Sub-Zero 700TCI Manual de usuario

Integrated re rigeration can be used

anywhere in the home. It merges seamlessly

into the décor, with no visible hinges or

grilles. Model 700TCI has an upper cabinet

re rigerator with reezer storage drawers.

Two distinct temperature zones ensure the

reshest ood and energy e iciency. This

model is ENERGY STAR®quali ied or

energy e iciency.

27" Integrated

Combination—Tall

FEATURES

•Upper cabinet refrigerator and two freezer

storage drawers.

•Custom front panels and hardware allow

for infinite design options.

•Point-of-use refrigeration that can be

placed anywhere in the home.

•Dual refrigeration system ensures the

freshest food and energy efficiency.

•Microprocessor maintains precise control,

within 1° of set temperature.

•Easy-access, illuminated touch control

panel.

•Bright interior lighting in cabinet and

drawers.

•Adjustable spill-proof glass shelves, door

shelves and dairy compartment.

•Adjustable deli drawer with shelf for

storage of smaller items.

•mooth-glide, full-extension storage

drawers.

•Alarm feature will sound an audible beep

if door or drawer is left open.

•Automatic ice maker provides crescent-

shaped ice.

•90° door stop built into hinge.

•tar-K compliant with harness kit.

•Meets U. . Department of Energy

standards.

MODEL 700TCI

Design Integrated

ACCESSORIES

•tainless steel front panels with tubular or

pro handles—80" or 84" finished height.

•tainless steel tubular and pro handles.

•Dual installation kit for installation with

column, tall or drawer model.

•Crisper drawer and shelf assembly.

•Dozen egg container.

Accessories are available through your Sub-Zero

dealer. For local dealer information, visit the find a

showroom section of our website, subzero.com.

INTERIOR FEATURES

•Re rigerator

Dual Refrigeration

2 Temperature Zones

3 Adjustable Glass helves

1 tationary helf

Adjustable Deli Drawer

3 Adjustable Door helves

Adjustable Dairy Compartment

Egg Container

•Freezer (Drawers)

1 Removable Drawer Divider

Automatic Defrost

Automatic Ice Maker

INSTALLATION NOTES

tainless steel panels with handles are

available as accessories. These panels are

not installed at the factory.

Complete installation specifications, including

panel sizes, can be found on our website,

subzero.com/specs.

SPECIFICATIONS

Overall Width 27"

Overall Height 80"

Overall Depth 24"

Door Clearance 251/2"

Drawer Clearance 191/2"

Refrigerator Capacity 10.2 cu ft

Freezer Capacity 5.1 cu ft

Finished Opening 27" W x 80" H x 25" D*

Electrical Requirements 115 V AC, 60 Hz

15 amp dedicated circuit

Plumbing Requirements 1/4" OD copper,

braided stainless steel or PEX tubing

35–120 psi

hipping Weight 360 lbs

*Depth is 24" from the front of the unit to its bac .

Your design may necessitate moving the unit bac ,

or cabinets forward to achieve a flush fit. This will

require a minimum opening depth of 25".

27" Integrated

Combination—Tall

Unit dimensions may vary by ± 1/8".

INSTALLATION SPECIFICATIONS

Opening Dimensions

Location of Electrical upply Location of Water upply

OVERALL DIMENSIONS

Dimensions in parentheses are in

millimeters unless otherwise specified.

27" (686)

14"(356)

13/16"

(21)

341/2"

(876)

203/8"

(518)

101/4"

(260)

131/4"

(337)

1/2"

(13)

3/8"

(10)

80"

(2032)

TO TOP OF

OPENNG

24" (610)

789/16"

(1995)

93/4"

(248)

(102)

HEIGHT DIMENSIONS ±

1/2" (13)

24"

(610)

DIMENSIONS WILL VARY WITH PANEL THICKNESS

191/2"

(495)

251/2"

(648)

45/8"

(117)

13" (330)

1/4" (6)

41/2"

(114)

POSITION OUTLET WITH

GROUNDING PRONG

TO THE RIGHT

FLOOR

21/2" (64)

FRONT VIEW

3" (76)

(229)

3/4"

(19)

FLOOR

21/2" (64)

FRONT VIEW

(229)

(152)

TOP VIEW

11/2"

(38)

21/2"

(64)

BACK

WALL

27" (686)

OPENING WIDTH

25" (635)

OPENING DEPTH

80" (2032)

OPENING

HEIGHT

FRONT VIEWSIDE VIEW

25" (635)

OPENING

DEPTH

TOP VIEW
