Sub-Zero DEC3050WAR Manual de usuario
Designer Series Wine Storage
Use and Care Guide
CLEANING, MAINTENANCE,
AND MORE
2 | Sub-Zero Customer Care 800.222.7820
Designer Series Wine Storage
Contents
3Designer Series Wine Storage
4Safety Precautions
6Designer Series Wine Storage Features
7Touch Controls
9Storage
11 Product Operation
12 Care Recommendations
13 Troubleshooting
15 Sub-Zero Warranty
subzero.com | 3
Customer Care
The model and serial number are printed on the enclosed
product registration card. Both numbers are also listed on
the product rating plate. Refer to page 6 for rating plate
location. For warranty purposes, you will also need the
date of installation and name of your authorized Sub-Zero
dealer. Record this information below for future reference.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certified Service Name
Certified Service Number
Authorized Dealer
Dealer Number
If your product ever needs attention, be sure to use a
Sub-Zero Factory Certified Service provider recommended
by our Customer Care Center, or select one from our list
of providers available at subzero.com/locator. All Factory
Certified Service providers are carefully selected and thor-
oughly trained by us.
Important Note
To ensure this product is installed and operated as safely
and eciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION
Indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING
States a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specified.
Designer Series Wine Storage
4 | Sub-Zero Customer Care 800.222.7820
IMPORTANT INSTRUCTIONS
WARNING
Do not store explosive substances such as
aerosol cans with a flammable propellant in
this appliance.
WARNING
Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
WARNING
Do not use mechanical devices or other
means to accelerate the defrosting pro-
cess, other than those recommended by the
manufacturer.
WARNING
Do not expose this appliance to rain.
WARNING
This appliance is only intended for residential
use.
WARNING
• This appliance contains flammable refrig-
erant and must be handled, installed, ser-
viced, and decommissioned by authorized
personnel. Once decommissioned, consult
local authorities for disposal instructions.
• To minimize the risk of ignition due to
improper installation, replacement parts,
or service procedures, only refrigeration
technicians with flammable refrigerant
training who are aware of the dangers of
dealing with high voltage electricity and
refrigerant under pressure are allowed to
work on this equipment.
• Do not damage the refrigeration circuit
when installing, maintaining, or servicing
the unit.
• This symbol indicates risk of fire/
flammable materials.
CAUTION
Incorporated ice makers must be installed by
the manufacturer or its service agent.
WARNING
Do not use electrical appliances inside the
food storage compartments of the appliance,
unless they are of the type recommended by
the manufacturer.
Safety Precautions
subzero.com | 5
IMPORTANT INSTRUCTIONS
WARNING
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or instruc-
tion concerning use of the appliance by a
person responsible for their safety. Children
should be supervised to ensure they do not
play with the appliance.
WARNING
DANGER: Risk of child entrapment. Before you
throw away your old refrigerator or freezer:
• Take o the doors.
• Leave the shelves and drawer dividers in
place so that children may not easily climb
inside.
WARNING
PROPOSITION 65 FOR CALIFORNIA RESIDENTS
Cancer and Reproductive Harm—
www.P65Warnings.ca.gov
This appliance is intended to be used in house-
hold and similar applications such as:
• sta kitchen areas in shops, oces, and other
working environments
• farm houses and by clients in hotels, motels,
and other residential type environments
• bed and breakfast type environments
• catering and similar non-retail applications
Safety Precautions
6 | Sub-Zero Customer Care 800.222.7820
Designer Series Wine Storage Features
Designer Series Wine Storage Features
FEATURES
1Product Rating Plate
2Touch Control Panel
3Wine Storage Racks
4Display Rack
5Full-View Glass Door
6Refrigerator Storage Drawers*
*Not available on all models.
Column model
3
5
4
2
1
Tall model
6
3
5
4
2
1
subzero.com | 7
Touch Controls
Touch Control Panel
For initial start-up, touch and hold on the control panel
for 2 seconds.
The temperature can be adjusted in one-degree incre-
ments on the home screen. The temperature on the left of
the display represents the lower zone and the temperature
on the right represents the upper.
To adjust temperature:
1 Touch the temperature to be adjusted.
2 Touch + or – until the desired temperature is displayed.
Refer to the illustration below.
