StarTech.com BEZ4MOD Manual de usuario
1
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
Compliance Statements
For the State of California
WARNING: Cancer and Reproductive Harm
www.P65Warnings.ca.gov
Use of Trademarks, Registered Trademarks, and other Protected Names
and Symbols
This manual may make reference to trademarks, registered trademarks, and
other protected names and/or symbols of third-party companies not related in
any way to StarTech.com. Where they occur these references are for illustrative
purposes only and do not represent an endorsement of a product or service
by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com
hereby acknowledges that all trademarks, registered trademarks, service marks,
and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.
Safety Statements
Safety Measures
• Wiring terminations should not be made with the product and/or electric
lines under power.
• Product installation and/or mounting should be completed by a certied
professional as per the local safety and building code guidelines.
• Cables (including power and charging cables) should be placed and routed
to avoid creating electric, tripping or safety hazards.
2
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
Mesures de sécurité
• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit
et/ou les câbles électriques sont sous tension.
• L’installation et/ou le montage du produit doit être réalisé par un
professionnel certié et dans le respect des normes locales et du code de
construction local.
• Les câbles (y compris les câbles d’alimentation et de chargement) doivent
être placés et acheminés de façon à éviter tout risque électrique, de chute ou
de sécurité
安全対策
• 電源が入っている状態の製品または電線の終端処理を行わないでください。
• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に従い、有資格の専門業者が行うようにしてください。
• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回しを行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう
にしてください 。
Misure di sicurezza
• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le
linee elettriche sotto tensione.
• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un
tecnico professionale certicato che conosca le linee guida locali sulle norme
edilizie e sulla sicurezza.
• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati
e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o
pericoli per la sicurezza.
Säkerhetsåtgärder
• Montering av kabelavslutningar får inte göras när produkten och/eller
elledningarna är strömförda.
• Installation och/eller montering får endast göras av behöriga yrkespersoner
och enligt gällande lokala förordningar för säkerhet och byggnormer.
• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så
sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.
Warning Statements
Make sure to assemble this product according to the instructions. Failure to do
so might result in personal injury or property damage.
Never use this product if parts are missing or damaged.
3
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
Table of Contents
Compliance Statements........................................................................1
Safety Statements..................................................................................1
Warning Statements ..............................................................................2
Product Diagram ....................................................................................4
Product Information ..............................................................................5
Package Contents ..................................................................................................................................... 5
Requirements ............................................................................................................................................. 6
Installation ..............................................................................................7
Cutting the Table/Surface ...................................................................................................................... 7
Installing the Module in the Modular Table Box............................................................................ 10
Installing the Lacing Bar (Cable Organization)............................................................................... 13
Installing the Modular Table Box into a Surface............................................................................. 14
Assembling the Cable Management Module ....................................16
Assembly Requirements:........................................................................................................................ 16
Installing the Cable Management Module...................................................................................... 17
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
4
Product Diagram
Lacing Bar
Mounting
Holes (2)
Mounting
Slot
Installation
Holes
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
5
Product Information
Package Contents
BOX4MODULE
• Modular Table Box x 1
• Installation Kit
• Wing Fastener x 2
• Die Cut Outline x 1
• Lacing Bar x 1
• Lacing Bar Screws (M4 x 4 mm) x 4
• Cable Management Module
• Cable Management Bracket x 1
• Cable Management Top Plates x 2
• Cable Management Plate Screws (#6-32 x 3/8”) x 4
• Cable Management Bracket Mounting Screws (#6-32 x 3/8”) x 4
• Small Cable Bushing x 1
• Large Cable Bushing x 1
• User Manual x 1
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
6
Requirements
Installation:
Installation requirements are sold separately.
• Surface for Installation
• Cable Ties
• Tools
• 3/8 Wood Drill Bit x 1
• Phillips Head Screwdriver x 1
• Jigsaw x 1
• Drill x 1
• Writing Utensil x 1
• Painter’s Tape x 1
Module:
Module requirements are optional and will depend on the conguration
needed for the Conference Table setup. Modules to choose from include:
• Docking Station Module (MOD4DOCKACPD)
• Cable Management Module (MOD4CABLEH)
Note: Half size module included, additional cable management brackets
sold separately.
• Power Module (MOD4POWERNA, MOD4POWEREU, or MOD4POWERUK)
• A/V Connectivity Module (MOD4AVHD)
• A/V Module with HDMI over CAT5e/CAT6 (MOD4AVHDBT)
7
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
Installation
For additional information on installing the Modular Table Box, please visit
www.startech.com/MOD4DOCKACPD to watch the installation video.
Notes: StarTech.com is not responsible for any damages related to the
installation of this product.
Prior to installation, please test the product’s port compatibility with all
devices and displays intended for use with this product.
The thickness of the table surfaced used for installation should not exceed
2.25 inches.
Cutting the Table/Surface
Note: Check the underside of the table/surface you are installing the
Modular Table Box into to ensure that there are no obstructions that may
interfere with the installation.
1. Carefully cut along the dotted guideline on the Die Cut Outline, cutting o
the four edges of the Die Cut Outline, leaving the inner Surface Cut-Out
Area intact.
Note: The Die Cut Outline has been created with a built in margin of error
of 1/16” (1.5 mm) in either direction of the marked cut line, to compensate
for any deviation while cutting out the Surface Cut-Out Area.
2. Before cutting the surface of the table, measure and align the Surface Cut-
Out Area (created in step 1) into the desired position on the table’s surface.
Tape the Surface Cut-Out Area in place using Painter’s Tape.
8
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
3. Using a Writing Utensil, trace around the Surface Cut-Out Area to create a
guide on the table’s surface.
Surface Cut-Out Area
4. Carefully remove the Surface Cut-Out Area from the table’s surface.
9
To view manuals, videos, drivers, downloads, and more visit www.startech.com/support
5. Using a Drill with a 3/8”Wood Drill Bit, carefully drill pilot holes in each of
the four corners of the guide.
Drill Pilot Holes
