Subaru H001ssC800 Manual de usuario
AUDIO VIDEO & NAVIGATION SYSTEM
OWNERS MANUAL
ITEM QTY DESCRIPTION
1 1 AUDIO HEAD UNIT W/LABEL
2 1 AUDIO COVER
3 1 PORTABLE NAVI. DEVICE (PND)
4 1 POUCH FOR PND
5 1 MAIN HARNESS
6 1 SECONDARY HARNESS
7 1 RADIO ANTENNAADAPTER HARNESS
8 1 IPOD HARNESS (DOCK CABLE)
9 1 GPS ANTENNA W/ HARNESS
10 1 GPS ANTENNA SCREW
11 9 CABLE TIE
12 1 GROMMET FOR IPOD
13 1 INSTALLATION SPACER
14 8 M5 BOLT (4 IN KIT, 4 ON RADIO)
15 1 OWNER’S MANUAL
16 1 FOAM TAPE
TOM TOM IN-BOX KIT
17 1 TOM TOM CD MANUAL
18 1 USB CABLE
19 1 PND BACK COVER
20 1 PND QUICK START GUIDE
ADDITIONAL REQUIRED ITEMS (NOT IN KIT)
21 1 USB/AUX MODULE (PN: H621SAJ220)
: Remove
: Install
: Disconnect
: Connect
: Location of Clip or Screw
: Tighten Torque
: Loosen
:Discard
: Reuse
T
NOT IN KIT
113
4
15 20
17
19
18
10
14
12
2
3
8
659
21
7
11
16
1 ”
10MM 1-1/4” (32MM)
PUNCH
OR
1-1/4” (32MM)
HOLE SAW
SUBARU OF AMERICA PAGE
1/20
DATE
10/26/10
ISSUE
E
IMPREZA
installation instructions
PART NUMBER: H001SSC800
DESCRIPTION: IMPREZA PND NAVI. AUDIO UNIT
KIT CONTENTS:
TOOLS REQUIRED:
MEANING OF CHARACTERS:
# PART NAME
1 RADIO TRIM
2 RADIO COVER PLATE & POCKET
3 CENTER CONSOLE
4CENTER CONSOLE’S REAR COVER PLATE
5 CENTER CONSOLE METAL PLATE (IF EQUIPED)
6 CENTER CONSOLE TRIM
7 GEAR SHIFT TRIM
8 IP TRIM
9 INSTRUMENT PANEL UNIT (IP UNIT)
Disconnect all correspondingNOTE:
Connectors as you disassemble.
#DESCRIPTION
1 GPSANTENNA W/ BRACKET AND HARNESS
2 SECONDARY HARNESS
3 IPOD HARNESS (DOCK CABLE)
4 USB/AUX MODULE (AVAILABLE FROM SUBARU (PN: H621SAJ220))
5 RADIO ANTENNAADAPTER HARNESS
6 MAIN HARNESS
INSTALLATION OVERVIEW
DISASSEMBLY OVERVIEW
SUBARU OF AMERICA PAGE
2/20
DATE
10/26/10
ISSUE
E
IMPREZA
Throughout this installation.NOTE:
Before starting this installation make sure that the Vehicle is on a at surface. Failing to • do so could result in damages to the vehicle, to you, and/or others.
Take care of all disassembled vehicle components as they will be reinstalled (• ) into
the vehicle, unless noted ( ) and instructed differently. Use blankets, tape, and other
protective items to avoid scratching components.
After or during installation, trim (• ) excess from the Cable Ties.
.1-1
.1-2
PRE-INSTALLI.
Afx the Installation Spacer [13] 1.
to the Audio Unit [1] as shown.
Apply pressure across the entire part to- seat the adhesive.
Do not touch the surfaceCAUTION:
of the radio where the Spacer will be
adhered.
Align the edge of the
CAUTION:
Spacer with the seam on the Audio
Unit.
Cut the Foam Tape [16] provided 2. in the kit as shown.
Do not discard any of the cut Foam-
Tapes [16].
