StarTech.com PCIUSB3S2 Manual de usuario

Manual Revision: 01/16/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

PCIUSB3S2

2 Port PCI SuperSpeed USB 3.0 Card

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Hardware Installation .............................................................................................................................. 2

Driver Installation...................................................................................................................................... 2

Specications..........................................................................................4

Technical Support ..................................................................................5

Warranty Information............................................................................5

Instruction Manual

Introduction

The PCIUSB3S2 2-Port PCI SuperSpeed USB 3.0 Adapter Card allows for legacy PCI slots

to support the USB 3.0 standard, which is capable of data transfer rates up to 5 Gbps

(10x faster than USB 2.0 at 480 Mbps). This allows for full use of the PCI bus at 1.3 Gbps,

allowing older systems double the performance with USB 3.0 versus using USB 2.0

cards and peripherals. Also being backwards compatible with USB 2.0 and 1.x devices,

this versatile adapter card will work with future USB 3.0 devices while still being able to

support older devices.

Designed for older PCI-based systems or computers with only PCI expansion slots left

available, this adapter card allows those systems to stay relevant and up-to-date with

the latest USB technology.

Packaging Contents

• 1 x PCI USB 3.0 card

• 1 x Low Prole Installation Bracket

• 1 x Driver CD

• 1 x Instruction Manual

System Requirements

• PCI enabled computer system with available PCI slot (3.3V or 5V, 33MHz)

• Microsoft® Windows® XP/ Server 2003/ Vista/ Server 2008 R2/ 7 (32/64-bit)

Instruction Manual

Installation

WARNING! PCI cards, like all computer equipment, can be severely damaged

by static electricity. Be sure that you are properly grounded before opening

your computer case or touching your PCI card. StarTech.com recommends

that you wear an anti-static strap when installing any computer component.

If an anti-static strap is unavailable, discharge yourself of any static electricity

build-up by touching a large grounded metal surface (such as the computer

case) for several seconds. Also be careful to handle the PCI card by its edges

and not the gold connectors.

Hardware Installation

1. Turn your computer o and any peripherals connected to the computer (i.e. Printers,

external hard drives, etc.). Unplug the power cable from the rear of the power

supply on the back of the computer and disconnect all peripheral devices.

2. Remove the cover from the computer case. Refer to documentation for your

computer system for details.

3. Locate an open PCI or PCI-X slot and remove the metal cover plate on the rear of the

computer case.

4. Insert the card into the open PCI or PCI-X slot and fasten the card’s bracket to the

rear of the case.

NOTE: If installing the card into a small form factor/low prole system, replacing the

pre-installed full prole bracket with the included low prole installation bracket may

be necessary.

5. Connect an 4-pin LP4 power connector from the system power supply to the LP4

connector on the rear edge of the card. This ensures all ports have full power.

6. Place the cover back onto the computer case.

7. Insert the power cable into the socket on the power supply and reconnect all other

connectors removed in Step 1.

Driver Installation

Windows XP/ Server 2003

1. Upon starting Windows, if the “Found New Hardware” wizard appears on the screen,

cancel/close the window and insert the included Driver CD into the computer’s CD/

DVD drive.

2. AutoPlay should automatically launch and provide the option to browse the disk. If

not, open “My Computer” and double-click on the CD/DVD drive the disk is inserted

into and navigate to the USB 3.0 Host / NEC folder and open the setup.exe le.

Instruction Manual

3. This should launch the driver Installation wizard.

4. Complete the wizard and this should automatically install all necessary drivers/

software.

Windows Vista/ 7/ Server 2008 R2

1. Upon starting Windows, if the “Found New Hardware” wizard appears on the screen,

cancel/close the window or choose not to install the drivers and insert the included

Driver CD into the computer’s CD/DVD drive.

2. AutoPlay should automatically launch and provide the option to browse the disk. If

not, open “Computer” and double-click on the CD/DVD drive the disk is inserted into

and navigate to the USB 3.0 Host / NEC folder and open the setup.exe le.

3. This should launch the driver Installation wizard.

4. Complete the wizard and this should automatically install all necessary drivers/

software.

Instruction Manual

Specications

Bus Interface

PCI specication 3.0

(33MHz, 3.3V/5V)

USB 3.0 specication 1.0

Form Factor Full/Low Prole

Chipset ID NEC uPD720200

External Connectors 2 x USB 3.0 type A female

Internal Connectors 1 x 4-pin LP4 Power male

Maximum Data Transfer Rate USB 3.0: 5 Gbps

PCI: 1.33 Gbps

Operating Temperature 5°C ~ 50°C (41°F ~ 122°F)

Storage Temperature -25°C ~ 70°C (-13°F ~ 158°F)

Humidity 15% ~ 90% RH

Dimensions 120.0mm x 57.0mm x 20.0mm

Weight 60g

Compatible Operating Systems Windows XP/ Server 2003/ Vista/

Server 2008 R2/ 7 (32/64-bit)

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
