Summit Professional FFBF181ESBI Manual técnico

DETAILED

INSTRUCTIONSFOR

USEOFUPRIGHT

REFRIGERATOR AND

FREEZER

FFBF181ESBI

FFBF249SSBI

FELIX STORCH, INC.

Summit Appliance Division

An ISO 9001:2015

registered company

770 Garrison Avenue

Bronx, New York 10474

www.summitappliance.com

[Type text]

545433

We thank you

forthe

confidence you have shown by

purchasing

our appliance. We wish

you much pleasure in its use.

The appliance is intended

solely for

household use,

and may be installed built-in

or freestanding.

This refrigerator/freezer

(hereinafter: the

appliance) consists

of two parts: the upper

part is the

refrigerator and the lower part is

the freezer.

The refrigerator is intended for

storing fresh food at temperatures

above 0°C (32°F). The freezer is

intended for freezing fresh food

and for long-term storage of

frozen

food (up to one year,

depending on the

type of food).

545433

TABLE OF CONTENTS

Important Notes and Warnings

.....................................................3 - 4

Advice for Saving Power with Refrigeration

Appliances ................................................................................ 5

Appliance Description ...................................................................... 6

Installation and Connection ........................................................7 - 8

Operating the Appliance ...........................................................9 - 13

Appliance Interior Equipment .................................................14 - 17

Recommended Distribution of Food in the Appliance ................... 18

Storing Food in the Refrigerator .................................................... 19

Storing Food in the ZeroZone Drawer ....................................20 - 21

Freezing and Storing Frozen Food .........................................22 - 24

Freezing process ..................................................................... 22

Important warnings on freezing fresh food .............................. 23

Storage of industrially frozen food ........................................... 23

Frozen food storage time ......................................................... 24

Defrosting frozen food ............................................................. 24

Defrosting the Appliance ............................................................... 25

Cleaning the Appliance ................................................................. 26

Troubleshooting ......................................................................27 - 28

Information about Appliance Noise ............................................... 29

Limited Warranty ........................................................................... 31

[Type text]

545433

IMPORTANT

NOTES

AND WARNINGS

////////////////////

This appliance can be used by children aged from 8

years and above and

persons with reduced physical,

sensory or metal capabilities or lack of

experience and knowledge if they have been given supervision or

instruction

concerning use of the appliance in a safe

way and understand the hazards

involved.

Children should not play with the appliance.

Cleaning and user maintenance should not be performed by

children without

supervision.

Before connecting the

appliance

to the power line,

please read carefully the

instructionsforusewhich describetheapplianceanditscorrectandsafeuse.The

instructions apply for several appliance types/models; thus, settings or

equipment may be described herein

which are not available in your appliance.

This instruction manual includes the NO FROST version/model of

the freezer

which is fitted with a fan and in which the

defrosting process is automatic.

Remove the packaging intended for protecting the appliance orparticular parts

duringtransport.

Spacers are fitted on the

corners of

the doors. Remove them and insert

the supplied plugs into

their slots

(only in some

models).

Before connecting the appliance to the power supply, let the appliance rest ina

vertical position for approximately 2 hours. This will reduce the possibility of

operational faults due to the effect of transport on the

cooling system.

The appliance must be connected to the power

line and grounded in

compliance with the effective

standards and regulations.

The appliance should not be used outdoors and it should not be exposed to

rain.

Do not store explosive substances such as aerosol cans

with a flammable

propellant in this appliance.

Beforecleaningtheappliance,unplugit

from the power line (unplug the power

cord from the walloutlet).

545433

If the power cord is damaged, it must be replaced by a

service technician or

other adequately trained person.

If the appliance will be out of use for a prolonged period of time, switch it off

using the relevant button,

andunplug the appliance from the powerline. Empty

theappliance,defrostit,cleanit,andleavethedoor

ajar.

If LED lighting does not work, call a service technician. Do not attempt to repair

the LED lighting yourself, as

there is danger of contact with high voltage!

