Strong Digital Satellite Receiver Manual de usuario

Digital Satellite Receiver

USER’S MANUAL

Table of contents

Safety…………………………………………………………………………….……

General Introduction………………………………………………………….…..….

Front Panel / Rear Panel…………………………………………………….……...

Remote Control Unit………………………………………………………….….….

Main Menu…………………………………………………………………….……..12

1. Satellite……………………………………………….…………………….….....12

1.1 ADD Satellite………………………………………………………………...…..12

1.2 Edit Satellite …………………………..……………………………….………13

1.3 Delete Satellite…………………………………………………………….…….13

1.4 Blind Scan…………………………………………………………...………..….13

1.5 Auto Scan……………………………………………………………..………….14

2.Prog List……………………..………………………………………………..……14

2.1 TV List……………………………………………………………………………14

2.2 Radio List………………………………………………………………..…..…...15

2.3 TV Favorite List…………………………………………………………..…..…15

2.4 Radio Favorite List…………………………………………………..…………..15

3. Prog Edit………………………………………………………………….…..……15

3.1 Choose Fav Prog……………………………………………………….………16

3.2 Move Program………………………………………..…………………………16

3.3 Delete Program……………………………………..………………… …..……16

3.4 Program Edit………………………..………………..……………………… …16

3.5 Loop Program………………………..………………..…………………………16

Table of contents

4. TP…………………………………………………………………………………..16

4.1 Add Transponder………………….…………………………………….……....16

4.2 Edit Transponder……………………………………………….…………….…17

4.3 Delete Transponder……………………………………………..……………...17

4.4 Manu Scan……………………………………………………………….……...17

5. System………………………………………………………………………….…17

5.1 TV Standard………………………………………………………………….…17

5.2 Language………………………………………………...................................17

5.3 Factory default……………………………………………………….……...….17

5.4 System Update………………………………………………………….….…...17

5.5 OSD Setting…………………………………………………………….….…....18

5.6 Picture Setting……………………………………………………….….….…...18

5.7 Version…………………………………………………………………………...18

5.8 Parental Lock…………………………………………………………….……...18

6. Tools………………………………………………………………………...……..18

6.1 Calendar………………………………………………………………….………18

6.2 Russion………………………………………………………………….………. 18

6.3 Snake……………………………………………………………………………. 18

Software Update…………………………………………………………………..…20

Trouble Shooting………………………………………………………………….…21

Glossary……………………………………………………………….……………...22

Specification

………………………………………………….…………………….….24

Safety Instructions

This STB has been manufactured to satisfy the international safety standards.

Please read the following safety precautions carefully.

MAIN SUPPLY

:AC 100/240V, 50/60Hz, 30W.

OVERLOADING

:Do not overload a wall outlet, extension cord or adapter as this may result

in fire or electric shock.

Ensure that the power source (socket) is easily accessible.

LIQUIDS

:This STB shall not be exposed to dripping or splashing and that no objects

filled with liquids, such as vases, shall be placed on the STB.

CLEANING

:Disconnect the STB from the main supply before cleaning. Do not use any

kind of solvents to clean the STB, only use a soft-dry cloth.

VENTILATION

:The slots on top of the STB must be left uncovered to allow proper airflow

to the unit.

Ensure a minimum distance of 5cm around the apparatus for sufficient

ventilation.

Ensure that the ventilation is not impeded by covering the ventilation

openings with items such as newspapers, table-cloths, curtains, etc.

Do not stand the STB on soft furnishings or carpets.

Do not expose the STB to direct sunlight or do not place it near a heater.

Do not stack electronic equipments on top of the STB.

Do not place naked flame sources, such as lighted candles on the

apparatus.

ATTACHMENTS

:Do not use any non recommended attachments as these may cause

hazard or damage to the STB.

Safety Instructions

CONNECTION TO THE SATELLITE DISH LNB

:Disconnect the STB from the main supply before connecting or

disconnecting the cable from the satellite dish.

FAILURE TO DO SO CAN DAMAGE THE LNB.

CONNECTION TO THE TV

:Disconnect the STB from the main supply before connecting or

disconnecting the cable from TV.

FAILURE TO DO SO CAN DAMAGE THE TV.

EARTHING

:The LNB cable MUST BE EARTHED to the system earth for the satellite

dish.

LOCATION

:Place the STB indoor in order not to expose to lightening , rain or Sunlight.

Use the apparatus only in moderate climates (not in tropical climates).

Battery handling

:Batteries may contain toxic agents that are hazardous to the environment.

Therefore, dispose of the batteries immediately according to the prevailing

statutory regulations. Never throw the batteries in normal household waste.

General Introduction

INTRODUCTION

This manual will help you learn basic functions such as installation, selecting

channels and many other functions of the STB. All functions can be operated by

the remote control. You can easily install it by selecting ”Installation” function

and upgrade its software through communication cable.

The remote control is designed for easy access to all the functions at once and

for comfortable grab for your hand. It is programmed to control all functions and

to easily watch TV and Radio programs via the STB.

WARNING

Any problems can be caused by the use of unofficial software. The use of

software versions other than dealers or distributors official software will void the

manufacturer’s warranty. It is advised that only the formal software released

from dealers or distributors should be used.

General Introduction

UNPACKING

Unpack the unit and check to make sure that all of the following

items are included in the packaging.

1 x Remote Control Unit (RCU)

1 x User Manual

2 x AAA batteries

1 x Digital Satellite Receiver

1 x A/V Cable

We hope you enjoy using your digital satellite receiver!

Front Panel/ Rear Panel

Front Panel

: Press to switch between Operation and Standby modes.

CH: Changes channels or items from top to bottom on the menus.

Dimension: 250 x 175x 38(W x D x H )

Front Panel/ Rear Panel

Rear Panel

No. Symbol Function

1 LNB INPUT Use to connect an antenna.

2 RS-232 Use it when connecting to your PC.

3 A/V RCA To connect the Audio/Video RCA output to TV.

4 RF OUT Connect to TV through Modulator.

5 POWER Power ON/OFF switch.

Remote Control Unit
