StarTech.com PCI1394_2 Manual de usuario

PCI Firewire DV Editing Kit

PCI1394_2

PCI1394_2LP

Instruction Manual

Actual product may vary from photo

2+1 Port IEEE-1394 FireWire PCI Card with Digital Video Editing Kit

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aannddootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other protected names

and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur

these references are for illustrative purposes only and do not represent an endorsement of a

product or service by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks,

registered trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Hardware Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Instruction Manual

TTaabblleeooffCCoonntteennttss

Instruction Manual

Thank you for purchasing a StarTech.com PCI 1394 2+1 FireWire card. Providing two

external and one internal FireWire port, this card is the perfect solution for connecting a

broad array of peripherals including digital video cameras, MP3 players and more to a

host computer, for top level performance and file transfer capability.

IInnttrroodduuccttiioonn

•Supports data transfer rates of 100, 200 and 400 Mbps

Features

System requirements

•A computer with an available PCI slot

Package contents

This package should contain:

•Compliant with IEEE 1394-1995, 1394a (rev. 1.1)

•Compliant with OHCI Interface Specification 1.0

•Provides hot-swappable connectivity for FireWire peripherals

•Operating system: Windows® 2000 / XP / Server 2003 / Vista

•Two Port PCI FireWire Card (1)

•FireWire Cable (1)

•Video Editing Software Kit (1)

•Instruction Manual

•Low-profile Bracket (1) (PCI1394_2 only)

•Standard Bracket (1) (Pre-installed, PCI1394_2 only)

Instruction Manual

HHaarrddwwaarreeGGuuiiddee

Please note: The internal FireWire port (designated above as P1) cannot be used while

the first external port (designated above as P2) is in use.

P1, P2:FireWire 400 port (6 pin)

P3: FireWire 400 port (4 pin)

IInnssttaallllaattiioonn

WARNING! PCI cards, like all computer equipment, can be severely damaged

by static electricity. Be sure that you are properly grounded before opening your

computer case or touching your card. StarTech.com recommends that you wear

an anti-static strap when installing any computer component. If an anti-static

strap is unavailable, discharge yourself of any static electricity build-up by

touching a large grounded metal surface (such as the computer case) for

several seconds. Also, be careful to handle the card by its edges and not the

gold connectors.

1. Power down the computer. As an additional precaution, you may wish to disconnect

the computer from the power source.

Instruction Manual

2. Remove the computer cover. For more detailed instruction on how to perform this

step, please refer to the documentation that was included with your computer at the

time of purchase.

3. Locate an empty PCI slot and remove the metal bracket covering the accompanying

empty port/socket.

4. PCI1394_2 only: If you need to change the bracket to fit your case requirements,

please remove the two screws fastening the bracket to the circuit board using a

Philips (cross-head) screwdriver, then replace with the secondary bracket (included).

5. Position the card above the open PCI slot, ensuring that the card is properly aligned

with the slot. Insert the card firmly into the slot, distributing force evenly across the

length of the board. Once inserted, secure the card into the adjoining socket

(previously covered by metal bracket), using the correct size screw.

6. Replace the computer cover and re-connect all power to the computer (if it was

removed in Step #1).

Software Installation

Once the computer has been restarted following the physical installation of the card,

Windows® 2000/XP/Vista will automatically detect and install the correct driver for the

FireWire adapter.

To verify that the driver has correctly been installed:

1. Right-click on the My Computer icon. If you are using Windows Vista, right-click on

Computer.

2. Select Manage, to open the Computer Management window.

3. In the left pane of the Computer Management window, click on Device Manager.

4. In the right pane of the Computer Management window, click on IEEE 1394 Bus host

controller. Here, you should see VIA OHCI Compliant IEEE 1394 Host Controller

listed.

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

LLiimmiittaattiioonnooffLLiiaabbiilliittyy

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

SSppeecciiffiiccaattiioonnss

Chipset VIA 6307

Bus Interface PCI bus 32 bit

Operating System Support Windows 98SE/ME, 2000 and XP, Vista

Connectors External x2 (1 4-pin, 1 6-pin)

Internal (6-pin) x 1

Data Transfer Rates Supported 100/200/400Mbps

Regulatory Certifications ROHS, FCC, CE

8 July 2007 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer Parts”.

Since 1985, we have been providing IT professionals with the quality products

they need to complete their solutions. We offer an unmatched selection of

computer parts, cables, server management solutions and A/V products and

serve a worldwide market through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products and to

access exclusive interactive tools such as the Parts Finder and the KVM

Reference Guide. StarTech.com makes it easy to complete almost any IT

solution. Find out for yourself why our products lead the industry in performance,

support, and value.
