STMicroelectronics STM32Cube Manual de usuario

Version 1.3 (May 27, 2019)

Quick Start Guide

STM32Cube function pack for IoT tracker node with

LoRa connectivity, GNSS and sensors

(FP-ATR-LORA1)

Quick Start Guide Contents 2

FP-ATR-LORA1: STM32Cube function pack for IoT tracker node with

LoRa connectivity, GNSS and sensors

Hardware and Software overview

Setup & Demo Examples

Documents & Related Resources

STM32 Open Development Environment: Overview

Hardware Overview

FP-ATR-LORA1: STM32Cube function pack for IoT tracker node with LoRa connectivity, GNSS and sensors is

available for two platforms: modular and integrated.

X-NUCLEO-IKS01A2

LSM6DSL

LPS22HB

HTS221

X-NUCLEO-GNSS1A1

LIV-3F (TESEO III)

B-L072Z-LRWAN1 discovery kit

Hardware overview

B-L072Z-LRWAN1 hardware description

•The B-L072Z-LRWAN1 Discovery kit embeds the CMWX1ZZABZ-091

LoRa®/Sigfox™ module (Murata). This Discovery kit allows users to develop

easily applications with the STM32L072CZ and the LoRa®/Sigfox™ RF

connectivity in one single module.

•The B-L072Z-LRWAN1 Discovery kit has the full set of features available in the

STM32L0 series and offers ultra-low-power and LoRa®/Sigfox™ RF features.

The B-L072Z-LRWAN1

•Discovery kit is a low-cost and easy-to-use development kit to quickly evaluate

and start a development with an STM32L072CZ microcontroller.

•The B-L072Z-LRWAN1 Discovery kit includes LoRa®/Sigfox™ RF interface,

LEDs, pushbuttons, antenna, Arduino™ Uno V3 connectors, USB 2.0 FS

connector in Micro-B format.

•The integrated ST-LINK/V2-1 provides an embedded in-circuit debugger and

programmer for the STM32L0 MCUs.

•The LoRaWAN™ stack is certified class A and C compliant. It is available inside

the I-CUBE-LRWAN firmware package.The Sigfox™ stack is RCZ1, RCZ2, and

RCZ4 certified.

•It is available inside the X-CUBE-SFOX expansion package.

•To help users setting up a complete node (LoRaWAN™, Sigfox™, or both), the

B-L072Z-LRWAN1 Discovery kit comes with the STM32 comprehensive free

software libraries and examples available with the STM32Cube package, as well

as a direct access to the Arm® Mbed Enabled™ resources at the http://mbed.org

website.

Latest info available

at www.st.com

B-L072Z-LRWAN1

Tee

GNSS expansion board

Hardware Overview 5

X-NUCLEO-GNSS1A1 Hardware Description

•The X-NUCLEO-GNSS1A1 expansion board is based on the Teseo-

LIV3F tiny GNSS module.

•It represents an affordable, easy-to-use, global navigation satellite

system (GNSS) module, embedding a Teseo III single die standalone

positioning receiver IC, usable in different configurations in your

STM32 Nucleo project.

•The Teseo-LIV3F is a compact (9.7x10.1 mm) module that provides

superior accuracy thanks to the on-board 26 MHz temperature

compensated crystal oscillator (TCXO) and a reduced time-to-first fix

(TTFF) with its dedicated 32 KHz real-time clock (RTC) oscillator.

•The Teseo-LIV3F module runs complete GNSS firmware (X-CUBE-

GNSS1) to perform all GNSS operations including acquisition,

tracking, navigation and data output without external memory

support.

•The X-NUCLEO-GNSS1A1 expansion board is compatible with the

Arduino™ UNO R3 connector and the ST morpho connector, so it

can be plugged to the STM32 Nucleo development board and

stacked with additional STM32 Nucleo expansion boards.

Key Products on board

Teseo-LIV3F: Single die standalone positioning receiver IC

working on multiple constellations, 10x10mm compact size.

26MHz Temperature Compensated Crystal Oscillator (TCXO)

and reduced Time To First Fix (TTFF) relying to a 32KHz

Real Time Clock (RTC) oscillator for superior accuracy. Latest info available at www.st.com

X-NUCLEO-GNSS1A1

Teseo-LIV3F Battery holder

Antenna connector Arduino UNO R3 Connectors

LPS22HB

HTS221

Key Product on board

LSM6DSL

MEMS 3D accelerometer (±2/±4/±8/±16 g) + 3D

gyroscope (±125/±245/±500/±1000/±2000 dps)

LSM303AGR

MEMS 3D magnetometer (±50 gauss) + MEMS 3D

accelerometer (±2/±4/±8/±16 g)

LPS22HB

MEMS pressure sensor, 260-1260 hPa absolute digital

output barometer

HTS221

Capacitive digital relative humidity and temperature

DIL 24-pin

Socket available for additional MEMS adapters and

other sensors (UV index)

DIL 24-pin

Motion MEMS and environmental sensors expansion board

Hardware Overview 6

X-NUCLEO-IKS01A2 Hardware Description

•The X-NUCLEO-IKS01A2 is a motion MEMS and

environmental sensor evaluation board system.