To adjust additional settings, touch on the control
panel. Refer to the illustration below.
SETTINGS
Turn the unit on or o
Turn accent lighting on or o and adjust brightness and
select soft on duration
Turn door alarm on or o and adjust duration
Adjust drawer temperature*
Turn connect on or o (if applicable)
Turn Sabbath on or o
Adjust temperature units
Adjust door alarm volume and tone
Select language
System information
View troubleshooting and service information
*Not available on all models.
4555
Home screen
8 | Sub-Zero Customer Care 800.222.7820
Touch Controls
Connect This Appliance
Connect this appliance to remotely monitor and control it.
Connecting requires a wireless router, an Internet connec-
tion with a network name and password, and a compatible
mobile device. There is no limit to the number of appli-
ances you can connect to an account. Connect products
from multiple homes to the same account. Connecting
appliances is optional.
Connect today to:
• Receive alerts, status updates, and routine maintenance
notifications.
• Streamline everyday tasks with the help of remote con-
trols and voice commands.
• Quickly access user manuals and cleaning and mainte-
nance tips.
To connect:
1 Download the free Sub-Zero Group Owner’s App from
the Apple App Store or Google Play.
2 With Bluetooth®enabled on the device, stand within a
few feet of the appliance, open the app, and follow the
on-screen instructions.
3 Log in or create an account.
4 Tap Add An Appliance to add appliances. To identify
which appliance to pair, open the appliance door.
5 Tap + next to the appliance to select it. If identical
appliances appear, follow the additional step on the
screen to identify which appliance to pair.
6 Tap Pair Via Bluetooth®. Wait for setup to complete,
then tap Set Up Your Appliance For Pairing.
7 Tap Choose a Network on the Connect Your Appliance
to Wi-Fi screen.
8 Select the home Wi-Fi network and enter the network
password.
9 Tap Turn on Notifications to allow notifications about
the appliance (for example, door left ajar).
10 Tap Done on the Success screen to complete the setup.
subzero.com | 9
Storage
DISPLAY RACK
The adjustable display rack is designed for wine to stay in
contact with the cork at any position. Refer to the illustra-
tion below.
To remove the display rack, pull out to full extension, tilt
up, then lift up and out.
CAUTION
Remove all bottles from the display rack before
removal.
Display rack
Wine Storage
WINE RACKS
The full-extension wine racks provide easy access to
750 ml bottles, half-bottles, and magnums. When storing
magnums, the rack above must be removed.
To remove a wine rack, pull out to full extension, tilt up,
then lift up and out. Refer to the illustration below. The top
two racks in each compartment cannot be placed in any
other position. These racks can be identified by the small
square cutout located in the right rear corner. Refer to the
illustration below.
The natural cherrywood facing on wine racks can be
stained or replaced with wood to complement cabinetry.
For more information, refer to the Sub-Zero Design Guide,
visit our website at subzero.com, or contact Sub-Zero
Customer Care at 800-222-7820.
CAUTION
Remove all bottles from the wine rack before
removal.
CUTOUT
Wine rack removal
Rack position indicator
10 | Sub-Zero Customer Care 800.222.7820
Storage Drawers
DRAWER DIVIDERS (TALL MODEL)
To reposition a drawer divider:
1 To remove a short divider, flex the long divider slightly,
then pull upward. Refer to the illustration below.
2 One long divider in the top drawer is adjustable.
To remove a long divider, all short dividers must be
removed. Pull the long divider up until it stops, rotate
counterclockwise, then pull upward.
3 To install a long divider, align the grooves with the
drawer tabs, rotate clockwise, then slide down.
4 To install a short divider, position as desired, then slide
down.
SHORT DIVIDER
Drawer dividers
Storage
DRAWER REMOVAL (TALL MODEL)
To remove/install a storage drawer:
1 To remove, pull the drawer open until it stops. Raise the
front of the drawer slightly and pull straight out. Refer
to the illustration below.
2 To install, raise the front of drawer and place onto the
slides. Align the back of the drawer with hooks on the
slide, then align the white pegs at the front of the slide
with holes at the front of the drawer.
Drawer removal