1”
(2.5 cm)
5”
(12.7 cm)
2”
(5.08 cm)
SUBARU OF AMERICA PAGE
3/20
DATE
10/26/10
ISSUE
E
IMPREZA
4. Remove 4 Screws.
Remove the Radio Cover Plate5. and Pocket.
Remove the Radio Trim.3.
Using the Nylon Pry Tool start by- releasing the bottom clips (1) and (2).
Avoid scratching theCAUTION:
dash and trim panel.
(1) (2)
DISASSEMBLYII.
Place the Vehicle into Park “P”1. with the Parking Brake set.
Disconnect the Negative Battery2. Terminal.
Note the battery cable position as it will- be reinstalled in the same position.
Do not touch the PositiveCAUTION:
Battery Terminal.
10MM
.2-1
.2-2
.2-3
SUBARU OF AMERICA PAGE
4/20
DATE
10/26/10
ISSUE
E
IMPREZA
Remove 2 Screws.9.
Open the Console.7.
Remove the Rubber Mat8. (if equipped).
Dislodge the Emergency Brake6. Trim.
Start by dislodging the front bottom clip- (1).
(1)
.2-4
.2-5
.2-6
SUBARU OF AMERICA PAGE
5/20
DATE
10/26/10
ISSUE
E
IMPREZA
Remove 1 Screw.12.
Remove Metal Plate.13.(if equipped)
Remove the Center Console’s11.Rear Cover Plate.
Remove 1 Screw.10.
.2-7
.2-8
.2-9
SUBARU OF AMERICA PAGE
6/20
DATE
10/26/10
ISSUE
E
IMPREZA
Dislodge the Center Console and16.tilt back.
Avoid scratching theCAUTION:
Center Console or the Vehicle.
Using the 1 1/4” (31.7mm)15.Punch or Hole Saw, make a hole
on the back side of the Center
Console as shown.
1 ”
Remove the rear Center Console14.Trim.
.2-10
.2-11
.2-12
SUBARU OF AMERICA PAGE
7/20
DATE
10/26/10
ISSUE
E
IMPREZA
.2-13
.2-14
.2-15
SUBARU OF AMERICA PAGE
8/20
DATE
10/26/10
ISSUE
E
IMPREZA
Remove the Vehicle’s18.AUX ONLY Module.
Using the Nylon Panel Removal Tool,- dislodge the AUX Module’s 4 clips
from the bottom of the Center Console.
- Discard the Vehicle’sAUX Module.
Avoid scratching theCAUTION:
Center Console.
Install the USB/AUX Module [21].19.
Disconnect the Vehicle’s17.Connectors from the bottom
of the Console.
Perform this step for Manual
Transmission Vehicles ONLY.
Unscrew the Gear Shift Knob and22.remove it.
Remove the Gear Shift Trim.23.
Lift to release the rear clips, then pull- backwards to release the front clips.
Perform this step for Automatic
Transmission Vehicles ONLY.
Place the Vehicle back into “P.”24.
Perform this step for Automatic
Transmission Vehicles ONLY.
Remove the Insert covering the20.Shift Override Button.
Make sure the Vehicle’sCAUTION:
Parking Brake is set.
Depress the Shift Override21.Button and move the Shifter
to “D.”
.2-16
.2-17
.2-18
SUBARU OF AMERICA PAGE
9/20
DATE
10/26/10
ISSUE
E
IMPREZA
Remove 2 Screws from the26.Instrument Panel.
Disconnect Instrument Panel27.connector from back side and
remove Instrument Panel from
the vehicle starting from the top.
Remove any clips that do not28.come off during the Instrument
Panel removal in g. 2-19.
Re-attach them to the Instrument29.Panel Trim.
Remove the Instrument Panel25.Trim.
The Instrument Panel Trim isNOTE:
in 2 parts. Grip both pieces and
pull from the bottom to avoid
separating the parts.
Avoid scratching theCAUTION:
Instrument Trim or Panel.
.2-19
.2-20
.2-21
SUBARU OF AMERICA PAGE
10/20
DATE
10/26/10
ISSUE
E
IMPREZA
