Digital Free-To-Air Terrestrial Receiver PRIMA II

User Manual

Bedienungsanleitung

Manuel d'utilisation

Manuale d'uso

Manuel de Usario

Návod k obsluze

Information in thisdocument is subjectto change withoutnotice.

The manufacturer doesnot make anyrepresentations or warranties

(implied or otherwise)regarding the accuracyand completeness ofthis

document and shallin no eventbe liable forany loss ofprofit or any

commercial damage, includingbut not limitedto special, incidental,

consequential, or otherdamage.

Safety Instructions

Always read thesafety instructions carefully

Keep this User'sManual for futurereference

Keep this equipmentaway from humidity

Lay this equipmenton a reliableflat surface beforesetting it up.

Do not standit on softfurnishings.

If any ofthe following situationarises, get theequipment checked by

a service technician:

The equipment hasbeen exposed tomoisture.

The equipment hasbeen dropped anddamaged.

The equipment hasobvious sign ofbreakage.

The equipment hasnot been workingwell or youcannot get itwork

according to User'sManual.

Warning

Toprevent the riskof electric shock,do not openthe cover orthe

back of thereceiver.

Do not blockthe ventilation holesof the device.Leave appropriate

gap above andaround it toallow for adequateventilation.

Do not placethe device inan unventilated cabinetor on topof a unit

which emits heat.

No part ofthis publication maybe reproduced inany form byany means

without the priorwritten permission. Othertrademarks or brandnames

mentioned herein aretrademarks or registeredtrademarks of their

respective companies.

English

Disclaimer

Tableof Contents

Introduction ................................................................................... 1

Front and RearPanel...................................................................... 2

Remote Controll... .........................................................................3

Connections...................................................................................5

First TimeInstallation..................................................................... 7

Basic Operations ...........................................................................9

Using the On-ScreenSetup Menu...................................................13

Troubleshooting ...........................................................................25

Specifications.............................................................................. 26

1. Introduction

II is aFree-To-Airdigital terrestrial receiver, allowing youto

access free-to-air digitalterrestrial TVchannels and radiobroadcasts on

your TVset. Its digitalreception covers VHF& UHF band.Compared

with the analogTV programs,digital TVprograms eliminate thenoise

and interference butoffer highquality video andaudio. Anon-screen

initial installation guideis provided sothat you caneasily start toenjoy

watching the programs. In addition, afully featured remotecontroller is

included that offers you accessto every featurewith a simplepress of a

button.

1.1 MainFeatures

Fully complies withEuropean DVB-Tstandard

MPEG2 ISO/IEC 13818transport stream compliantaudio/video decoding

Bandwidth of 6/7/8MHzsupported

COFDM demodulator

Automatic/manual channel search

Channel edit, movingand deletion

Parental lock control

NTSC/PALconverting automatically andmanually

EPG (Electronic ProgramGuide) andTeletextfunction

Multiple-language OSD (

Supports multi-subtitle

RS-232 serial port for software upgrade

2 SCARTs (TV SCART output/VCRSCART input)

Tuner RFin/loop through

Active antenna support(5 volt)

SDTV only

Full function remotecontrol

1.2 Accessories

Before installation, pleasecheck the itemsof the package.

The package shouldcontain the followingitems:

~ PRIMAII Receiver x1

~ Remote Controll x1

~ AAABattery for theremote controllerx2

~ User's Manualx1

PRIMA

English, German, French,Italian, Spanish,

Czech)

English

2. Front Panel andRear PanelIllustration

2.1 Frontpanel

1 ANT IN : This socket connects to your external aerial.

2 TO TV: This socket willbypass the RF signalto either yourTV or another

video system.

3 S/PDIF COAXIAL: This socket connectsto a coaxial socketon your surround soundsystem.

4 VCR SCART: This socket connectsto either a DVDor other video system.

5 TV SCART: This socket connectsto your TV.

6 RS-232 PORT: This socket isonly used for softwareupgrade.

7 MAINS CABLE: This is usedto connect to yourmain power supply.

1 POWER BUTTON: Used to turn on/off the main powersupply.

2 REMOTE CONTROLSENSOR: Used to receive thesignal from the remotecontrol.

3 STANDBYINDICATOR: Used to visually showpower state of thereceiver, the green

LED will be lightif turned on thereceiver and the redLED will be light if the receiver

entered standby mode.

