Product Improvement Centre
EM0480 Recalibration Guide
Page 1 of 3
Step 1
Ensure the coffee grinder is switched off and
unplugged from the power outlet. Remove the
bean hopper from the motor base, push down
and turn anti-clockwise, see figure 1.
Step 2
To remove the top burr turn the grind
adjustment collar in an anti-clockwise
direction until it stops, see figure 2.
Note: The top burr can only be removed
when graphic arrow on the grind adjustment
collar is aligned with the arrow on the motor
base.
Step 3
Press and hold down the “UNLOCK” button at
the rear of the motor base and with the other
hand turn the grind adjustment collar anti-
clockwise until the graphic arrow on the collar is
aligned with the arrow on the motor base, see
figure 3.
Figure 1
Figure 2
Figure 3
Product Improvement Centre
EM0480 Recalibration Guide
Page 2 of 3
Step 4
Lift out the top burr from the grind adjustment
collar using the handle, see figure 4.
Step 5
Lift the grind adjustment collar away from the
motor base.
Step 6
Using a 10mm spanner or
socket, unscrew the cap nut in a
clockwise direction.
Tip: To hold the bottom burr in
place while unscrewing the cap
nut, insert a screw driver into the
unit and press it against the burr.
Figure 4
Figure 5
Product Improvement Centre
EM0480 Recalibration Guide
Page 3 of 3
Step 7
Remove the star washer, burr
blade and the lower burr.
Step 8
Add a spacer to make the grind
finer or remove a spacer to make
the grind coarser.
Note: One spacer is
approximately equivalent to 7
graduations on the grind
adjustment collar.
For assembly repeat the above
steps in reverse order.
Caution: During assembly and before securing the lower burr,
ensure the burr location hole is aligned with the burr location pin.