•It is compatible with theArduino UNO R3 connector

layout, and is designed around ST’s latest sensors.

Arduino UNO R3 connector

ST morpho connector**

** Connector for the STM32 Nucleo Board

LSM6DSL

LSM303AGR

Latest info available at www.st.com

X-NUCLEO-IKS01A2

STEVAL-STRKT01 evaluation board

Hardware Overview 7

STEVAL-STRKT01 Hardware Description

•The STEVAL-STRKT01 LoRa® IoT tracker is

designed and optimized to implement the latest

technologies in IoT tracker applications such as

asset, people and animal tracking as well as fleet

management. Thanks to the STM32L072CZ

embedded in the CMWX1ZZABZ-091 LoRa® module

(by Murata), it allows acquiring position from Teseo-

LIV3F GNSS module and monitoring motion

(LIS2DW12) and environmental (HTS221 and

LPS22HB) sensors.

The board also transmits and receives data to and

from the cloud over a LoRaWAN™ network.

The STEVAL-STRKT01 is a LiPo battery operated

solution and implements low power strategies thanks

to an enhanced power/battery management design,

based on the STBC02 battery charger and the

ST1PS01 step-down converter, to ensure long battery

autonomy. The STUSB1600Aaddresses 5 V USB

Type-C port management and implements high

voltage protection features against short-circuits to

VBUS up to 28 V. Latest info available at www.st.com

STEVAL-STRKT01

http://www.st.com/IoTLoraTracker

Key Products on board

•CMWX1ZZABZ

•LoRaTM module based on high-performance and

low power ARM® Cortex®-M0 32-bit STM32L072

and SX1276 Semtech LoRa transceiver

•TESEO-LIV3F

•GNSS standalone module based on TESEO III

•STBC02

•Li-Ion linear battery charger with LDO, load

switches and reset generator

•ST1PS01EJR

•400mA Nano-Quiescent™ Synchronous step-down

converter with voltage selection and power good

•STUSB1600A

•USB Type-C controller

•LIS2DW12, HTS221, LPS22HB

•Motion and environmental sensors

•M95M02-DR

•EEPROM

STEVAL-STRKT01 evaluation board

Hardware Overview 8

FP-ATR-LORA1

Software Overview 9

FP-ATR-LORA1 Software Description

FP-ATR-LORA1 is an STM32Cube function pack which lets you

read data from environmental and motion sensors, retrieve geo-

position from GNSS and send collected data via LoRaWAN

connectivity.

The package implements low power profiles and related transitions

to ensure long battery autonomy. This software together with the

suggested combination of STM32 and ST devices can be used, for

example, to develop asset tracking, fleet management and pet/child

tracking applications.

The software runs on the STM32 microcontroller and includes

drivers for the LoRa radio, Teseo-LIV3F GNSS module, the motion

and environmental sensors, and the power management.

Key features

•Complete firmware to connect an IoT node to a LoRaWAN

network, sending geo-position coming from GNSS and

environmental and sensor data.

•Middleware library supporting LoRaWAN specification

1.0.2 class A and USB 2.0.

•Teseo-LIV3F based GNSS positioning and geofencing

•LoRaWAN keys provisioning via USB

•Power/Battery Management with low-power operating

modes

•Datalogging on external EEPROM for STEVAL-STRKT01

and on internal RAM for B-L072Z-LRWAN1, with data

download over-the-air or off-line via USB

•Sample implementation available for STEVAL-STRKT01

evaluation board and for X-NUCLEO-GNSS1A1 and X-

NUCLEO-IKS01A2 expansion boards connected to a B-

L072Z-LRWAN1 development board

Overall Software Architecture

FP-ATR-LORA1

Latest info available at www.st.com

Quick Start Guide Contents 10

FP-ATR-LORA1: STM32Cube function pack for IoT tracker node with

LoRa connectivity, GNSS and sensors

Hardware and Software overview

Setup & Application Examples

Documents & Related Resources

STM32 Open Development Environment: Overview
