5 to 10 meters and results from static or interference from
something near the receiver or something on the same frequency.
The most accurate determination of position occurs when the satellite and receiver
have a clear view of each other and no other objects interfere.
How do I Check for GPS Signal?
Before checking, ensure you have maximum clear sky above and the Sureshotgps™
Hero 150x has been on for at least ve minutes.
At the top of the main screen on the right there is a satellite icon.
When it is solid [not ashing] you have good satellite strength.
4. Navigating around your Sureshotgps™ Hero 150x
For best GPS reception always ensure you are in an open area
Start Menu
Press Power on/Enter key for 3 seconds until the power is on.
Three options are listed on the start menu: <Play>, <Settings>
andb<Power off>.
You can move the mark by pressing <Up arrow> and
<Down arrow> to the selected option and then press enter.
Satellite Position
You can enter the main menu after choosing
<Play> on the start menu.
You will see a satellite icon on the top right corner that ashes
when you start your Sureshotgps™ Hero 150x for the rst time.
This means it is searching for satellites. The icon will stop
ashing once it has locked in and you can then use all of the
functions of the device.
Main Menu
This display will be used most frequently when you use your Sureshotgps™ Hero
150x.
You can choose <Play> on the start menu and press Enter; alternatively, you can
press Enter for 3 seconds to return to the start menu on any menu; then you can
choose <Play> and press Enter.
4. Navigating around your Sureshotgps™ Hero 150x
For best GPS reception always ensure you are in an open area
The main menu displays the distance between you and the front,
centre and rear of each green.
You can press the Up and Down Key to move to the next hole or
any other hole.
If current hole number is <1>, you can press the Up key to
switch to the second hole and you will see the hole number in
the bottom left corner change into <2>
The menu will display the distance from you and the front, centre
and rear of the second hole.
This menu also displays battery status, satellite reception status,
current hole number and real time.
Automatic Course Searching
The Sureshotgps™ Hero 150x can provide an automatic course
searching service; when you arrive at a course, stay at the start
menu until the satellite icon has stopped ashing.
The Sureshotgps™ Hero 150x will ask if you want to select the
course it has chosen. You can choose <Yes> to use the course
information or choose <Play Previous> to maintain original
course setting or choose <Select Course> to select the course
you need in the course list.
Please note you must have previously up loaded courses onto
your Sureshotgps™ Hero 150x before applying the auto course
searching function.
*please note, the courses will only display once you are at the Course.
5. Settings Menu
Before using your Sureshotgps™ Hero 150x please go to
settings.
After you move the mark to item\ <Settings> with Down arrow
and press Enter on the start menu, you will see the following
items:
Distance measure
Metres or Yards
Distance measure is preset to metres.
If you want to change it into yards, you can choose
<Metre/Yard> on the setting menu and press Enter, the unit will
be changed into yards if you press Enter again, it will switch
back to metres.
Round Time
The Sureshotgps™ Hero 150x provides a simple timer to enable
you to view the time taken to play your round of golf.
You can return the timer to zero at any time by selecting
<Reset Timer> and pressing Enter.
You can view the time taken during your game by going to the
Course Card page.
This page can be located anytime by pressing the page key.
