USER’S MANUAL
Revision 1.1
SuperStorage Server
6039P-E1CR16H
6039P-E1CR16L
PB
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGESARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used in this product may expose you to lead, a
chemical known to the State of California to cause birth defects and other reproductive harm.
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.1
Release Date: September 29, 2017
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this
to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2017 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
33
SuperStorage Server 6039P-E1CR16H/L User's Manual
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the SuperStorage Server 6039P-E1CR16H/L.
Installation and maintenance should be performed by experienced technicians only.
on supported memory, processors, and operating systems (http://www.supermicro.com).
Notes
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
If you have any questions, contact our support team at:
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.
Warnings
Special attention should be given to the following symbols used in this manual.
Warning! Indicates high voltage may be encountered when performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
4
Preface
Contents
Chapter 1 Introduction
1.1 Overview...............................................................................................................................8
1.2 Unpacking the System .........................................................................................................8
1.3 System Features ..................................................................................................................9
1.4 Server Chassis Features....................................................................................................10
Control Panel ....................................................................................................................10
Front Features...................................................................................................................11
Rear Features ...................................................................................................................12
1.5 Motherboard Layout ...........................................................................................................13
Quick Reference Table......................................................................................................14
Chapter 2 Server Installation
2.1 Overview.............................................................................................................................17
2.2 Preparing for Setup ............................................................................................................17
Choosing a Setup Location...............................................................................................17
Rack Precautions ..............................................................................................................17
Server Precautions............................................................................................................18
Rack Mounting Considerations .........................................................................................18
Ambient Operating Temperature....................................................................................18
............................................................................................................................18
Mechanical Loading.......................................................................................................18
Circuit Overloading ........................................................................................................19
Reliable Ground.............................................................................................................19
2.3 Installing the System into a Rack.......................................................................................20
Identifying the Sections of the Rack Rails........................................................................20
Releasing the Inner Rails..................................................................................................20
Installing The Inner Rails on the Chassis.........................................................................21
Installing the Outer Rails on the Rack..............................................................................22
Installing the System into a Rack .....................................................................................23
Chapter 3 Component Installation and Maintenance
3.1 Removing Power ................................................................................................................24
3.2 Accessing the System........................................................................................................24
3.3 Motherboard Components..................................................................................................25
Processor and Heatsink Installation..................................................................................25
5
SuperStorage Server 6039P-E1CR16H/L User's Manual
The Xeon Scalable Processor.......................................................................................26
Overview of the Processor Socket Assembly................................................................26
Overview of the Processor Heatsink Module (PHM).....................................................28
Assembling the Processor Package..............................................................................29
Assembling the Processor Heatsink Module (PHM) .....................................................30
Removing the Processor Heatsink Module from the Motherboard ...............................31
Installing Memory ..............................................................................................................32
Memory Support ............................................................................................................32
DIMM Installation ..............................................................................................................33
DIMM Removal .................................................................................................................33
Installing PCI Expansion Cards ........................................................................................34
..........................................................................34
Motherboard Battery .........................................................................................................35
3.4 Chassis Components .........................................................................................................36
Hard Drives .......................................................................................................................36
Hard Drive Backplane .......................................................................................................37
Optional Hot-Swap Hard Drives ...................................................................................37
Logical Drive Numbers ..................................................................................................39
System Cooling .................................................................................................................40
System Fan Failure .......................................................................................................40
Air Shroud......................................................................................................................40
Power Supply ....................................................................................................................42
Power Supply Failure ....................................................................................................42
Replacing the Power Distributor .......................................................................................43
Chapter 4 Motherboard Connections
4.1 Power Connections ............................................................................................................44
4.2 Headers and Connectors ...................................................................................................45
Control Panel ....................................................................................................................49
4.3 Ports ...................................................................................................................................52
4.4 Jumpers..............................................................................................................................54
Explanation of Jumpers.....................................................................................................54
4.5 LED Indicators....................................................................................................................57
6
Preface
Chapter 5 Software
5.1 OS Installation....................................................................................................................60
Installing the Windows OS for a RAID System ................................................................60
Installing Windows to a Non-RAID System ......................................................................60
5.2 Driver Installation................................................................................................................61
5.3 SuperDoctor®5...................................................................................................................62
5.4 IPMI ....................................................................................................................................63
Chapter 6 BIOS
6.1 Introduction.........................................................................................................................64
6.2 Main Setup .........................................................................................................................65
.........................................................................................67
6.4 Event Logs .........................................................................................................................93
6.5 IPMI ................................................................................................................................... 95
6.6 Security...............................................................................................................................98
6.7 Boot ..................................................................................................................................102
6.8 Save & Exit.......................................................................................................................105
Appendix A BIOS Codes
Appendix B Standardized Warning Statements for AC Systems
Appendix C System Specications
Appendix D UEFI BIOS Recovery
7
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: +1 (408) 503-8000
Fax: +1 (408) 503-8008
Email: [email protected] (General Information)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: +31 (0) 73-6400390
Fax: +31 (0) 73-6416525
Email: [email protected] (General Information)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: +886-(2) 8226-3990
Fax: +886-(2) 8226-3992
Website: www.supermicro.com.tw
SuperStorage Server 6039P-E1CR16H/L User's Manual
8
SuperStorage Server 6039P-E1CR16H/L User's Manual
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the 6039P-E1CR16H/L.
