Installing TeamViewer for remote support
1. Ensure the LAN functionality in TeamViewer is enabled (go to Extras > Options
> General > Incoming LAN connections). Using TeamViewer over LAN allows
for much faster operation and better quality. SubC recommends using a LAN
connection whenever possible.
2. You can obtain TeamViewer 8 software from:
https://community.teamviewer.com/t5/Knowledge-Base/Download-TeamV
iewer-8-and-9/ta-p/78348
Contact support
Telephone
+1 (709) 702-0395
Email
Web
www.subcimaging.com
Mail
SubC Control Ltd
327 Memorial Drive
Clarenville, NL, Canada
A5A 1R8
3. Install and open Teamviewer on your
computer. You will see a window similar to the
one below.
4. Make note of the Your ID and Password fields.
5. Contact SubC tech support and provide them
with your codes; they now have remote
access and can help with any issues that may
arise.
Support Engineered in Canada
3
Please read this manual carefully before setting-up and using your unit. The electronic version of this document is the controlled copy. Therefore, all printed
versions of this document are uncontrolled.
1. SubC equipment is designed to work at various depth ratings on unmanned vehicles. Designs are tested to their full pressure rating. Production units are
pressure-tested to a nominal rating to ensure no leaks. If using our equipment on vehicles containing people, you do so at your own discretion as
SubC does not certify equipment for direct human contact underwater. Manned submersibles require equipment to have additional pressure-testing
to ensure safety.
2. The camera has been designed for subsea usage. Observe the operating temperature specifications before prolonged usage in air. If camera is running
in a warm environment (>20°C), it automatically reduces the clock speed and decreases performance. Run the camera in water.
a. A CPU temperature error message will appear when the camera CPU reaches 80°C.
b. An ambient temperature error will appear when the camera reaches 50°C.
3. The power supply is polarized. Ensure the correct polarity is used before plugging into the unit. There are many built-in protections on the camera pins,
however, incorrect electrical connections may still damage the internal electronics. See your camera’s datasheet for correct wiring. Some equipment
has a custom pinout selected at point of sale. Check your documentation before powering.
4. Water should not come in contact with the pins on the bulkheads. When not in use, use dummy plugs. If water touches the pins, use contact cleaner
and compressed air to remove the water.
5. Before attaching the connector to the camera, be certain that the pins are aligned, clean and lightly lubricated with appropriate silicone o-ring grease
(Ultimate o-ring lubricant for example http://www.ablesealanddesign.com).
6. All fasteners on the camera are metric. They should be hand tightened during regular maintenance.
Precautions and Maintenance
4
Best practices for assembling your system
Greasing the Connector/Dummy Plug (ABOVE WATER - DRY MATE ONLY)
A. Connectors must be greased with Molykote 44 Medium (or equivalent)
before every mating. Check the MSDS for your type of o-ring lubricant
before use.
B. A layer of grease corresponding to minimum 1/10 of socket depth should be
applied to the female connector
C. The inner edge of all sockets should be completely covered, and a thin
transparent layer of grease left visible on the face of the connector
D. After greasing, fully mate the male and female connector in order to secure
optimal distribution of grease on pins and in sockets
E. To confirm that grease has been sufficiently applied, de-mate and check for
grease on every male pin then re-mate the connector
O-Ring Lubricant
5
Best practices for assembling your system
For the fundamentals of how to capture excellent underwater photos and detailed video, check out
our Underwater Photography Guide:
https://issuu.com/subcimaging/docs/subc_underwater_photography_guide?fr=sZmI1MTI1MjM2MzM
1. SubC products are designed to run in water. There is built-in thermal protection in our
equipment, however, we cannot guarantee performance in air.
2. The camera, LED, and laser should be attached to a solid mounting point with either stainless
steel hose clamps OR a machined clamp. In between the mount point and the equipment, use
some neoprene rubber, electrical tape, or similar insulation material to prevent corrosion from
dissimilar metal contact.
3. To limit particle backscatter, the LED should be positioned as far away from the camera as
possible in the system while also angling the light so that there is sufficient overlap. The Rayfin
camera field of view is 80 degrees diagonal and the LED’s beam angle is also matched at 80. So
the light should be slightly further from the scene than the camera, which is easily achievable. If it
isn’t set up properly, you may end up with dark corners in the images.
4. When connecting the cables to the equipment, use o-ring lubricant. See page about o-ring
lubricant.
