Supermicro AOC-URG4N4-b2XT Manual de usuario

User's Guide

Revision 1.0

AOC-URG4N4-b2XT

User's Guide Revision 1.0

Release Date: September 2, 2022

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

The information in this user's guide has been carefully reviewed and is believed to be accurate.

The manufacturer's assumes no responsibility for any inaccuracies that may be contained in this

document, and makes no commitment to update or to keep current the information in this user's

guide, or to notify any person or organization of the updates. Please Note: For the most up-to-date

version of this user's guide, please see our Website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this user's guide at any time and without notice. This product, including software and

documentation, is the property of Supermicro and/or its licensors, and is supplied only under a

license. Any use or reproduction of this product is not allowed, except as expressly permitted by

the terms of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE

USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.

SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between the manufacturer and the customer shall be governed by the laws of

Santa Clara County in the State of California, USA. The State of California, County of Santa Clara

shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for

all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in an industrial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the manufacturer’s instruction manual, may cause harmful interference with

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference, in which case you will be required to correct the interference at your own expense.

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproduc�veharm. Formore informa�on, go

to www.P65Warnings.ca.gov.

Preface

About this User's Guide

This user's guide is written for system integrators, PC technicians, and

knowledgeable PC users. It provides information for the installation and use of the

AOC-URG4N4-b2XT add-on card.

About this Add-on Card

Ultra Riser Cards are the most advanced Riser Cards in the market. They provide

PCI-E 4.0 expansion slots for the latest Gen. 4 PCI-E add-in cards while function-

ing as networking devices with various LAN controllers. The AOC-URG4N4-b2XT

provides two ports 10GbE networking solution based on Broadcom®BCM57416,

an internal PCI-E 4.0 x16 slot, and four NVMe ports to provide the exibility of

conguring Supermicro Ultra systems.

An Important Note to the User

All images and layouts shown in this user's guide are based upon the latest PCB

Revision available at the time of publishing. The card you have received may or

may not look exactly the same as the graphics shown in this user's guide.

Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required before

any warranty service will be rendered. You can obtain service by calling your ven-

dor for a Returned Merchandise Authorization (RMA) number. When returning the

motherboard to the manufacturer, the RMA number should be prominently displayed

on the outside of the shipping carton, and the shipping package is mailed prepaid

or hand-carried. Shipping and handling charges will be applied for all orders that

must be mailed when service is complete. For faster service, You can also request

a RMA authorization online (http://www.supermicro.com/RmaForm/).

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alternation, misuse, abuse, or improper

maintenance of products.

During the warranty period, contact your distributor rst for any product problems.

Preface

iii

Super AOC-URG4N4-b2XT Add-on Card User's Guide

Conventions Used in the User's Guide

Pay special attention to the following symbols for proper system installation and to

prevent damage to the system or injury to yourself:

Warning: Important information is given to ensure proper system installa-

tion or to prevent damage to the components or injury to yourself.

Note: Additional information is given to di󰀨erentiate between various mod-

els or provides information for the correct system setup.

Naming Convention

Preface

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: +1 (408) 503-8000

Fax: +1 (408) 503-8008

Email: [email protected] (General Information)

[email protected] (Sales Inquiries)

[email protected] (Gov. Sales

Inquiries)

[email protected] (Technical Support)

[email protected] (RMA Support)

[email protected] (Webmaster)

Website: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: +31 (0) 73-6400390

Fax: +31 (0) 73-6416525

Email: [email protected] (Sales Inquiries)

Support_Europe@supermicro (Technical Support)

RMA_Europe@supermicro (RMA Support)

Website: www.supermicro.nl

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: +886-(2) 8226-3990

Fax: +886-(2) 8226-3992

Super AOC-URG4N4-b2XT Add-on Card User's Guide

Asia-Pacic

Email: [email protected] (Sales Inquiries)

[email protected] (Technical Support)

[email protected] (RMA Support)

Website: www.supermicro.com.tw

Table of Contents

Preface

Chapter 1 Overview

1-1 Overview ......................................................................................................... 1-1

1-2 Key Features................................................................................................... 1-1

1-3 Specications .................................................................................................. 1-2

1-4 Available SKUs ............................................................................................... 1-5

Chapter 2 Hardware Components

2-1 Add-On Card Image and Layout..................................................................... 2-1

2-2 Major Components.......................................................................................... 2-2

2-3 Ports................................................................................................................ 2-3

2-4 Connectors ...................................................................................................... 2-3

2-5 Jumpers........................................................................................................... 2-4

Installation

3-1 Static-Sensitive Devices.................................................................................. 3-1

3-2 Before Installation ........................................................................................... 3-2

3-3 Installing the Add-on Card .............................................................................. 3-2

3-4 Installing Drivers for Windows ........................................................................ 3-3

3-5 Installing Drivers (for Broadcom®BCM57416)................................................ 3-4

Preface

Chapter 1: Overview

1-1

Chapter 1

Overview

1-1 Overview

Congratulations on purchasing your add-on card from an acknowledged leader in

the industry. Supermicro products are designed with the utmost attention to detail

to provide you with the highest standards in quality and performance. For product

support and updates, please refer to our website at http://www.supermicro.com/

products/nfo/networking.cfm#adapter.

1-2 Key Features

The key features of this add-on card include the following:

• 1U Networking Ultra Riser card for 1U Ultra systems

• Dual 10GbE RJ45 ports

• Broadcom®BCM57416 Ethernet Controller

• One internal PCI-E 4.0 x16 slot

• Four NVMe ports (two Slim SAS x8)

• Low latency RDMA over Converged Ethernet (RoCE)

• Thermal sensor support

• NC-SI for Remote Management

• Supports RJ45 Category 6 and 6A cables

1-2

Super AOC-URG4N4-b2XT Add-on Card User's Guide

1-3 Specications

General

• Broadcom®BCM57416 dual-port 10Gbps controller

• PCI-E 3.0 x8 (8GT/s) interface

• Dual RJ45 connectors

• One internal PCI-E 4.0 x16 slot

• Four NVMe ports (two Slim SAS x8)

Networking Features

• Jumbo Frames (up to 9600-byte)

• 802.3x ow control

• Link Aggregation (802.3ad)

• Virtual LANs 802.1q VLAN tagging

• Congurable Flow Acceleration (CFA)

• IEEE 1588 and Time Sync

• RDMA over Converged Ethernet (RoCE)

• TruFlow Technology

Stateless O󰀪oad Features

• TCP, UDP, IPv4, IPv6 checksum o󰀪oad

• Large Send O󰀪oad (LSO)

• Receive Segment Coalescing (RSC)

• TCP Segmentation O󰀪oad (TSO)

Chapter 1: Overview

1-3

• Large Receive O󰀪oad (LRO)

• Receive Side Scaling (RSS)

• Transmit Side Scaling (TSS)

NIC Partitioning (NPAR)

• 16 Physical Functions

Virtualization Features

• NetQueue, VMQueue, and Multiqueue

• Support for 128 Virtual Functions

• VXLAN

• NVGRE

• Geneve

• Edge Virtual Bridging (EVB)

Flow Processing

• Exact/Wildcard Match Flow Lookup

• VLAN insertion/deletion

Data Center Bridging

• Priority-based Flow Control (PFC; IEEE 802.1Qbb)

• Enhanced Transmission Selection (ETS; IEEE802.1Qau)

• Quantized Congestion Notication (QCN; IEEE802.1Qau)

• Data Center Bridging Capability eXchange (DCBX; IEEE802.1Qaz)

• Eight tra󰀩c classes per port; fully DCB compliant per 802.1Qbb
