Superbrightleds EL-S Series Manual de usuario

LED Emergency Light

EL-Sx

4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com

Included Parts

Specications

EL-Sx

Total Power Consumption 6 W

Operating Voltage Range 120/277 VAC

Operating Temperature 14°–122° F (-10°–50° C)

Operating Humidity <90%

Fixture Weight 2.6 lb (1.2 kg)

Battery Type 6V4 5AH Sealed Lead Acid

Maximum Mounting Height 8.35 ft (2.54 m)

1 - xture

1 - hardware kit

¹Limited 2-year warranty on battery.

Testing

Manual Test

Test button can be held to illuminate lights for manual

testing purposes.

Wiring Diagram

User Manual

120 V Wiring

277 V Wiring

BLACK

WHITE

ORANGE

120 V POWER

NEUTRAL

N/C

BLACK

WHITE

ORANGE

N/C

NEUTRAL

277 V POWER

BLACK

WHITE

ORANGE

120 V POWER

NEUTRAL

N/C

BLACK

WHITE

ORANGE

N/C

NEUTRAL

277 V POWER

EL-SW

Rev Date: V2 04/09/2020

Important: Read all instructions prior to installation. SAVE THESE INSTRUCTIONS.

Important Safeguards

Read and follow all safety instructions. When using electrical

equipment, basic safety precautions should always be followed

including the following:

• This product should be installed and serviced by a certied

electrician in accordance with applicable national, state, and

local building and electrical codes.

• Light must be maintained, tested, and serviced in

accordance with all applicable National Fire Protection

Association (NFPA) and local codes.

• To reduce the risk of electric shock, ensure that the main

power source and circuit breakers are switched o󰀨 before

performing any installation or wiring procedures.

• Ensure xture is securely mounted and mount will support

weight of the xture. Failure to properly support xture may

result in damage or injury, for which the manufacturer does

not assume responsibility.

• Equipment should be mounted in locations and at heights

where it will not be subjected to tampering by unauthorized

personnel.

• Indoor use only—do not use outdoors.

• Do not mount near gas or electric heaters or any other

radiant heat sources.

• Use caution when handling or servicing the battery pack.

• For conduit wiring installation, use exible conduit only

• The use of accessory equipment not recommended by the

manufacturer may cause an unsafe condition.

• Do not use this equipment for anything other than its

intended use.

Installation Instructions

1. Carefully remove mounting panel by using a at-head

screwdriver to release tabs in two lower slots.

2. Remove appropriate knockouts for wiring and mounting

from real panel.

3. Run wiring through mounting plate and connect

wiring to junction box. Cap unused wire.

(refer to wiring diagram)

Note: Orange and black wires should

never be connected at the same time.

4. Securely attach mounting panel to wall

or junction box with hardware.

5. Use a screwdriver to remove battery retaining bracket

from light and securely connect battery. Reinstall

battery retaining bracket.

6. Reattach light assembly to mounting

panel (FIG 3).

7. Apply power and allow battery pack to charge for at

least 24 hours before initial use/test.

8. After 24-hour period, press test button to make

certain lights are functioning as intended.

4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com

LED Emergency Light

EL-Sx

User Manual

11.80in

299.72mm

5.20in

132.08mm

16.08in

408.5mm

4.63in

117.65mm

2.97in

75.38mm

2.97in

75.38mm

2.60in

66.04mm

1.72in

43.688mm

2.30in

58.42mm

2.30in

58.42mm

3.06in

77.80mm

6.01in

152.65mm

11.80in

299.72mm

5.20in

132.08mm

16.08in

408.5mm

4.63in

117.65mm

2.97in

75.38mm

2.97in

75.38mm

2.60in

66.04mm

1.72in

43.688mm

2.30in

58.42mm

2.30in

58.42mm

3.06in

77.80mm

6.01in

152.65mm

Test Button

PCB

PCB Plug

Fixture

Battery

Retaining Bracket

Mounting Panel

Test Button

PCB

PCB Plug

Fixture

Battery

Retaining Bracket

Mounting Panel

¹Limited 2-year warranty on battery.

Rev Date: V2 04/09/2020

Important: Read all instructions prior to installation. SAVE THESE INSTRUCTIONS.