To protect the environment, take the obsolete appliance to an authorized

home appliance collection

center.

Packaging is made of environmentally friendly materials that can be recycled,

disposed of, or destroyed without

any hazard to the environment.

A rating plate can be found in the appliance interior. If

the language on the

rating plate is not the language of

your choice or the language of your country,

replace it

with the one supplied.

DANGER:

Risk of child entrapment! Before you throw

away your old

refrigerator or freezer: take off the doors andleave the shelves inplace so that

children

maynoteasilyclimbinside.

WARNING!

Keepventilationopeningsinthe appliance enclosure or in the built-

instructure,clearof

obstruction.

WARNING!

Do not use mechanical devices or other

means to accelerate the

defrosting process, other than

those recommended by the manufacturer.

WARNING! Do not damage the refrigerant circuit.

WARNING!

Do not use electrical appliances inside

the food storage

compartments of the appliance,

unless they are of the type recommended by

the

manufacturer.

The symbol on the product or its packaging indicates that the product should not

be treated as normal household waste. The product should be taken to an

authorized collection center for waste electric and electronic equipment

processing. Correct disposal of the product will help prevent any negative effects

on the environment and health of people which could occur in case of incorrect product

removal. For detailed information on removal and processing of the product, please

contact the relevant municipal body in charge of waste management, your waste

disposal service, or the store where you bought the product.

–Save these instructions –

[Type text]

545433

ADVICE FOR SAVING POWER WITH

REFRIGERATION APPLIANCES

•

Install the appliance as speciﬁed in the instruction manual.

•

Donot openthe door more often than necessary.

•

Occasionally make sure air circulation underneath the appliance is unobstructed.

•

Condenser unit on the rear wall should be kept clean (see chapter

Cleaning the

appliance).

•

If the gasket is damaged or does not provide a perfect seal for other

reasons, have it

replacedas soon as possible.

•

Store the food in tightly sealed containers or appropriate packaging.

•

Before placing the food in the appliance, cool it to room temperature.

•

Defrost frozen food in the refrigerator compartment.

•

Remove the drawers fromthe freezer compartment as described inthe

instruction

manual,in orderto make use of the entire interior.

•

Defrost your conventional freezer when anapproximately 3-5 millimeter

(1/8 to 1/4 inch) layer of frost or ice has built up on the refrigerated surfaces.

•

Make sure the layout of shelves in the compartment is uniform and that

the food is

placed so that the air can freely circulate in the appliance

interior (observe the

recommended placement of food as described in

the instructions).

•

In appliances with a fan, do not block the fan slots.

•

If you do not need the fan or the ionizer, switch them off to reduce power

consumption.

545433

APPLIANCE DESCRIPTION

A 5

A Refrigerator

1 Control unit

2 Led lighting of refrigerator

interior

3 IonAir air ionizer (+ on/off

switch)*

4 Pull-out glass shelf (height

adjustable)

Bottle rack

6 ZeroZone drawer

7 CrispZone fruit and

vegetables drawer with

humidity control

SimpleSlide

height-adjustabledoorbin

9 Bottle bin

B Freezer

Freezer drawers

Glass shelves

•

Applianceinterior equipment may change according to the appliance model.

•

The drawers are protected against pulling out. To remove a drawer from the

appliance,

open it, then lift the front part and pull it out.

* Only in some models

545433

INSTALLATION AND

CONNECTION

SELECTING THE ROOM

•

Do not install the refrigerator where temperatures will be below 55°F or

above 110°F,

because it will not maintain proper temperatures and the

refrigerator could develop high internal humidity.

Warning:

Make sure the room where the appliance is installed is large enough.

There

should be at least

yd3 of space per 0.37 ounces of refrigerant. Amount

of refrigerant is stated

on the rating plate in the appliance interior.