4 CHANNEL UP/DOWN: Used to change channels without using the remotecontrol.

2.2 Rearpanel

Remote Key Function:

1. DTV/VCR To switchbetween the VCR SCARTinput and the

DTV output mode.

2. INFO To displayinformation about the channelbeing

viewed or further informationabout the program

when in small EPGscreen.

3. PAUSE To pause the program being viewed.

4. EPG To displayinformation about the programbeing

viewed and what's onnext.

5. EXIT To returnto the previous screen or menu.

6. Ok To confirma selection within amenu.

7. VOL+ To movearound the menu screens or changing

the volume in non-menustate.

8. FAVORITE: To access your favourite channels.

9. GAME: To select3 built-in mini games: Mine,Tetris,

Gomoku, and the Calendar.

10. RECALL To switchbetween the last twoviewed channels.

11. SUBTITLE:To switchbetween different subtitles orselect

subtitle to On that are broadcasted

12. TEXT: To openteletext OSD display ifteletext available

in the broadcasted stream.

13. STANDBY: To switchthe receiver to onand standby.

14. MUTE To turn the sound on oroff directly.

15. MENU To openthe main menu window.

16. CH+ To movearound the menu screens or selecting

the channels in non-menustate.

17. VOL- To movearound the menu screens or changing

the volume in non-menustate.

18. CH- To movearound the menu screens or selecting

the channels in non-menustate.

19. NUMBER KEYS:To selectchannel numbers or input

numbers in menus.

20. AUDIO To setthe sound output, theavailable settings are

STEREO, LEFT,RIGHT, MONO.

21. TV/RADIO:To switchbetween TV channels andRadio

stations.

22. COLOR KEYS(RED/GREEN/YELLOW/BLUE): To operate

different functions inTEXT screen or othermenus.

Note: SUBTITLE/TEXT/LANGUAGE may not be available

for all channels

2.2 RemoteControll

English

2.3 Installingthe Batteries

Remove the batterycover from theremote control andput 2XAAAsize batteries

inside the compartment.

The diagram insidethe battery compartmentshows the correctway to installthe

batteries.

OPEN

1.Open the cover 2.Install batteries 3.Close the cover

2.4 Usingthe RemoteControl

Touse the remotecontrol, point ittowards the frontof the digitalreceiver

The remote controlhas a rangeof up to7 metres fromthe receiver atan angle

of up to60 degrees.

The remote controlwill not operateif its pathis blocked.

Sunlight or verybright light willdecrease the sensitivityof the remote

control.

Caution: Make sure tocheck the voltagespecification of thewall outlet

is the samerating with thereceiver.Toprevent the riskof electric shock,

do not openthe cover orthe back ofthe receiver.

3. Connections

3.1 Connectingto aTV Set

English

3.2 Connectingto TVand VCR

Note: When connecting thereceiver to otherequipment, e.g., TV, VCR and

amplifier, makesure to referto relevant usermanual for instruction.Also, make

sure you disconnectall the equipmentsfrom the mainssupply before theconnection.

VCR

After allthe connections havebeen made properly, switch onyour TV.

Make sure thereceiver is connectedto the mainsand pressPower to

switch the receiveron. If youare using thereceiver for thefirst time,

a First TimeInstallation menu will bedisplayed to guideyou through

the initial setup.Use the remotecontroller to finishthe setup.

1. At theFirst time installationmenu, select infirst step yourregional

settings, for nextstep press on the remotecontrol.

2. Select thenyou're OSD Language,Time Zoneand AntennaPower.

If you usean active antennaplease selectAntenna Power toON.

Then selectNEXT to proceed.

Note: Make sure toselect the regionyou are locatedsince the receiverwill scan the

channels based onthe bandwidth ofthe region youselected. If yourregion is noton

the list, youare recommended toconduct a manual search. Refer to Manual

Search on page 16 for details.

4. FirstTime Installation

England

English

GMT + 00:00

OFF

First Time Installation (1)

BACK NEXT

Region

Language

Time Zone

Antenna Power

English
