StarTech.com 4UDRAWER Manual de usuario

Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: May 25, 2023 1:19 PM

Product ID

4UDRAWER

Component Function

1Drawer Key Lock

• Use the included Set of Keys to Lock or Unlock

the Drawer

• Rev 02 and above only

2Drawer Handle • Use to Open or Close the Drawer

3Mounting Brackets

• Fasten the Drawer to the Front Posts of the Rack

or Cabinet

• Two Holes on each side of the Drawer

4U Storage Drawer for 19” Server Racks

Requirements

For the latest drivers/software, technical specications, and declarations of

conformance, please visit: www.StarTech.com/4UDRAWER

Package Contents

• 4U Storage Drawer x 1

• M5 Screws and Cage Nuts x 4

• Plastic Washers x 4

• Set of Keys x 1 (Rev 02 and Above Only)

Installation

Warnings! Read the entire Quick-Start Guide and ensure the instructions are fully

understood before assembling and using this product. Before adding equipment

to this product, ensure this product has been properly mounted. Never operate this

product if parts are missing or damaged. Ensure the weight of the equipment does not

exceed the weight capacity of this product. If the weight capacity is exceeded, personal

injury or damage to the equipment is possible. This product can support 55.1 lbs [25

kgs]. The maximum supported weight is only possible when both mounting brackets

are properly mounted to two front posts on a rack. Arrange your equipment in the rack

in descending order of weight. The lightest equipment is installed at the top of the rack,

and the heaviest is on the bottom.

1. Locate a suitable section in the Rack/Cabinet to mount the 4U Storage Drawer. The

Drawer itself requires 4U of space within the rack/cabinet.

2. (Optional) If the Rack uses Square Mounting Holes, install the included Cage Nuts

into the Square Mounting Holes on the Front Posts of the Rack.

3. Place the Drawer into the Rack and align the Mounting Points on the Front

Brackets of the Drawer with the Mounting Points on the Rack (e.g. the cage nuts, if

used).

4. Use a Phillips Head Screwdriver and the included M5 Screws to secure the Drawer

to the Rack.

Note: If the included Cage Nuts and/or M5 Screws are not used, please use the

recommended Mounting Screws for the Rack.

5. Make sure the M5 Screws are properly tightened and the Drawer has no movement

before attempting to place anything inside.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or

symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are

for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or

an endorsement of the product(s) to which this manual applies by the third-party company in question. StarTech.

com hereby acknowledges that all trademarks, registered trademarks, service marks, and other protected names

and/or symbols contained in this manual and related documents are the property of their respective holders.

PHILLIPS® is a registered trademark of Phillips Screw Company in the United States or other countries.

Safety Measures

• Read the entire manual and ensure the instructions are fully understood before assembling and/or using this

product.

Mesures de sécurité

• Lisez tout le manuel et assurez-vous que vous comprenez les instructions avant de commencer à assembler et

utiliser ce produit.

安全対策

• 最初に取扱説明書を最後まで読み、本製品の組み立て方をすべて理解してから組み立て作業を始めて下

さい。

Misure di sicurezza

• Leggere l’intero manuale e assicurarsi di aver compreso tutte le istruzioni prima di iniziare ad assemblare e a

utilizzare questo prodotto.

Säkerhetsåtgärder

• Läs hela manualen och se till att du förstår instruktionerna innan du börjar montera och använda produkten.

Warranty Information

This product is backed by a lifetime warranty.

For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss

of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the

product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the

limitations or exclusions contained in this statement may not apply to you.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com

Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp

The Netherlands
