Suprema Biostation Manual de usuario

www.supremainc.com

Innovative Fingerprint Terminal

Installation Guide

(ver 1.1)

EN 101.00.BST V1.31

Contents

Product Contents 3

Connectors for External Interfaces 5

Cable and Connector Pinout 6

Installation Example 7

Product Dimension 8

Installation of Wall-mount Bracket 9

Power Connection 10

USB Cable Connection 11

LAN Connection 12

Wireless LAN Connection 13

RS485 Network Connection 14

USB Memory Connection 15

Intercom Connection 16

Relay Connection –Fail Safe Lock 17

Relay Connection –Fail Secure Lock 18

Relay Connection -Automatic Door 19

TTL Input Port Connection –RTE Switches 20

TTL Output Port Connection 21

Wiegand Input Connection –External reader 22

Wiegand Output Connection –Control Panel 23

Ferrite Core Installation 24

System Specification 25

Electrical Specification 26

FCC Rules 27

Product Contents

Basic Contents

Product Contents

BioStation fingerprint terminal Wall mounting metal bracket

USB cable

Wall mounting

screwsand holders - 3 ea Star-shape screw for fixing

main body

Star-shape small wrench

5pin, 3pin, 6pin, 4pin, 7pin cable –1 ea Software CD Diodes –1 ea

Product Contents

Optional accessories

USB fingerprint scanner

for enrollment on PC

12V power adaptor Plastic stand type A

Interphone

Wireless LAN Access Point

Secure I/O USB Mifare

reader/writer

Connectors for External Interfaces

Bottom

Rear

Slot for USB memory device : USB type A

Slot for PC USB connection : Mini USB

Ethernet cable connector : RJ45

3pin cable connector -Door

6pin cable connector –Input/Output or Wiegand

4pin cable connector -RS485

7pin cable connector -RS232 or BEACon

5pin cable connector –Power and doorphone

12V power adaptor

Cable and Connector Pinout

PIN PIN DESCRIPTION WIRE

1PWR +VDC RED

2PWR GND BLACK

3INPH AUD ORANGE

4INPH DTA BLUE

5SH GND GRAY

Power & Doorphone

Relay

TTL I/O or Wiegand

RS485

RS232

PIN PIN DESCRIPTION WIRE

1RLY NO WHITE

2RLY COM BLUE

3RLY NC ORANGE

PIN PIN DESCRIPTION WIRE

1TTL / WG IN0 BLUE

2TTL / WG IN1 YELLOW

3TTL / WG OUT0 GREEN

4TTL / WG OUT1 WHITE

5TTL / WG GND BLACK

6SH GND GRAY

PIN PIN DESCRIPTION WIRE

1485 TRXN YELLOW

2485 TRXP BLUE

3485 GND BLACK

4SH GND GRAY

PIN PIN DESCRIPTION WIRE

1232 GND BLACK

2232 TX BLUE

3232 RX YELLOW

4TTL OUT1 WHITE

7SH GND GRAY

Before Start

Installation Example

Exit Button

Door Lock

PC Network hub

6pin cable

3pin cable

7pin cable

Ethernet

USB

RS232

Product Dimension

BracketFront Side

128

135

128

108

112

(unit : mm)

Installation of Wall-mount Bracket

Fix wall mount bracket on a wall using wall

mounting screws

Hook BioStation on the wall mount bracket.

Wall Mounting

Screws

Star-shape Screw

Star-shape Small Wrench

Fix BioStation and wall mounting bracket using a

star shape screw.

Power Connection

Method 1

Method 2

Recommended power supply

12V ±10%, at least 2500mA for BioStation alone installation.

Comply with standard IEC/EN 60950-1

Use a separate power supply for Secure I/O, electric lock and BioStation respectively. If

connecting and using the power supply to these devices together, the devices may malfunction.

DC12V ADAPTOR

(1) PWR +VDC (Red)

(2) PWR GND (Black)