The 6039P-E1CR16H/L is based on the X11DPH-T motherboard and the 836BE1C-R1K23B
chassis.
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
1.2 Unpacking the System
Inspect the box that the SuperStorage Server 6039P-E1CR16H/L was shipped in and note
the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well-ventilated. Avoid areas where heat, electrical noise, and
precautions and considerations noted in Appendix B.
Main Parts List
Description Part Number Quantity
Air Shroud MCP-310-39001-0N 1
Heatsink SNK-P0068PS 2
Hard Drive Backplane BPN-SAS3-836EL1 1
Front Hot-swap Hard Drive Trays MCP-220-00075-0B 16
Rear Hot-swap Dual Hard Drive Tray (optional) MCP-220-83605-0N 1
Power Distributor PDB-PT826-8824 1
System Fans (Rear Exhaust) FAN-0125L4 2
System Fans (Middle Cooling) FAN-0158L4 3
SuperCap for SAS3108 Controller* (optional) BTR-TFM8G-LSICVM02 1
8-port Mini SAS Cable Adapter AOM-SAS3-8I8E 1
Rack Rail Mounting Kit MCP-290-00053-0N 1
*Note: Only included with the 6039P-E1CR16H.
9
Chapter 1: Introduction
1.3 System Features
The following table provides an overview of the main features of the 6039P-E1CR16H/L.
System Features
Motherboard
X11DPH-T
Chassis
836BE1C-R1K23B
CPU
Intel Xeon 81xx/61xx/51xx/41xx/31xx series processors* [Socket P0-LGA 3647 processor with up to 28 cores
and a thermal design power (TDP) of up to 205W]
Socket Type
P0-LGA 3647
Memory
Supports up to 512GB of RDIMM or 2TB of 3DS LRDIMM DDR4-2666 (288-pin) ECC memory in 16 DIMM slots
Chipset
Intel C624 chipset
Expansion Slots
Four PCI Express 3.0 x8 Slots
Three PCI Express 3.0 x16 Slots
(Slots 2 and 3 occupied by controller and JBOD expansion port)
Hard Drives
Sixteen 3.5" hard drives in hot-swap drive carriers (option for additional two 2.5" hard drives in the rear)
Power
Dual (redundant) 1200W power supply modules (p/n PWS-1K23A-1R)
Form Factor
3U rackmount
Dimensions
(WxHxD) 17.2 x 5.2 x 25.5 in. (437 x 132 x 647 mm)
*Note: Does not support FPGA or Fabric processors.
10
SuperStorage Server 6039P-E1CR16H/L User's Manual
Figure 1-1. Control Panel View
1.4 Server Chassis Features
Control Panel
The switches and LEDs located on the control panel are described below. The control panel
is located on the left handle of the chassis. See Chapter 4 for details on the control panel
connections.
Control Panel Features
Item Feature Description
1Power Button
The main power button is used to apply or remove power from the power supply
but maintains standby power. To perform maintenance tasks, you must also
unplug the system before servicing.
2Reset Button The reset button is used to reboot the system.
3Power LED Indicates power is being supplied to the system power supply. This LED should
normally be illuminated when the system is operating.
4HDD LED
5NIC1 LED
6NIC2 LED
7Information LED Indicates one of multiple conditions. Refer to the table on the following page for
more information.
8Power Fail LED
Indicates a power supply module has failed. The redundant power module
keeps the system running, but the failed module needs to be replaced. This
1876543 2
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Servidor de almacenamiento en red de Supermicro
Manuales populares de Servidor de almacenamiento en red de otras marcas
HP
HP NetStorage 6000 Manual de usuario
Seagate
Seagate U10 ST320423A Manual de usuario
Synology
Synology RackStation RS816 Manual
D-Link
D-Link ShareCenter Pro DNS-1200-05 Manual de usuario
Avid Technology
Avid Technology VideoRAID ST Guía de seguridad
Western Digital
Western Digital My Cloud Home Duo Manual de usuario