System Hookup
80˚80˚
PACKAGING AND
QUICKSTART GUIDES
Included with your Rayfin shipment:
1. Impact resistant shipping case with designed foam insert
2. Rayfin camera
3. Component compartment:
a. High-pressure dummy plugs for camera Aux0 & Aux1 bulkheads
b. DBH13F test whip bench testing the camera and downloading offline
c. AC cable (matching your region) and AC-DC power supply (24VDC)]
d. Cat5e Ethernet cable
4. Optional Components
a. Aquorea LED(s)
b. Laser(s) w/ calibrated delrin mount for attachment
c. 3m cable for camera Aux ports (MCIL5M to MCIL5F - for LEDs or lasers)
d. 0.5m Y-splice laser cable to plug into camera
e. 2x Titanium hose clamps for attachment of lasers to the camera
5. USB stick with:
a. Windows 10 compatible Rayfin Control Software
b. Product manuals
c. QC documentation
6. Documentation: complete QA checklist, pressure-test certificates, packing list
datasheets, and quick start guide (located under the lid foam)
HDE Packaging and Quality Control
PM: CC
Production: JMH Updated:
2020-11-03
1
2
34
4
5
6
Required Components
Rayfin Interface cable
Windows PC or laptop AC-DC power supply (24VDC)
Cat5e Ethernet cable AC cable
1. Ensure software is installed by following Software Install instructions.
2. Plug the 13-pin interface cable into camera.
3. Connect interface box Ethernet cable to the network or a router with
DHCP. The Windows PC or tablet has to be on the same network as
the Rayfin.
4. Connect the AC power supply cable to the interface box and plug in.
5. Follow Ethernet Connection instructions to connect to the camera from
the Rayfin Control Software.
AC-DC power
supply
Interface cable
Cat5e Router or
network
PC or laptop (for control)
HDE: Ethernet Quickstart
Bench Testing the Camera
8
PM: CC
Production: JMH
Software: AR
Updated:
2019-11-21
Required Components
Rayfin Interface cable
Windows PC or laptop AC-DC power supply (24VDC)
Cat5e Ethernet cable AC cable
HD-SDI cable
1. Ensure software is installed by following Software Install instructions.
2. Plug the 13-pin interface cable into camera.
3. Connect interface box Ethernet cable to the network or a router with DHCP. The
Windows PC or tablet has to be on the same network as the Rayfin.
4. Connect the AC power supply cable to the interface box and plug in.
5. Immediately after powering on the Rayfin camera, the bootup screen should be
visible on the HD-SDI monitor. It will say “RAYFIN” then a few seconds later it will
show the SubC logo followed by live video.
6. If you cannot see video on the monitor: In software, ensure the camera video is
being transmitted at a framerate and resolution the ROV system mux can handle.
Ex. 1080/30p is HD-SDI (1.5Gbps) and 1080/60p is 3G-SDI (3Gbps).
7. Follow Ethernet Connection instructions to connect to the camera from the
Rayfin Control Software.
AC-DC power
supply Interface cable
Cat5e Router or
network
HD-SDI monitor
HD-SDI cable ROV mux/demux
PC or laptop (for control)
HDC: HD-SDI + Ethernet Quickstart
Bench Testing the Camera and Getting Live HD Video
9
PM: CC
Production: JMH
Software: AR
Updated:
2019-11-21
Included with your Rayfin PLE shipment:
1. Impact-resistant shipping case with designed foam insert
2. Rayfin PLE camera
3. DCBoostBox
4. Component compartment:
a. High-pressure dummy plugs for camera Aux0 & Aux1 bulkheads
b. MCIL2F PLE Test Cable for bench testing camera and downloading
c. AC cable (matching your region) and AC-DC power supply (24VDC)
d. IP67 Rated Ethernet cable
5. Optional Components
a. Aquorea LED(s)
b. Laser(s) w/ calibrated delrin mount for attachment
c. 3m cable for camera Aux ports (MCIL5M to MCIL5F - for LEDs or lasers)
d. 0.5m Y-splice laser cable to plug into camera
e. 2x Titanium hose clamps for attachment of lasers to the camera
6. USB stick with:
a. Windows 10 compatible Rayfin Control Software
b. Product manuals
c. QC documentation
7. Documentation: complete QA checklist, pressure-test certificates, packing list
datasheets, and quick start guide (located under the lid foam)
8. Kevlar Tow Cable (if purchased)
9. Aux Cables: MCIL5M to MCIL5F (for LEDs or lasers)
PLE Packaging and Quality Control
7
8
9
5
PM: CC
Production: JMH Updated:
2021-03-18
1
2
3
4
5
6