INSTALLING THE APPLIANCE

max

30 mm

Applianceinstallationshouldbe

carried

out by at least two persons to

avoid

any physical injury or damage to

the appliance.

•

The appliance must stand level or

tilted slightly backwards, stable on a

solid base. At the front, the

appliance is ﬁtted with two adjustable

legs that can be used

to level the

appliance. At the rear side,

casters

allow for easier installation of the

appliance (only with some models).

•

There should be a clearance of at

least 5

cm (2”) between the

appliance and any

cupboard

installed above it, in order to

allow

adequate cooling of the condenser

unit.

•

Do not expose the appliance to

direct

sunlight and do not place it

near any

source of heat. If this

cannot be avoided, install an

insulation panel.

688 mm

640 mm

1201 mm

1249 mm

545433

•

This appliance is intended for built-in installation, but it may also be installed

freestanding. When installed built-in, please allow these minimum clearances to ensure

the best operation and proper ventilation: 1/4” on one side (and even more space on

the hinge side to allow the doors to open wider than their width to make it easier to

remove shelves and storage bins), 5/8” at the rear and 1/16” at the top. Be sure that

airflow at the bottom of the appliance is not blocked.

Consider the clearance

required to open the door fully in order to allow pulling out the drawers and

shelves (see

installation diagram).

600mm

644mm

NOTE: The doors of your appliance are not user-reversible.

CONNECTING THE APPLIANCE

•

Connect the appliance to the powersocketusing a connection cable. The

wall outlet

should be ﬁtted with a ground contact (safety socket). Nominal

voltage and frequency

are indicated on the rating plate/label with basic

information on the appliance.

•

The appliance must be connected to the power line and grounded in

compliance

with the effective standards and regulations. The appliance will

withstand short-term deviations from the nominal voltage, but not more

than +/- 6%.

545433

OPERATING THE APPLIANCE

CONTROL PANEL

Appliance On key and

refrigerator

compartment Off key

Acoustic alarm Off key

Super cool On/Off key

Refrigerator compartment temperature

keys

Refrigerator temperature display

Freezer compartment On key and

appliance Off key

G ECO function On/Off key

H Super freeze On/Off key

I Freezer compartment temperature keys

J Freezer compartment temperature

display

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Refrigerador de Summit Professional

Summit Professional

Summit Professional FFBF181SS Manual de usuario

Summit Professional

Summit Professional FFBF181ESLHD Manual técnico

Summit Professional

Summit Professional FF64B Manual de usuario

Summit Professional

Summit Professional SPR315OS Manual de usuario

Summit Professional

Summit Professional FFBF240W Manual de usuario

Summit Professional

Summit Professional SPFF51OS Manual de usuario

Summit Professional

Summit Professional FFBF249SS Manual de operación y mantenimiento

Summit Professional

Summit Professional FF1532B Manual de usuario

Summit Professional

Summit Professional ALR15B Manual de usuario

Summit Professional

Summit Professional FF1075W Manual de usuario

Summit Professional

Summit Professional SPR316OS Manual de usuario

Summit Professional

Summit Professional FFBF181ESBIIM Manual técnico

Summit Professional

Summit Professional ALB651 Series Manual de usuario

Summit Professional

Summit Professional FF874 Manual de usuario

Summit Professional

Summit Professional FFBF181ES Manual de operación y mantenimiento

Summit Professional

Summit Professional FFBF181SSBI Manual de usuario

Summit Professional

Summit Professional FF1078B Manual de usuario

Summit Professional

Summit Professional AL54SSTB Manual de usuario

Summit Professional

Summit Professional ASDS1523 Manual de usuario

Summit Professional

Summit Professional FFRF3070B Manual de usuario

Summit Professional

Summit Professional FF1074 Manual de usuario

Summit Professional

Summit Professional FF1538B Manual de usuario

Summit Professional

Summit Professional SPR628BCSS Manual de usuario

Summit Professional

Summit Professional FFBF245SS Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
